Material: |
Sus 304 |
Thickness: |
3mm |
Heating Way: |
Steam Heating |
Power Supply: |
According To Your Local Power Supply |
Capacity: |
7BBL |
Certificate: |
CE ,UL ,ISO |
Control System: |
Semi-automatic |
SUS 304 7Bbl Large Scale Brewing Equipment Semi Automatic Control System
Product Description
CGET offer brewers a simple and cost effective brewing solution. By combining the Mash Tun & Lauter Tun, and the Kettle & Whirlpool into our typical 2-Vessel solution, we provide space and cost savings without compromising brewing quality and control.
CGET Microbrewery Equipment systems are available with several options to help deliver brewing efficiency, control & automation, and overall flexibility.
Typical size range: 100L~8000L,1 BBL,2 BBL, 3 BBL, 5 BBL, 7 BBL, 10 BBL, 15 BBL,30BBL (custom sizing & configuration available).
Standard Brewhouse configuration:
1. Mash / Lauter Tun with side grain out access
2. Brew Kettle / Whirlpool Vessel with integrated steam jacket and temperature control
3. Semi-Automated Controls with PLC & Remote Access Support
4. 304 Sanitary Pumps with VFD Controls
5. 304 Stainless Steel Plate Heat Exchanger with integrated temperature controls
6. Manual Sanitary Butterfly Valves
7. Ergonomic and efficient 304 stainless steel Brew Deck with easy access to all vessels and brewing functions
Options:
· Integrated CIP On-Demand System
· Full-Automation PLC Control System
· Hot Liquor Tank –Designed and Sized for Double Brew efficiency
· Cold Liquor Tank –Fully insulated and integrated
· Mash / Lauter Tun Rakers
· Air Actuated Automatic Butterfly Valves
. All brewhouse pipelines are used automatic argon protect welding.
Brewhouse Details:
. 2,3,4 and 5 vessels can be avaiable
. All the tanks materials are made by 304 Stainless steel
. 304 stainless steel operate platform and stairs
. Glass manways
. 1~80bbl volume system can be available
. Grain mill and screw conveyer (optional)
. Plate heat exchanger
. Stainless steel 304 pump with ABB or Siemens motors
. Automatic and Semi-automatic control for choice,PLC or mobile control can be available
1. Dished head top head, cone shaped bottom;
2. Dimensions: according to your plant details
3. Effective volume 7BBL
4. Rock wool insulation, insulation thickness 80mm;
5. Inner tank thickness 3mm, cladding thickness 2mm;
6. Steam heating: Side and cone steam heating jacket, bottom Cone heating(patent product No. 2009200271826), Heat transfer area 1.46m2;
7. Top mechanical agitation: Cycloid reducer, motor power 0.75kw;
8. CIP rotatable spray balls 2 pieces
9. Top manhole, φ500mm, with glass sight glass;
10. Top LED sight light;
11. PT100 temperature probe;
12. Stainless steel try-clamp level gauge, with stainless protection tube;
13. Welding seams brushed polished;
14. 4 legs, with adjustment bolts, 2 fixing holes on the base plates;
15. Indoor vapor condense device, with steam condensate tube;
16. Assorted valves and fittings
Advantage
Professional Beer Equipment manufacture with 21 years experiences in China.
Dedicated team of consulting Services&Professional team of technical engineers
Complete quality control and management systems
Industry leading manufacturing facilities
Complete beer line to meet different capacities and all kinds of beer
Customize machine can be offered(voltage,material,dimension,heating source and so on)
With CE & ISO9001:2000 Certification
