Our company through investment steel smelting and forging factory resume stability, a wide range of available resources.Main produce and process stainless steel bar/rod/shaft/profile,stainless steel pipe/tube, stainless steel coil/sheet/plate/strip, stainless steel wire/wire rod/wire rope.Our company supply products from SAKY,TISCO, LISCO, BAOSTEEL, JISCO and so on.We can customize non-standard special stainless steel products with high quality with short time. Our products used to chemical treatment equipments, chemicals tanks, petrochemical equipment and press plates. It is also used in railway coaches, roof drainage products, storm door frames, food machinery and tableware.
| Type | Nickel Alloy Tube/Pipe |
| Length | 1000mm,3000mm, 5800mm, 6000mm,etc |
| Standard | ASTM,AISI,JIS,DIN,EN |
| Application | Construction,Ship,Boiler,Machinery,etc |
| Certification | ISO,SGS,TUV |
| Technique | Cold Rolled/Hot Rolled |
| Quality | Mill Test Certificate supplied with the shipment ,third part inspection is acceptable |
| Grade |
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc |
| Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC | |
| Incoloy: Incoloy 800/800H/800HT/825/925/926;etc | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc | |
| Monel: Monel 400/K500/R405,etc | |
| Nitronic 40/50/60/75/80A/90/A263 ;etc | |
| Specification | Wire: 0.02-6mm /Strip: 0.05*5.0-5.0*250mm /Bar: φ4-800mm;Length 2000-5000mm /Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm /Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
| Cutting Type | Laser cutting;water-jet cutting;flame cutting |
| Protection | 1. Inter paper available2. PVC protecting film available |
Specifications
Plate and strip are generally supplied after hot or cold rolling, annealing or solid solution, pickling and polishing.
• Rods, forgings and rings may be supplied in the form of forging or hot rolling;It can also be supplied with solid solution after forging.The bar can be polished or polished after solid solution.When the order is required, it can be placed in the cold drawing state.
• Silk can be supplied in solid solution state.For silk materials with nominal diameter or thickness less than 6.35mm, it can be provided with 50% ~ 65% cold drawing deformation after solid dissolution.Silk material with nominal diameter or side length greater than 6.35mm shall be supplied with no less than 30% cold drawing deformation after solid solution treatment.For silk materials with nominal diameter or side length not exceeding 0.65mm, according to the requirements of solid solution treatment, no less than 15% cold drawing deformation is provided.
Item |
600 |
601 |
617 |
625 |
690 |
718 |
X750 |
825 |
C |
≤0.15 |
≤0.1 |
0.05-0.15 |
≤1.0 |
≤0.05 |
≤0.08 |
≤0.08 |
≤0.05 |
Mn |
≤1 |
≤1.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.35 |
≤1 |
≤1 |
Fe |
6-10 |
rest |
≤3 |
≤5.0 |
7-11 |
rest |
5-9 |
≥22 |
P |
≤0.015 |
≤0.02 |
≤0.015 |
≤0.015 |
-- |
-- |
-- |
-- |
S |
≤0.015 |
≤0.015 |
≤0.015 |
≤0.015 |
≤0.015 |
≤0.01 |
≤0.01 |
≤0.03 |
Si |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.35 |
≤0.5 |
≤0.5 |
Cu |
≤0.5 |
≤1 |
-- |
-- |
≤0.5 |
≤0.3 |
≤0.5 |
1.5-3 |
Ni |
≥72 |
58-63 |
≥44.5 |
Bal |
≥58 |
50-55 |
≥70 |
38-46 |
Co |
-- |
-- |
10-15 |
≤1.0 |
-- |
≤1 |
≤1 |
-- |
Al |
-- |
1-1.7 |
0.8-1.5 |
≤0.4 |
-- |
0.2-0.8 |
0.4-1 |
≤0.2 |
Ti |
-- |
-- |
≤0.6 |
≤0.4 |
-- |
-- |
2.25-2.75 |
0.6-1.2 |
Cr |
14-17 |
21-25 |
20-24 |
20-23 |
27-31 |
17-21 |
14-17 |
19.5-23.5 |
Nb+Ta |
-- |
-- |
-- |
3.15-4.15 |
-- |
4.75-5.5 |
0.7-1.2 |
-- |
Mo |
-- |
-- |
8-10 |
8-10 |
-- |
2.8-3.3 |
-- |
2.5-3.5 |
B |
-- |
-- |
≤0.006 |
-- |
-- |
-- |
-- |
-- |
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
