Metal Integrated Insulated Curtain Wall Panels Source Manufacturer | Customized to Your Needs
US$ 80
≥1000 Square Meters
Key Specifications
Get Latest Price
Standard:
Other
After-sales Service:
24-hour after-sales service
Connection Form:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
30 days
Related Products
-
Metal Rock Wool Curtain Wall Panel Four-sided Box Structure Class A Fire Rating Easy InstallationUS$ 80MOQ: 1000 Square Meters -
Metal Integrated Curtain Wall Panel, Thermal Insulation, Customized to Your Needs.US$ 30MOQ: 1000 Square Meters
-
Architectural Insulated Metal Wall Panels Four-sided Box Structure Class A Fire Rating Easy InstallationUS$ 80MOQ: 1000 Square Meters
-
Standardized Metal-Integrated Insulated Curtain WallUS$ 30MOQ: 1000 Square Meters
-
Polyurethane Edge-sealed Rock Wool Color Steel Sandwich Panel for Exterior Walls and Roofs of Industrial Buildings.US$ 16MOQ: 1000 Square Meters
Standard
Other
After-sales Service
24-hour after-sales service
Connection Form
Other
Molding Method
Other
Construction Member
Other
Residential Wall Structure
Other
Steel Type
Other
Structure
Other
Grade
Other
Transport Package
Packing and transportation
Specification
50mm/75mm/100mm
Trademark
Hongxing Technology
Origin
China
Parameter
| Surface coatings | [LUXACOTE]、[PVDF]、[POLYESTER](Other customization) |
| Colors | Provide colors that meet RAL standards according to design requirements |
| Flame spread | Class 1 (British Standard BS476 Part 7) |
| Surface fire resistance | ClassA |
| Project | Standard specifications and parameters |
| Standard specifications of boards | |
| Material of panels | Pre-roller coated aluminum plate/stainless steel plate/copper plate/titanium zinc plate |
| Material of back panels | Pre-roller coated aluminum sheet |
| Core materials | High quality hydrophobic rock wool |
| Adhesives | Thermoplastic two-component polyurethane PU adhesive |
Product Overview
The NS/HP/FP series products continuously optimize new products with super creative design, integrating functionality, practicality and aesthetics to inject fresh power into the construction industry. The outstanding system advantages and diversified design combination forms help realize the integrity of modern architecture.
Key Features
Four-Sided Box Structure
Enclosed composite structure with inner and outer panel wrapping for long-lasting insulation and extended lifespan.
Concealed Clip-Fixing System
Fixing clips concealed beneath the surface prevent penetration damage and allow thermal expansion & contraction without deformation.
Dual EPDM Sealing
Integrated dual EPDM gaskets for superior airtightness, watertightness, and reduced thermal conductivity.
Multi-Directional Installation
Supports horizontal, vertical, and diagonal layouts; vertical installation enables top-to-bottom precision assembly.
Insulated PVC Joint
Reinforced PVC connectors enhance panel strength, break thermal bridges, and allow easy disassembly & recycling.
Performance Advantages
Energy Efficiency: Outstanding insulation reduces HVAC energy consumption.
Fire Safety: Class A fire resistance for high-security buildings.
Acoustic Comfort: 38dB sound insulation for a peaceful indoor environment.
Weather Resistance: Anti-corrosion and fade-resistant coatings for all climates.
