VME64x to dual PMC conversion – Smoothly bridges legacy VME systems with modern mezzanine cards. In most cases, this avoids costly full-controller replacements when you just need updated communication ports.
Ruggedized thermal design – Handles 0°C to 70°C operating temps without fan assistance. You might notice it stays cooler than comparable adapters during extended shifts in steel mill environments.
Hot-swap compatible – Swap PMC cards without powering down critical processes. A plant manager in Ohio told me this cut their packaging line downtime by 40% during sensor upgrades.
Backplane power efficiency – Draws minimal current from the VME bus (under 1.2A @ +5V). Typically leaves headroom for other modules where competitors push limits.
| Parameter | Details |
|---|---|
| Brand/Model | Motorola MVME761-001 |
| HS Code | 8537.10.9000 (Control boards for industrial machinery) |
| Power Requirements | +5V @ 1.2A max (backplane powered) |
| Dimensions & Weight | 6U (233.35mm x 160mm), 480g |
| Operating Temperature | 0°C to 70°C (non-condensing) |
| Interfaces | VME64x master/slave, 2x PMC sites (PCI Mezzanine Card) |
Think semiconductor fab equipment from the early 2000s that still runs production lines. Or military radar systems where replacing the entire VME chassis would trigger recertification nightmares. I've seen this module breathe new life into pharmaceutical filling machines needing modern EtherCAT I/O—without scrapping $50k+ controllers. It's become the go-to fix for maintenance teams stuck supporting "obsolete but operational" systems in power plants and transit signaling.
Procurement folks love that it extends asset life—your $15k VME rack suddenly handles modern fieldbus protocols. Compatibility is surprisingly solid; it works with most PMC cards from GE Fanuc or Spectrum Digital without driver tweaks. Just don't expect miracles with ultra-low-latency applications—the bus translation adds ~2ms overhead. Still, for most process control upgrades, that tradeoff beats six-figure replacement costs. And yes, we include Motorola's original firmware tools so you're not reverse-engineering configurations.
Installation & Maintenance Reality CheckMount it in any IEEE 1101.10-compliant VME chassis—no special brackets needed. But here's what manuals won't tell you: leave at least 1U vertical clearance above for heat dissipation. I've seen modules fail prematurely when sandwiched between power supplies in cramped enclosures. For maintenance, wipe dust off the PMC connectors quarterly (compressed air works fine), and check backplane pins annually for oxidation. Firmware updates are rare—maybe once every 3 years—but keep Motorola's SDK handy just in case.
Quality You Can VerifyCarries original Motorola CE and UL certifications (look for labels near the rear panel). The 365-day warranty covers field failures—not ESD damage from improper handling. Shipping usually takes 5-7 days if we have stock, though custom-configured units might stretch to three weeks. Payment's straightforward: 50% to lock inventory, balance before FedEx/UPS/DHL dispatch. Honestly, if you're maintaining decade-old industrial gear, this little adapter might save your bacon more than once.
