Electrical Inconel 625 Conduits Weather-Resistant Chromate Passivation Galvanized Steel Plate
Negotiable
MOQ: 1 Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Certification:
ISO, ROHS, AISI, ASTM, GB, EN
Shape:
Square
Technique:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Structural Steel Plate for Building Construction Inconel 625 Hot Rolled Steel PlateNegotiableMOQ: 100000 Meters -
High Quality Customized Inconel 625 Stainless Steel Plate PriceNegotiableMOQ: 100000 Meters
-
High Quality A36 Ss400 ASTM Carbon Steel Plate and Carbon Steel Pipe for SaleUS$ 390MOQ: 10 Tons
-
304/304L/316/409/410/904L/2205/2507/310H Premium Stainless Steel Sheets Supplier Custom Sizes & FinishesUS$ 1.72MOQ: 1 Ton
-
ASTM SUS304L Stainless Steel Plates 3-200mm Cold Rolled 201 202 304 303 Stainless Steel Decorated Sheet Plate for Elevator DoorUS$ 800MOQ: 1 Ton
Certification
ISO, ROHS, AISI, ASTM, GB, EN
Shape
Square
Technique
Other
Surface Treatment
Pickling
Model NO.
201 304 316L
Production Process
welding/ polishing/inside bead removing
Specification
Customized
Product Description
The density of titanium is 4.506-4.516g/cm^3, melting point is 1668, boiling point is 3535. Therefore Titanium have low weight, excellent high strength and nonmagnetic festures, low density, excellent corrosion resistance features, high specificate strength and high temperature resistance features, so it is widely used in chemical industry field, medical field, electronics manufacture, mechanical parts field, automobile industry, and aerospace field, etc.
| Grade | TA1, TA2, TA3, TA4, TA10, TA15, TA17, GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR11, GR12 |
| Size | T (0.6mm - 2.0mm) * W (1000mm) * L (3000mm max)T (3.0mm- 5.0mm)*W (1250mm)* L (3500mm max) T (6.0mm - 60mm) * W (2500mm max)* L (7000mm max) |
| Standard | ASTM B 265, ASME SB265 AMS491 |
| Application | Chemical, industry, sports etc. |
| Feature | High corrosion resistance, low density, good thermal stability |
| Surface | Bright, Polished, Pickling, Acid cleaning, Sandblasting |
| Quality and test | Hardness test, Bending test, Hydrostatic etc. |
| Finish | Roll-up(Hard) |
| Surface | Polished |
| 1.Chemical requirements | |||||||||||
| Grade | N(≤) | C(≤) | H(≤) | Fe(≤) | O(≤) | Al(≤) | V(≤) | Pd(≤) | Mo(≤) | Ni(≤) | Ti |
| GR1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
| GR2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
| GR3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
| GR4 | 0.05 | 0.08 | 0.015 | 0.2 | 0.4 | / | / | / | / | / | bal |
| GR5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| GR7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| GR9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
| GR12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
| GR23 | 0.05 | 0.08 | 0.012 | 0.25 | 0.13 | 5.5~6.5 | 3.5~4.5 | bal | |||
| 2.Tensile requirements | |||||
| Grade | Tensil strength(≥) | Yeild strength(≥)) | Elongation(≥)%) | ||
| ksi | Mpa | ksi | Mpa | ||
| GR1 | 35 | 240 | 20 | 138 | 24 |
| GR2 | 50 | 345 | 40 | 275 | 20 |
| GR3 | 65 | 450 | 55 | 380 | 18 |
| GR4 | 80 | 550 | 70 | 483 | 15 |
| GR5 | 130 | 895 | 120 | 828 | 10 |
| GR7 | 50 | 345 | 40 | 275 | 20 |
| GR9 | 90 | 620 | 70 | 483 | 15 |
| GR12 | 70 | 483 | 20 | 345 | 18 |
| GR23 | 120 | 828 | 110 | 760 | 10 |
Surface finish:
| Surface Finish | Defination | Application |
| 2B | Those finished,after cold rolling,by heat treatment,picking or other equivialent treatment and lastly by cold rolling to given appropriate luster | Medical equipment,Food industry, Construction material,Kitchen utensils |
| BA | Those processed with bright heat treatment after cold rolling | Kitchen utensils,Electric equipment, Building construction |
| No.1 | The surface finished by heat treatment and picking or processes corresponding there to after hot rolling | Chemical tank,pipe |
| No.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R 6001 | Kitchen utensils,Building construction, Medical equipment |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size | Building construction |
| 8K | A mirror-like reflective surface by polishing with finer abrasives over 800 mesh | Reflector,Mirror,Interior-Exterior decoration |
Stainless steel does not stain, corrode, or rust as easily as regular carbon steel and provides high strength and impact resistance along with the aesthetic appeal. The material also has anti-bacterial qualities and is easy to clean and sanitize.
Stainless steel sheet and stainless steel plate are both a perfect solution for applications that require a durable metal with anti-oxidation qualities.
Name | Stainless steel plate/sheet |
Grade | 310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L,302, 301, 201, 202, 403, 405, 409, 409L, 410, 410S, 420, 430, 631, 904L, Duplex, 2205,2507,etc. |
Standard | JIS, AISI, ASTM, DIN, TUV,BV,SUS,EN,etc |
Thickness | 0.1-300mm thickness |
Surface | 2B, 2D, BA, NO. 1, NO. 4, NO. 8, 8K, mirror,checkered,embossed,hair line, sand blast, Brush, etching, etc |
Technique | Hot Rolled And Cold Rolled |
Color | Golden, Black , Sapphire Blue, Brown, Rose gold, Bronze, Purple, gray, silver, Champagne, violet, blue diamond, etc |
Application | Interior/exterior/architectural/bathroom decoration, elevator decoration, hotel decoration, kitchen equipment, ceiling |
Lead time | 7 to 25 working days after the receipt of 30% deposit |
Application | Machine shells, cans, pressure vessels, automotive precision parts, boilers, energy (nuclear power, thermal power, fuel cells), industrial furnaces, incinerators, heating furnaces, chemicals, petrochemicals, washing machine drums, interior panels, kitchen facilities, refrigerators, Dishwasher, pot, pot, microwave oven, display counter, water tank, hot water system equipment (solar, electric water heater), heat exchanger, automobile exhaust system, |
Stainless steel sheet specifications
Standard Size:
1219 x 2438 mm (4 ft x 8 ft)
1219 x 3048 mm (4 ft x 10 ft)
1000 x 2000 mm
1250X2500mm
1500X3000mm
Base Metals:
Stainless steel 304, 304L, 316, 316L, 310S, 430, 201, etc.
Support customization, material complete, 2b surface above can be customized, free samples can be provided.
Packing&Shipping
Packing | Water-proof paper + Edge Protection + Wooden Pallets |
Production Time | 30-45 days depending on processing requirement & production season |
Payment Term | T/T, Irrevocable L/C at sight |
