Insulated Aluminum Wire AWG 6-32 Coil Winding Enameled Electrical Wires Manufacturing Price IEC60317 Afghanistan
500 - 4999 Kilograms
≥5000 Kilograms
You May Like
-
IEC60317 Standard AWG SWG High Temperature Aluminum Winding Wire Insulated Electrical Wires for Transformer and Motors Afghanistan
-
High Temperature Insulated Aluminum Wire AWG SWG Enameled Aluminum Coil Winding Wire for Ceiling Fan Electrical Wire Prices Afghanistan
-
Aluminum Wire Coil Winding Enameled Aluminium Magnet Wire AWG4-32 With ISO9001 UL Certification Round Wire
-
Electrical Wires Aluminium Enameled Winding for Motor and Transformer AWG 6-32 With ISO9001 Certification Afghanistan
-
High Temperature Electrical Wires Aluminium Winding Insulated Wire for Ceiling Fan Motor and Transformer IEC60317 Standard Afghanistan
-
QZYB-180 IEC-60317 Standard Insulated Aluminium Wire Enameled Winding for Motor and Transformer AWG SWG ISO9001 Certification
Product Details
| Type | Insulated | |||
| Conductor Material | Aluminum | Conductor Type | Solid | |
| Model Number | EIW-180 | Brand Name | YONGDONG | |
| Place of Origin | Shandong, China(Mainland) | Diameter: | AWG/SWG | |
| Style: | Enameled Aluminum Wire | Shape: | Round | |
| Heat-resisting class: | H class | Insulation Material: | polyester-imide, Polyamide imide | |
| Production Range: | 0.20mm-5.00mm | Certification: | ROHS REACH ISO9001 | |
| Bobbin: | PT25 PT30 PT60 PT200 PT270 | Standard | IEC NEMA GB JIS | |
| Conductor | Aluminum |
Product Description
Round Wire Diameter: 0.6mm-5.00mm (4awg-32awg) Magnetic wire swg





Product Name | QZ(G)-155 | QZ-180 | Q(ZY/XY)-200 | Q(ZY/XY)-220 |
Thermal Class | 155, class F | 180, class H | 200, class C | 220, class N |
Coating Material | PEW(G) | EIW | EI/AIW | EI/AIW |
Cross Section Range (mm) | 0.60-5.00 | 0.60-5.00 | 0.60-5.00 | 0.60-5.00 |
Insulation Thickness (IEC) | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 |
Standard | GB/T6109.2 GB/T23312.4 IEC60317-3 | GB/T6109.5 GB/T23312.5 IEC60317-8 NW30 | GB/T6109.20 GB/T23312.7 IEC60317-13 NW35 | GB/T6109.22 IEC60317-46 NW16 |
