Dual-Control Bamboo Winch With Manual and Remote Operation for Efficient Bamboo Harvesting
≥1 Acres
- 1
- T/T L/C Money Gram PayPal D/P Western Union Other
- 2 days
You May Like
-
Industrial Bamboo Winch With 12mm Wire Diameter and Safety Emergency Stop Features
-
Dual-Speed Bamboo Winch With Manual Gear Lever and Throttle Control for Variable Terrain
-
Multi-Function Bridge Tractor Featuring Track Transmission System for Stable Fiber Optic Cable Installation
-
High-Efficiency Bamboo Winch Reduces Labor Costs by 300% in Non-Electrified Mountain Forests
-
Ceramic Ink Printing On Glass Inorganic Glass Paint Enamel Pigments High Coverage For Range Hood Glass
-
Home Use Beer Brewing Equipment Kit for Craft Beer Enthusiasts and Beginners
Product Details
| Core Function | Bamboo centralization in mountainous terrain | Power Source | Water-Cooled Diesel Engine | |
| Rated Tractive Force | 30KN | Dimensions | 2020x1570x1170mm | |
| Control System | Panel + Remote dual control | Wire Rope Diameter | 12mm | |
| Operation Modes | Traction/Reeling dual function | Safety Mechanism | Mechanical emergency stop | |
| Weight | 1155kg (± tolerance) |
Product Description
Transform bamboo harvesting operations with the Dual-Control Bamboo Winch engineered for rugged, non-electrified forestry environments. This diesel-powered system centralizes bamboo transport across complex terrains, delivering a 300% efficiency increase versus manual handling while reducing labor costs and physical strain.
Key innovations include:
- Dual-operation technology eliminating separate reeling equipment
- Mutually redundant controls with mechanical emergency shutdown
- Adaptive speed modulation via gear lever and throttle acceleration
Technical specifications:
| Parameter | Value |
| Rated Power | 42KW |
| Max Tractive Force | 54KN |
| Drum Capacity | 7-wire rope wraps (Ø12mm) |
| Gear System | Multi-speed manual transmission |
Operational advantages for forestry teams:
- Remote control enables operation at 300m+ distances
- Dual-speed modulation adapts to variable load requirements
- Spring-pin locked drum prevents accidental disengagement
Maintenance protocols ensure longevity:
- Clutch friction plate inspection every 6 months
- Gear oil replacement after 12 months operation
- External linkage lubrication every 200 operational hours
Designed specifically for Southeast Asian bamboo forests where grid power is unavailable, this winch system creates centralized collection points - reducing secondary transport costs by up to 40% based on field tests in Yunnan province.
Frequently Asked Questions:
Q: What safety features prevent operator injury during rewinding?
A: Mechanical drum locking via shear pins + automatic shutdown when foreign objects approach rotating parts (ISO 13857 compliance).
Q: Can this winch handle steep inclines above 45 degrees?
A: Maximum tested incline is 50° with reduced load capacity (consult engineering specs).
Q: Is training provided for maintenance procedures?
A: Digital operation manuals and video tutorials are available upon shipment.
Q: What's the remote control's effective range?
A: 300m line-of-sight in open terrain (reduced in dense forestry).
Q: Are replacement parts available internationally?
A: Yes - clutch assemblies and gear components ship globally from Shandong warehouse.
Optimize your bamboo supply chain with this heavy-duty winch system - contact our engineering team for terrain-specific configuration consulting and volume discount pricing.
