Schneider Air Duct CO2 Sensor 5152300000 Vista-Specific SCD110
≥1 Units
- T/T
You May Like
Product Description
The SCD110 (part number 5152300000) is a duct-mounted CO₂ transmitter designed for use with the VISTA system.
It features non-dispersive infrared (NDIR) sensing technology for CO₂ measurement, an integrated temperature sensor (1.8 kΩ thermistor) and optionally a humidity sensor, depending on the variant.
The output is field-selectable among 0-5 V, 0-10 V or 4-20 mA, enabling flexible interfacing with building management systems (BMS).
It also incorporates the ABC (Automatic Baseline Calibration) algorithm, allowing for automatic drift compensation over long intervals.
Typical CO₂ measurement range is 0-2000 ppm with accuracy of ±2 % of the measured value (or ±1.5 % of full range) under typical conditions.
The device accepts either 24 VAC (±20 %) or 20-36 VDC power supply.
The housing is designed for mounting in air ducts; the airflow direction must be aligned with the probe installation.
