Multi-Application Inconel 625 Nickel-Based Alloy Bar for Chemical Processing and Industrial Machinery
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Nickel based wear-resistant alloy
Shape:
Bar
Color:
Silver
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Premium Nickel GH4145 N08020 Based Alloy Plate for Oil and Gas Industry Equipment and ComponentsNegotiableMOQ: 1 Ton -
Precision-Cut Inconel800 800H 825 Nickel Based Alloy Plate Compatible With Chemical Processing StandardsNegotiableMOQ: 1 Ton
-
Corrosion-Resistant Nickel Based Alloy Plate Inconel800 800H 825 With Superior Heat Tolerance and DurabilityNegotiableMOQ: 1 Ton
-
High-Performance GH4145 N08020 Nickel Based Alloy Plate Ideal for Aerospace and Defense ApplicationsNegotiableMOQ: 1 Ton
-
GH3128 Nickel Based Alloy Plate in Various Sizes and Thicknesses for Custom Industrial FabricationNegotiableMOQ: 1 Ton
Type
Nickel based wear-resistant alloy
Shape
Bar
Color
Silver
Product Overview
The Multi - Application Inconel 625 Nickel - Based Alloy Bar is a high - performance product designed to meet the demanding requirements of chemical processing and industrial machinery. This alloy bar is crafted from Inconel 625, a nickel - chromium - molybdenum - niobium alloy known for its exceptional corrosion resistance, high - strength properties, and excellent fabricability.
Chemical Composition
- Nickel (Ni): The base element of Inconel 625, nickel provides a stable matrix and contributes to the alloy's overall corrosion resistance. It typically constitutes around 58% or more of the alloy, ensuring the material's ability to withstand harsh chemical environments.
- Chromium (Cr): With a content of approximately 20 - 23%, chromium forms a passive oxide layer on the surface of the alloy bar. This layer acts as a protective barrier against oxidation, preventing the material from corroding in oxidizing environments such as those found in chemical processing plants.
- Molybdenum (Mo) and Niobium (Nb): Molybdenum, present at about 8 - 10%, and niobium, around 3.15 - 4.15%, enhance the alloy's strength and corrosion resistance, especially in reducing acids and chloride - containing environments. These elements also contribute to the alloy's resistance to pitting and crevice corrosion.
Physical and Mechanical Properties
- Density: The density of Inconel 625 alloy bar is approximately 8.44 g/cm³, which provides a good balance between strength and weight. This makes it suitable for applications where weight is a concern, such as in aerospace and some industrial machinery components.
- Melting Point: It has a melting point in the range of 1290 - 1350°C. This high melting point allows the alloy bar to maintain its structural integrity in high - temperature applications, such as in heat exchangers and furnaces.
- Tensile Strength: The alloy bar exhibits excellent tensile strength, with a typical ultimate tensile strength of around 827 MPa. This high strength enables it to withstand heavy loads and stresses in industrial machinery and chemical processing equipment.
- Yield Strength: The yield strength of Inconel 625 is approximately 414 MPa, ensuring that the material can deform elastically under normal operating conditions without permanent damage.
Applications
- Chemical Processing: In the chemical industry, this alloy bar is widely used in the construction of reaction vessels, pipes, and valves. Its outstanding corrosion resistance makes it suitable for handling a variety of corrosive chemicals, including acids, alkalis, and salts. For example, it can be used in the production of fertilizers, where it is exposed to highly corrosive substances such as sulfuric acid and ammonia.
- Industrial Machinery: In industrial machinery, the Inconel 625 alloy bar is used in components such as shafts, gears, and fasteners. Its high strength and wear resistance ensure long - term reliability and performance in high - stress applications. For instance, in heavy - duty manufacturing equipment, the alloy bar can withstand the continuous friction and mechanical stress, reducing the need for frequent replacements.
- Marine Applications: Due to its excellent resistance to seawater corrosion, the alloy bar is also used in marine engineering. It can be found in components of offshore platforms, shipbuilding, and desalination plants, where it is exposed to the harsh marine environment.
Manufacturing and Quality Assurance
The Inconel 625 alloy bars are manufactured using advanced production techniques to ensure consistent quality and performance. The production process includes melting, casting, forging, and heat treatment. Each step is carefully monitored to meet the strictest quality standards. The company holds the ISO9001 production certification, which means that every aspect of the manufacturing process, from raw material sourcing to final product inspection, is subject to rigorous quality control. This ensures that the alloy bars meet or exceed customer expectations in terms of dimensional accuracy, chemical composition, and mechanical properties.
Company Support and Service
- Product Information and Sample Supply: Our company provides customers with detailed product information, including specifications, features, and uses. We also offer samples for customers to evaluate and confirm the suitability of the alloy bar for their specific applications.
- Price and Negotiation: We provide a quotation based on customer needs, including price, delivery terms, and payment methods. We are open to price negotiation to reach a mutually satisfactory agreement.
- Order Processing: We accept customer orders and process them with the highest level of accuracy. We confirm order details such as quantity, model, and delivery time to ensure a smooth order - fulfillment process.
- Production Follow - up and Quality Control: We closely follow up on the production progress to ensure timely delivery. Our quality control team conducts comprehensive inspections at every stage of production to ensure that the product meets customer requirements and standards.
- Logistics Arrangement: We arrange transportation and logistics, including shipping, transportation mode selection (sea freight, air freight, etc.), and customs clearance procedures. We track the transportation of goods to ensure they arrive smoothly at the customer's designated location.
- After - Sale Service: Our customer service team is dedicated to handling customer complaints and issues. We strive to ensure customer satisfaction and provide continuous support after the sale.
In conclusion, the Multi - Application Inconel 625 Nickel - Based Alloy Bar is a reliable and high - performance product that offers a wide range of benefits for chemical processing and industrial machinery applications. With our company's strong support and service, customers can have full confidence in choosing our alloy bars for their projects.
