Premium Customized Nickel Alloy Magnetic Soft Plates for Industrial Applications
Negotiable
MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Nickel Plate
Purity:
>98%
Application:
Aviation, Electronics, Industrial, Medical, Chemical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days
Related Products
-
Incoloy 020 (UNS N08020) Sheet/Plate Excellent Corrosion Resistance Nickel Alloy 825, Inconel 600, Hastelloy C276 ASTM B409/B168 CertifiedNegotiableMOQ: 1 Kilogram -
Age-Hardening Nickel Alloy Udimet 720 720li Gh4720li U720 U720li Nickel Alloy Plate Strip SheetNegotiableMOQ: 1 Kilogram
-
Nickel Alloy Sheet N4 Huge Plates High Purity Nickel201 Pure Nickel PlateNegotiableMOQ: 1 Kilogram
-
Inconel 725 (UNS N07725) Sheet/Plate Hastelloy C276/400, Incoloy 800/825, Monel 400 Nickel Alloy Supplier ASTM B168/B409 CertifiedNegotiableMOQ: 1 Kilogram
-
Durable N06625 Nickel Alloy Plate for Extreme EnvironmentsNegotiableMOQ: 1 Kilogram
Type
Nickel Plate
Purity
>98%
Application
Aviation, Electronics, Industrial, Medical, Chemical
Standard
JIS, GB, DIN, BS, ASTM, AISI
Powder
Not Powder
Alloy
Non-alloy
Product Description
Specification
| Product Name | Nickel Alloy Product | |
| Product Form | Plate,Sheet,Pipe,Tube,Coil,Strip,Bar,Rod,Pipe Fitting,Casting,Forging,Welding Material,Wire | |
| Standard | ASTM,JIS, AISI, GB, DIN, EN | |
| Size Range | Pipe/Tube | Outer Diameter: 6-2500mm, (3/8"-100") |
| Thickness: 0.3-150mm,(SCH10-XXS) | ||
| Length: 2000mm, 2500mm, 3000mm, 5800mm, 6000mm,12000mm,etc | ||
| Plate/Sheet | Thickness: 0.2mm-300mm or as required Length: 2000mm-6000mm or as required |
|
| Strip | 0.05*5.0-5.0*250mm | |
| Bar/Rod | Outer diameter: 5mm-500mm or as required Length: 2000mm-120000mm or as required |
|
| For customization product such as pipe fitting, casting, forging, welding material, wire, etc., HYT provides one-stop customization service to meet your specific re quirements. | ||
| Technique | Hot Rolled/Cold Rolled/Cold Drawn/Forging/Casting/Welding | |
| Inspection | ISO,SGS,BV and so on. | |
| Delivery | 7-25 days or according to the product | |
| MOQ | 100Kg | |
| Nickel alloy material choice | ||
| Nickel Alloy | DIN/EN | UNS | Chemical Composition |
| Hastelloy C276 | 2.4819 | N10276 | 57Ni-15.5Cr-16Mo-4.5Fe-0.5W-3.8Co-0.01C-0.08Si-0.3Mn-0.35V |
| Hastelloy C22 | 2.4602 | N06022 | 56Ni-22Cr-13Mo-3Fe-2.5Co-0.02C-0.5Mn-0.08Si-0.35V |
| Hastelloy X | 2.4665 | N06002 | 47Ni-22Cr-18Fe-9Mo-1.5Co-0.1C-1Mn-0.6Si |
| Hastelloy C4 | 2.461 | N06455 | 65Ni-16Cr-16Mo-3Fe-0.7Mn-0.08Si-0.01C |
| Hastelloy B | 2.481 | N10001 | 61Ni-28Mo-5Fe-1.5Mn-0.2Si-0.02C |
| Hastelloy B3 | 2.46 | N10675 | 65Ni-28.5Mo-1.5Fe-3Co-0.01C-0.1Mn-0.2Si |
| Hastelloy B2 | 2.4617 | N10665 | 69Ni-28Mo-2Fe-1Mn-0.1Si-0.02C |
| Hastelloy C2000 | 2.4675 | N06200 | 59Ni-23Cr-16Mo-1.6Cu-3Fe-0.01C-0.08Si-0.5Mn |
| Hastelloy G30 | 2.4603 | N06030 | 43Ni-30Cr-15Fe-5.5Mo-2.5W-1Mn-1Cu-0.03C-0.8Si |
| Inconel 718 | 2.4668 | N07718 | 52.5Ni-19Cr-3Mo-5.1Nb-0.9Ti-0.5Al-18Fe-0.08C-0.35Mn-0.35Si |
| Inconel 625 | 2.4856 | N06625 | 58Ni-20Cr-9Mo-3.65Nb-5Fe-0.1C-0.5Mn-0.5Si-0.4Al |
| Inconel 600 | 2.4816 | N06600 | 72Ni-15.5Cr-8Fe-0.1C-0.5Mn-0.5Si |
| Inconel X-750 | 2.4669 | N07750 | 70Ni-15Cr-2.5Ti-0.7Al-7Fe-0.08C-1Mn-0.5Si |
| Inconel 601 | 2.4851 | N06601 | 61Ni-22Cr-1.4Al-14Fe-0.1C-0.5Mn-0.5Si |
| Inconel 617 | 2.4663 | N06617 | 52.5Ni-22Cr-13Co-9Mo-1.2Al-0.15Ti-0.1C-0.5Mn-0.5Si |
| Inconel 690 | 2.4642 | N06690 | 58Ni-30Cr-9Fe-0.02C-0.5Mn-0.5Si |
| Monel 400 | 2.436 | N04400 | 63Ni-28Cu-2Fe-0.3Mn-0.2Si-0.024C |
| Monel K500 | 2.4375 | N05500 | 63Ni-27Cu-0.85Al-2.5Fe-1.5Mn-0.55Ti-0.18Si-0.025C |
| Incoloy 800 | 1.4876 | N08800 | 32Ni-21Cr-46Fe-0.1C-1.5Mn-1Si-0.3Al-0.3Ti |
| Incoloy 825 | 2.4858 | N08825 | 42Ni-21.5Cr-3Mo-2.2Cu-0.9Ti-30Fe-0.05C-1Mn-0.5Si |
| Incoloy 800H | 1.4958 | N08810 | 32Ni-21Cr-46Fe-0.05-0.1C-1.5Mn-1Si-0.4Al-0.4Ti |
| Incoloy 800HT | 1.4959 | N08811 | 32Ni-21Cr-46Fe-0.06-0.1C-1.5Mn-1Si-0.85Al-0.4Ti |
Pipes & Tubes: Ensuring safe and effective transfer of fluids and gases.
Strips: Versatile for various sealing and decorative applications.
Bars & Rods: Durable and suitable for various construction needs.
Welding Materials: High-quality welding results that enhance structural stability and durability.
Wire: Widely used in electronics and fine mechanical processes.
Casting & Forging: Custom components with high strength and complex shapes.
Pipe Fittings: Ensuring ease of installation and seal integrity.
