Introduction to Tailored Electroplating Jig Coating
Our PVC Plastisol Coating Liquid for electroplating jigs combines anti-high temperature performance with full customization, making it ideal for facilities seeking both functionality and brand alignment. Available in a range of colors (e.g., black, blue, red) and finishes (matte, glossy), it allows you to color-code jigs by workpiece type or plating process—simplifying inventory management. Additionally, it meets global environmental standards such as RoHS and REACH, containing no heavy metals (lead, cadmium) or harmful plasticizers. This coating not only protects jigs from heat and chemicals but also enhances workplace efficiency through intuitive color-coding.
Key Benefits: Customization & Compliance
1. Full Color & Finish Customization: Match your brand colors or use color-coding to distinguish jigs for different plating tasks (e.g., nickel plating vs. chrome plating).
2. Eco-Friendly Compliance: RoHS/REACH-certified, ensuring compliance with environmental regulations in Europe, North America, and Asia.
3. Heat Stability Under Stress: Maintains performance even during prolonged exposure to 220°C, suitable for high-temperature electroplating processes like hard chrome plating.
Technical Details (Table Format)
Parameter |
Specification |
Benefit |
Color Options |
Black, Blue, Red, Custom (Pantone-matched) |
Color-coding for efficient jig management |
Finish Types |
Matte, Glossy |
Customizable appearance |
Regulatory Compliance |
RoHS, REACH |
Meets global environmental standards |
Heat Resistance |
220°C (continuous use), 250°C (short-term) |
Suitable for high-temperature plating |
Elongation at Break |
>180% |
Flexible, resists cracking when jigs bend |
Shelf Life (Unopened) |
12 months (25°C) |
Reduces material waste |
Coverage |
10–12 m²/L (at 100 μm thickness) |
Cost-effective for large jig batches |
Chemical Compatibility |
Resists plating salts, degreasers |
No degradation in harsh electroplating environments |
Efficiency-Boosting Features for Plating Operations
• Color-Coding Convenience: Different colored coatings let workers quickly identify jigs for specific parts or processes, reducing setup time.
• Low Maintenance: The smooth coating surface is easy to clean—simply wipe off excess plating solution with a cloth, no harsh scrubbing needed.
• Consistent Application: Stable viscosity ensures uniform coating thickness across all jigs, avoiding uneven protection or plating defects.
Application & Storage Tips
1. Color Matching: Provide a Pantone code or sample for custom colors; allow 3–5 business days for color formulation.
2. Coating Thickness: For heavy-duty use (frequent part loading), apply 100–120 μm; for light use, 80–90 μm is sufficient.
3. Storage: Keep unopened containers in a cool, dry area (15–25°C); avoid direct sunlight to preserve color and viscosity.
Cleanup: Use PVC-compatible solvent to clean application tools (brushes, spray guns) immediately after use.
