F-1300/1600 Oil drilling mud pump parts
Name of the product Old model New model
F1300/F1600 F-1300/F1600
Frame Assembly  AH36002-01.00         AH1301020100
Crankshaft Assembly AH36002-02.00 AH1301020200
AH37002-01.00 AH1601020100
Pinion Shaft Assembly AH36002-03.00 AH1301020300
AH37002-02.00 AH1601020200
Crosshead Assembly AH36002-04.00 AH1301020400
Fluid End Assembly AH36002-05.00 AH1301020500
Power End Lubrication Assembly AH36002-06A.00    AH1301020600
Base Seat AH36002-07.00 AH1301020700
 Spray Pump Assembly AH36002-08.00 AH1301020800
BS Name Plate AH13010209  AH13010209
AH37002-03B AH16010203
Attachment tools AH36002-10.00 AH1301021000
Attachment spare parts AH36002-11.00 AH1301021100
Discharge filter assembly AH34004-18.00 AH1001021100
Sealing  washer AH33001-09   AH10010109
Breather Cap T515-1001.00   T515-1001.00
Crane AH36001-10.00    AH1301011000
Crane AH36001-11A.00     AH1301011100
Cover Plate AH36001-12.00   AH1301011200
Gasket AH36001-13 AH13010113
Indication board AH33001-17B AH10010113
AH33001-17A AH10010210
Oil Level Indicator AH33001-18.00   AH1001011400
Clean Out Cover(III) AH33001-22.00 AH1001011500



Name of the product Old model Model
F1300/F1600 F-1300/F1600
Gasket AH36001-19      AH10010116
Crosshead Door AH36001-15A AH13010114
AH37001-04  AH16010104
Gasket AH36001-16 AH13010115
Transition joint T512-1002 T512-1002
Elbow Pipe AH33001-30 AH10010212
Ring Gasket R44 T58-5002 T508-5002
Flange T58-1002 T508-1002
KB-75 Pulsation Dampener AH33010-00 AK75350200
JA-3 Shear Relief Valve AH33007-00   AH0000060200
Adapter NPT3 T510-1002 T510-1002
Cover Plate Assembly AH36001-21B.00 AH1301011800
Quarter Bend NPT3 T511-1002 T511-1002
Bolt 1/2-13UNCX1 T50-1001 T500-1001
Bolt 1/2-13UNCX1 1/2 T50-1017 T500-1017
Bolt 5/8-11UNCX1 5/8 T50-1010 T500-1010
Bolt 1-8UNCX3 1/4 T50-1013 T500-1013
Nut 1-8UNC-2B T51-1003 T501-1003
Bolt 5/8-11UNCX1 3/4 T50-1008 T500-1008
Nut 5/8-11UNC-2B T51-1002 T501-1002
Sign with the nail  3X10 420999050603001000  420999050603001000
Spring Washer  27  420503011271600000  420503011271600000
Washer 12       420501036120200000  420501036120200000
Washer  16      420501036160200000  420501036160200000
Spring Washer 16  420503010161600000  420503010161600000



Name of the product Old model Model
F1300/F1600 F-1300/F1600
Cross Recess Head ScrewM4X16  420101050704001000  420101050704001000
Rubber Strip40X10X5800 140601061000000000  140601061000000000
double scale pressure gauge 60MPa 380207192602511000  380207192602511000
Thread lock solid anaerobic glue 170506010100243000  170506010100243000
Adjusting shim AH36001-23       AH13010119
Flat Gasket 27 420501060270100000  420501060270100000



F-1300/1600 Crank Shaft Assemble
Name of the product Old model Model
F1300/F1600 F-1300/F1600
Main bearing end cover AH36001-02.01C.00 AH130101020100
Main bearing set (right) AH36002-02.01 AH1301020201
AH37002-01.01 AH1601020101
sealing washer AH36001-02.03   AH1301010203
Inner locking ring AH36001-02.04     AH1301010204
Outer race retainer AH36001-02.05 AH130101020500
AH37001-01.03 AH160101010200
Connection rod AH36002-02.02 AH1301020202
AH37002-01.02 AH1601020102
locating ring(I) AH36002-02.03 AH1301020203






Hollow crank shaft AH36002-02.04A.00   AH130102020400
locating ring(II) AH36002-02.05     AH1301020205
Big gear ring AH36001-02.10D.00 AH130101021000
AH37001-01.05D.00 AH160101010400



Name of the product Old model Model
F1300/F1600 F-1300/F1600
spacer AH36001-02.12       AH1301010211
Main bearing set (left) AH36002-02.06 AH1301020206
 AH37002-01.03 AH1601020103
Retainer ring AH36001-02.14  AH1301010213
AH37001-01.07 AH1601010106
Bolt 5/8-11UNCX1 1/2 T50-1018K T500-1018K
Retainer AH36001-02.15    AH1301010214
Bolt  5/8-11UNCX1 3/4 T50-1008 T500-1008
Main bearing bolt AH36001-02.16C   AH1301010215
Shim set AH36001-02.17 AH130101021600
Bolt 5/8-11UNCX4 T50-3004K T500-3004K
Eccentric Bearing AH36001-02.19.00 AH1301010217
 AH37001-01.08.00  AH1601010107
Main Bearing AH36001-02.20.00 AH1301010218
AH37001-01.09.00  AH1601010108
Washer 16   420501036160200000  420501036160200000
Bolt 5/8-11UNCX4 3/4 T50-3006K T500-3006K
Lock Wire Φ1.5  40101010150600000  40101010150600000
Lock Wire Φ3   40101010300600000  40101010300600000
Loctite  243 170506010100243000  170506010100243000
Big gear ring (piece together) AH36001-02.10B.00 AH130101021900
AH37001-01.05B.00 AH160101010900
Bolt 1 1/2-8UNX7 T50-2033 T500-2033



F-1300/1600 Pinion Shaft Assembly
Name of the product Old model Model
F1300/F1600 F-1300/F1600
Key    2″×2″×11 3/8″ AH36002-03.01   AH1301020301
Pinion Shaft AH36002-03.02 AH1301020302
 AH37002-02.01 AH1601020201
Oil Seal Wear Ring  AH36001-03.03   AH1301010303
End Cover AH36002-03.03B   AH1301020303
Gasket AH36001-03.05   AH1301010305
Gasket AH36001-03.06     AH1301010306
Bearing Sleeve AH36001-03.07B AH1301010307
Race Retainer AH36002-03.05B AH1301020305
seal washer AH36001-03.12B   AH1301010309
Oil Gathering Box AH36001-03.13B.00   AH130101031000
Bolt 1/2-13UNCX1 3/8 T50-1019 T500-1019
Bolt 7/8-9UNCX2 T50-1027 T500-1027
Oil Seal 9.125"X10.375"X0.625" AH36001-03.08A   AH1301010311
Bearing 4G32844H AH36001-03.09      AH1301010312
Washer 22   420503011221600000  420503011221600000
Washer 14 420503011141600000  420503011141600000
Flange AH36001-03.11 AH1301010313
Bolt 5/8-11UNCX1 3/4 T50-2003 T500-2003
Spring Washer 420503011161600000  420503011161600000



F-1300/1600 Crossing Head Assemble
Name of the product Old model Model
F1300/F1600 F-1300/F1600
Crosshead AH36002-04.01 AH1301020401
Upper slide AH36001-04.02 AH1301010402
Gasket unit AH36001-04.03A.00   AH100101041700
Adjusting pad AH36001-04.04 AH1301010403
Packing box AH36001-04.05 AH1301010404
Oil seal ring AH36001-04.21 AH1301010405
O-ring φ190×3.55  530301011900035000  530301011900035000
Two-lip seal 5"X6.25"X0.625" AH36001-04.08A AH1301010406
Locking spring AH36001-04.13 AH1301010407
Splash guard AH36001-04.10 AH1301010408
Extension rod AH36001-04.11 AH1301010409
Crosshead pin AH36002-04.03 AH1301020403
O-ring φ125×7    530301011250070000  530301011250070000
Bolt 3/4-10UNCX2 1/2 T50-3010 T500-3010
Sealing gasket AH36001-04.15   AH1301010411
O-ring φ160×7    530301011600070000  530301011600070000
Lower slide AH36001-04.17 AH1301010412
Crosshead pin guide AH36002-04.04   AH1301020404
Cross head bearing AH36001-04.19    AH1301010414
Pipe joint NPT3/8″×2 AH33001-04.07 AH1001010405
Bolt 1-8UNCX2 1/4 T50-2018K     T500-2018K
Bolt 1-8UNCX2 1/2 T50-2019K T500-2019K
Locking plate AH36002-04.02   AH1301020402
Bolt 3/8-16UNCX1 T50-1021 T500-1021
Screw 1-8UNCX2 1/2 T50-3013K T500-3013K
Spring washer 10 420503011101600000  420503011101600000
Zinc-coated wire  φ1.6     40104030160000800  40104030160000800
Loctite 170506010100243000  170506010100243000



F-1300/1600 Hydraulic End Assemble
Name of the product Old model Model
F1300/F1600 F-1300/F1600
Hydraulic cylinder assembly AH36002-05.01.00 AH130102050100
Cylinder head flange AH36001-05.02    AH1301010502
Cylinder head AH36001-05.03 AH1301010503
Plug board assembly AH36001-05A.04.00   AH130101050400
Valve rod guides(lower) AH36001-05A.05.00 AH130101050500
Cylinder head plug AH36001-05A.06.00   AH130101050600
Positioning plate AH36001-05A.07   AH1301010507
Cylinder head gasket AH36001-05.08   AH1301010508
Discharge manifold AH36001-05.09   AH1301010509
Valve spring AH33001-05.16A AH00000101
O-ring φ95×5.3   530301010950053000  530301010950053000
Valve assembly API 7 through-hole AH36001-05.12A.00 AH0000020300
Valve cover sealing ring AH36001-05.13 AH1301010510
Valve cover AH36002-05.02 AH1301020502
Cylinder liner seal AH36001-05.15   AH1301010512
Wearing plate AH36002-05.03 AH1301020503
Cylinder liner flange AH36001-05.17 AH1301010514
Cylinder liner gland AH36001-05.18.00 AH130101051500
Piston rod AH36002-05.05 AH1301020504
Adapter NPT3/8  AH36002-05.04.00 AH130102050500
O-ring φ200×7    530301012000070000  530301012000070000
Cylinder liner lock ring AH36001-05.22 AH1301010518
Bi-metal cylinder liner  AH130102051200 AH130102051200
Clamp assembly AH36002-05.06.00 AH130102050600
Elbow NPT3/8-M22X1.5 AH36002-05.08     AH1301020507
Cylinder end cover AH36001-05.27 AH1301010520



Name of the product Old model Model
F1300/F1600 F-1300/F1600
British piston AH36002-05.09.00 AH130102050800
Bolt 7/8-9UNCX2 T50-1027 T500-1027
Adapter connector NPT1/2-M22X1.5 AH36002-05.10 AH1301020509
Right-angle connector NPT1-NPT1/2 AH36002-05.11    AH1301020510
Suction manifold AH36002-05.12A.00 AH130102051100
Gasket unit AH36001-05.33A.00 AH130101052300
Backup ring AH36001-05.39 AH1001010527
Valve rod guide (upper) AH33001-05.12 AH1001010510
Double armed bolt 1 1/2-8UNX10 1/2 T50-7002 T500-7002
Nut 1 1/2-8UN T51-2001 T501-2001
Dam-board AH33001-05.14   AH1001010512
Bot 3/8-16UNCX3/4 AH35003-05.04 AH0501020509
O-ring 41.2X3.55  GB3452.1-82   530301010412035000
Piston nut 1 1/2-8UN  T51-3003.0 T501-303.0
O-ring Φ185X7    GB3452.1-82 530301011850070000
Inhalation of the blocking plate T55-1006     T505-1006
O-ring Φ345X7    GB3452.1-82   530301013450070000
Suction flange （I） AH33001-05.39     AH1001010525
Suction flange（II） AH33009-05.03 AH1001020509
Nut 1-8UNC T51-1003 T501-1003
Bolt 1-8UNCX3 1/2 T50-1023 T500-1023
Stainless steel wire   φ1.6×1830 40104030160001900  40104030160001900
Withhold type hose assembly C-13X1W-850 140507011301008000  140507011301008000
Screwed plug NPT 1 1/2 T56-1007    T506-1007
Double armed bolt 1 1/2-8UNX22 1/4 AH36002-05.01.00A AH1301020513
Le Tai glue 243 243  170506010100243000
Bolt 1-8UNCX4 1/4 T50-1024 T500-1024
Hose clip 3        61401030750000000  61401030750000000
Discharge blocking plate T55-1008         T505-1008
Suction air chamber AH33001-05.35A.00   AH0000050100
B.Locking spring C.Valve rubber


Product Tags: AH36002-04.01 , F1300 mud pump , F1600 mud pump

Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Jinan Purite Petroleum Equipment Co., Ltd.
Verified Business License
Contact Supplier Request Quote Chat Now

You May Also Like

Related Searches

Recommended Categories

Explore top categories and find suppliers for your specific needs
Pumping Unit Pumping Unit
Cementing Tool Cementing Tool
Mud Circulating System Mud Circulating System
Oilfield Shale Shaker Oilfield Shale Shaker
Other Petroleum Equipments & Machinery Other Petroleum Equipments & Machinery
