stainless steel coil has a smooth surface, high plasticity, toughness and mechanical strength, and is resistant to corrosion by acids, alkaline gases, solutions and other media. It is an alloy steel that does not rust easily, but not absolutely rust-free. Stainless steel coil refers to a steel coil that is resistant to corrosion by weak media such as atmosphere, steam and water, while acid-resistant steel coil refers to a steel coil that is resistant to corrosion by chemically corrosive media such as acid, alkali, and salt.
Product Name |
Stainless Steel Sheet/Plate/Coil/Strip |
|||
Type |
Coil/Sheet/Strip |
|||
Process Method |
Hot rolled and Cold rolled |
|||
Material |
304, 304L, 304H, 304N, 316, 316L, 316Ti, 317L, 310S, 321, etc. |
|||
Standard |
ASTM AISI DIN JIS GB EN ASTM A240, ASTM A480, EN10088, JIS G4305 |
|||
Specification |
a) Width : 1000mm/1219mm/1500mm or as request
b) Thickness: (Cold rolled) 0.3~3.0mm; (Hot rolled) 3.0~120mm
c) Length: 2000mm/2438mm/2440mm
|
|||
Tolerance |
a) Width:+/-0.5mm : +/-0.2mm b) Thickness : +/-0.1mm or as required c) Length: Length:+/-1.0mm |
|||
Surface Treatment |
Annealing pickling + Surface polishing + Tempered rolling |
|||
Surface Finish |
No.1 No.3 No.4 HL 2B BA 4K 8K 1D 2D |
|||
End/Edge |
Plain End / Bevel edge End |
|||
Application |
Widely used in petroleum, chemical, medical, food, light industry, mechanical instrument and other industrial pipeline and mechanical structure parts,etc. |
|||
Packing |
Standard Export Packing/Waterproof paper+Wooden pallet or As required |
|||
Payment terms |
30%T/T Advance + 70% Balance T/T before shipping |
|||
Precipitation hardening stainless steel
It has good forming properties and good weldability, and can be used as ultra-high strength materials in the nuclear industry, aviation and aerospace industries.
According to the composition, it can be divided into Cr series (400 series), Cr-Ni series (300 series), Cr-Mn-Ni (200 series), heat-resistant chromium alloy steel (500 series) and precipitation hardening series (600 series).
200 series: chromium-manganese-nickel
201,202, etc.: manganese replaces nickel, corrosion resistance is relatively poor, and it is widely used as a cheap substitute for the 300 series in China
300 series: chromium-nickel austenitic stainless steel
301: good ductility, used for molded products. It can also be hardened quickly by machining. Good weldability. Wear resistance and fatigue strength are better than 304 stainless steel.
302: Corrosion resistance is the same as 304, and the strength is better due to the relatively high carbon content.
303: By adding a small amount of sulfur and phosphorus, it is easier to cut than 304.
304: General model; that is, 18/8 stainless steel. Products such as: corrosion-resistant containers, tableware, furniture, railings, medical equipment. The standard composition is 18% chromium plus 8% nickel. It is a non-magnetic stainless steel whose metallographic structure cannot be changed by heat treatment. The GB grade is 06Cr19Ni10.
304 L: Same characteristics as 304, but low carbon, so it is more corrosion-resistant and easy to heat treat, but the mechanical properties are poor. It is suitable for welding and products that are not easy to heat treat.
304 N: Same characteristics as 304, a nitrogen-containing stainless steel. Nitrogen is added to increase the strength of the steel.
309: Better temperature resistance than 304, up to 980ºC.
309 S: Contains a large amount of chromium and nickel, so it has good heat resistance and oxidation resistance. Products such as: heat exchangers, boiler components, and jet engines.
310: Excellent high-temperature oxidation resistance, with a maximum operating temperature of 1200ºC.
316: After 304, the second most widely used steel grade, mainly used in the food industry, watch accessories, pharmaceutical industry and surgical equipment. Molybdenum is added to give it a special corrosion-resistant structure. Because it has better chloride corrosion resistance than 304, it is also used as "marine steel". SS316 is usually used in nuclear fuel recovery devices. 18/10 grade stainless steel usually meets this application level.
316 L: Low carbon, so it is more corrosion-resistant and easy to heat treat. Products such as: chemical processing equipment, nuclear power generators, and refrigerant storage tanks.
321: Except that the risk of rusting of material welds is reduced by the addition of titanium, other properties are similar to 304.
347: Adding stabilizing element niobium, suitable for welding aircraft equipment parts and chemical equipment.
400 series: ferritic and martensitic stainless steel, manganese-free, can replace 304 stainless steel to a certain extent
408: Good heat resistance, weak corrosion resistance, 11% Cr, 8% Ni.
409: The cheapest model (UK and US), usually used as automobile exhaust pipes, belongs to ferritic stainless steel (chrome steel).
410: Martensite (high-strength chrome steel), good wear resistance, poor corrosion resistance.
416: The addition of sulfur improves the processing performance of the material.
420: "Tool-grade" martensitic steel, similar to Brinell high-chromium steel, the earliest stainless steel. Also used for surgical knives, can be made very bright.
430: Ferritic stainless steel, decorative, such as for car accessories. Good formability, but poor temperature resistance and corrosion resistance.
440: High-strength tool steel, with a slightly higher carbon content, can obtain a higher yield strength after proper heat treatment, and the hardness can reach 58HRC, which is one of the hardest stainless steels. The most common application example is "razor blades". There are three commonly used models: 440A, 440B, 440C, and 440F (easy to process).
500 series: heat-resistant chromium alloy steel.
600 Series: Martensitic precipitation hardening stainless steel
SURFACE |
PROCESSING METHODS |
APPLICATION |
NO.1 |
The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. |
Chemical tank, pipe. |
2B |
Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. |
Medical equipment, Food industry, Construction material, Kitchen utensils. |
BA |
Those processed with bright heat treatment after cold rolling. |
Kitchen utensils, Electric equipment, Building construction. |
8K |
The product is continuously processed with 1000# abrasive thus it is with high gloss and reflection properties. |
Contruction,mirrors,plate sets,decorations,ect. |
NO.4 |
Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction, Medical equipment. |
Product name |
China | |||
| Mode | 201 301 304 304L 316 316L 309S 409 410 430 904L 2205 2507 | |||
| Rd &Material | ASTM A240 Standard | 201, 304 304L 304H 309S 309H 310S 310H 316 316H 316L 316Ti 317 317L 321 321H 347 347H 409 410 410S 430 904L | ||
| ASTM A480 Standard | 302, s30215, s30452, s30615, 308, 309, 309Cb, 310, 310Cb, S32615,S33228, S38100, 304H, 309H, 310H, 316H, 309HCb, 310HCb, 321H,347H, 348H, S31060, N08811, N08020, N08367, N08810, N08904,N08926, S31277, S20161, S30600, S30601, S31254, S31266,S32050, S32654, S32053, S31727, S33228, S34565, S35315,S31200, S31803, S32001, S32550, S31260, S32003, S32101,S32205, S32304, S32506, S32520, S32750, S32760, S32900, S32906, S32950, S32974 | |||
| JIS 4304-2005 Standard | SUS301L,SUS301J1,SUS302,SUS304, SUS304L, SUS316/316L, SUS309S, SUS310S, 3SUS21L, SUS347, SUS410L, SUS430, SUS630 | |||
| JIS G4305 Standard | SUS301, SUS301L, SUS301J1, SUS302B, SUS304, SUS304Cu,SUS304L, SUS304N1, SUS304N2, SUS304LN, SUS304J1, SUSJ2,SUS305, SUS309S, SUS310S, SUS312L, SUS315J1, SUS315J2,SUS316, SUS316L, SUS316N, SUS316LN, SUS316Ti, SUS316J1,SUS316J1L,SUS317, SUS317L, SUS317LN, SUS317J1, SUS317J2,SUS836L, SUS890L, SUS321, SUS347, SUSXM7, SUSXM15J1, SUS329J1, SUS329J3L, SUS329J4L, SUS405, SUS410L, SUS429, SUS430, SUS430LX, SUS430J1L, SUS434, SUS436L, SUS436J1L,SUS444, SUS445J1, SUS445J2, SUS447J1, SUSXM27, SUS403,SUS410, SUS410S, SUS420J1, SUS420J2, SUS440A | |||
| Finish | 2b, BA, No. 4, 8K, hairline, embossed, etched, vibration, PVD color coated, titanium, sand blasted, anti-fingerprint | |||
| Production technology | 1. Round steel preparation; 2. Heat; 3. Hot rolling perforation; 4. Cut the head; 5. Pickling; 6. Grinding; 7. Lubricate; 8. Cold rolling processing; 9. Degreasing; 10. Solution heat treatment; 11. Straightening; 12. Cut the tube; 13. Pickling; 14. Inspection of finished products. | |||
| Typical uses | Seawater equipment, chemicals, dyes, papermaking, oxalic acid, fertilizer and other production equipment; Photography, food industry, coastal facilities, ropes, CD rods, bolts, nuts. | |||
| Thickness | 1. Thin plate (0.2mm-4mm) 2. Middle plate (3mm-30mm) 3. Thick plate (4mm-60mm) 4. Extra thick plate (60-115mm) as customer's requirement | |||
Size |
as customer's requirement | |||
| Density | 7.98 g/cm³ | |||
| 201 Chemical element content (%) | ||||||||
| element | C | Si | Mn | P | S | Cr | Ni | N |
| Min | - | - | 5.5 | - | - | 16 | 3.5 | - |
| Max | 0.15 | 1 | 7.5 | 0.06 | 0.03 | 18 | 5.5 | 0.25 |
| 310 Chemical element content (%) | ||||||||
| element | C | Si | Mn | P | S | Cr | Ni | N |
| Min | - | - | - | - | - | 16 | 6 | - |
| Max | 0.15 | 1 | 2 | 0.045 | 0.03 | 18 | 8 | 0.1 |
| 304 Chemical element content (%) | |||||||
| element | C | Si | Mn | P | S | Cr | Ni |
| Min | - | - | - | - | - | 18 | 8 |
| Max | 0.08 | 1 | 2 | 0.045 | 0.03 | 20 | 11 |
| 304L Chemical element content (%) | |||||||
| element | C | Si | Mn | P | S | Cr | Ni |
| Min | - | - | - | - | - | 18 | 8 |
| Max | 0.03 | 1 | 2 | 0.045 | 0.03 | 20 | 12 |
| 316 Chemical element content (%) | ||||||||
| element | C | Si | Mn | P | S | Cr | Ni | Mo |
| Min | - | - | - | - | - | 16 | 10 | 2 |
| Max | 0.08 | 1 | 2 | 0.045 | 0.03 | 18 | 14 | 3 |
| 316L Chemical element content (%) | ||||||||
| element | C | Si | Mn | P | S | Cr | Ni | Mo |
| Min | - | - | - | - | - | 16 | 10 | 2 |
| Max | 0.03 | 1 | 2 | 0.045 | 0.03 | 18 | 14 | 3 |
| 309S Chemical element content (%) | |||||||
| element | C | Si | Mn | P | S | Cr | Ni |
| Min | - | - | - | - | - | 22 | 12 |
| Max | 0.08 | 1 | 2 | 0.045 | 0.03 | 24 | 15 |
| 430 Chemical element content (%) | ||||||
| element | C | Si | Mn | P | S | Cr |
| Min | - | - | - | - | - | 16 |
| Max | 0.12 | 1 | 1 | 0.04 | 0.03 | 18 |
| 409 Chemical element content (%) | ||||||||
| element | C | Si | Mn | P | S | Cr | Ni | more |
| Min | - | - | - | - | - | 10.5 | - | Ti:6C~0.75 |
| Max | 0.08 | 1 | 1 | 0.045 | 0.03 | 11.7 | 0.5 | |
| 410 Chemical element content (%) | ||||||
| element | C | Si | Mn | P | S | Cr |
| Min | - | - | - | - | - | 11.5 |
| Max | 0.15 | 1 | 1 | 0.04 | 0.03 | 13.5 |
| 430 Chemical element content (%) | ||||||
| element | C | Si | Mn | P | S | Cr |
| Min | - | - | - | - | - | 16 |
| Max | 0.12 | 1 | 1 | 0.04 | 0.03 | 18 |
| 2205 Chemical element content (%) | |||||||||
| element | C | Si | Mn | P | S | Cr | Ni | Mo | N |
| Min | - | - | - | - | - | 22 | 4.5 | 3 | 0.14 |
| Max | 0.03 | 1 | 2 | 0.03 | 0.02 | 23 | 6.5 | 3.5 | 0.2 |
| 2507 Chemical element content (%) | ||||||||||
| element | C | Si | Mn | P | S | Cr | Ni | Cu | Mo | N |
| Min | - | - | - | - | - | 24 | 6 | - | 3 | 0.24 |
| Max | 0.03 | 0.8 | 1.2 | 0.035 | 0.02 | 26 | 8 | 0.5 | 5 | 0.32 |
ApplicationStainless steel is used to make a variety of products including kitchen supplies, tableware, electronic appliances flatware, laundry equipment, sinks, kegs and, vats, silos, and large kitchen equipment. In addition to a multitude of products, the use of stainless steel spans a wide range of industries, including engineering and construction, and can be used in smaller items such as elevator doors, gutters, to largerscale applications such as skyscrapers.
Packing & Delivery
Containership standard:
20ft GP : 5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP : 12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC : 12032mm(Length)x2352mm(Width)x2698mm(High)
20feet container load 25tons Max and Length 5800mm MAX
40feet container load 26tons Max and Length 11800mm MAX
convenient and efficient packaging services will be provided.
