AISI 201j2 Customized 304 Grade Col Rolled Sheet 4*8 Inch Plate Mill/Slit Edge Used Stainless Steel Plate for Building Materials
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Certification:
ISO, ROHS, AISI, ASTM, GB, EN
Shape:
Square
Technique:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Aluminum Plate, Rust-Proof Aluminum Alloy Plate, Aluminum Coil, Roofing Plate, Corrosion-ResistantNegotiableMOQ: 100000 Meters -
High Quality Corrosion-Resistant Aluminum Sheet/Plate for Household ProductsNegotiableMOQ: 1 Ton
-
Fast Delivery/N08800 N08810 N08825 N06600 Corrosion-Resistant Nickel-Based Alloy PlateUS$ 50 - 80MOQ: 1 Meter
-
Supplier Price Cold Rolled Stainless Steel Coil AISI 409LUS$ 1800 - 2150MOQ: 1 Ton
-
304/316 8K Stainless Steel Coils Factory Supply 6K Mirror Cold Rolled Slit Edge Inox CoilsUS$ 1800 - 2150MOQ: 1 Ton
Certification
ISO, ROHS, AISI, ASTM, GB, EN
Shape
Square
Technique
Other
Surface Treatment
Pickling
Model NO.
201 304 316L
Production Process
welding/ polishing/inside bead removing
Specification
Customized
Product Description
AR400 wear-resistant steel plate origin Wugang delivery status quenching and tempering (Q+T) (quenching and tempering)
1, AR400 Product Introduction:
AR400 is a high-strength wear-resistant plate.
Naming: N is the first pinyin letter of the two Chinese characters "Nai" and "Mo", while 400 represents the average Brinell hardness of this steel plate.
2, NM450 Function and Performance:
Function: It mainly provides protection in situations or parts that require wear resistance, prolonging the service life of the equipment, reducing maintenance downtime caused by maintenance, and correspondingly reducing investment in funds.
Performance: Performance: Yield over 950, tensile strength above 1180.
| GB NM400 Wear Resistant Steel Plate Cuttable Quenched Tempered Heat Treatment Hot Rolled High Hardness 400HB Metal plate | |
Standard grade | DIN: XAR300,XAR400, XAR450, XAR500, XAR600, DILLIDUR400V,DILLIDUR450V,DILLIDUR500V; X120Mn12; 1.3401; SSAB:400,450,500,550,600;WELDX700,WELDX900,WELDX960; NF: FORA400,FORA500,Creusabro4800,Creusabro8000; EN: QUARD400,QUARD450,QUARD500 ; RAEX320,RAEX400,RAEX450,RAEX500; DUrostat400,DUrostat450,DUrostat500; JIS: JFE-EH360,JFE-EH400,JFE-EH500, WEL-HARD400, WEL-HARD500; SUMIHARD-K340,SUMIHARD-K400,SUMIHARD-K500 GB: NM360,NM400,M450,NM500,NM550,NM600,NR360,NR400,B-HARD360,B-HARD400,B-HARD450,KN-55,KN-60,KN-63. |
Treatment | Quenched&Tempered Steel Plate |
Thickness | Common 2~100 mm (1~300 mm) |
Width | Common 10~2500 mm (600~2500 mm) |
Length | 100~12000 mm, customized |
surface | Clean, finishing,blasting and painting according to customer requirement |
Certificate | MTC will be provided with goods, third part inspection is acceptable, for example BV,SGS. |
Trading term | EXW, FOB, CFR, CIF |
Application | Widely used in a variety of architectural and engineering structures,such as 1.) metal constructions such as buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery; 4.) industrial furnace;boilers 5.) container frame, warehouse goods shelves, etc |
GB/T 24186 NM Wear Resistant Steel Plates Chemical Composition(%) max. | |||||||||
Grade | C | Si | Mn | P | S | Cr | Ni | Mo | Ti |
NM300 | 0.23 | 0.70 | 1.60 | 0.025 | 0.015 | 0.70 | 0.50 | 0.40 | 0.050 |
NM360 | 0.25 | 0.70 | 1.60 | 0.025 | 0.015 | 0.80 | 0.50 | 0.50 | 0.050 |
NM400 | 0.30 | 0.70 | 1.60 | 0.025 | 0.010 | 1.00 | 0.70 | 0.50 | 0.050 |
NM450 | 0.35 | 0.70 | 1.70 | 0.025 | 0.010 | 1.10 | 0.80 | 0.55 | 0.050 |
NM500 | 0.38 | 0.70 | 1.70 | 0.020 | 0.010 | 1.20 | 1.00 | 0.65 | 0.050 |
NM550 | 0.38 | 0.70 | 1.70 | 0.020 | 0.010 | 1.20 | 1.00 | 0.70 | 0.050 |
NM600 | 0.45 | 0.70 | 1.90 | 0.020 | 0.010 | 1.20 | 1.00 | 0.80 | 0.050 |
B: 0.0005-0.006, Als min. 0.010 | |||||||||
GB/T 24186 NM Wear Resistant Steel Plates Mechanical Properties | ||||
Steel Grade | Thickness | Hardness (HBW) | Elongation | Tensile Strength |
NM300 | ≤80 | 270-330 | ≥14% | ≥1000 Mpa |
NM360 | ≤80 | 330-390 | ≥12% | ≥1100 Mpa |
NM400 | ≤80 | 370-430 | ≥10% | ≥1200 Mpa |
NM450 | ≤80 | 420 - 480 | ≥7% | ≥1250 Mpa |
NM500 | ≤70 | ≥470 | - | - |
NM550 | ≤70 | ≥530 | - | - |
NM600 | ≤60 | ≥570 | - | - |
Grade Comparison | |
GB | NM300,NM360,NM400,NM450,NM500 |
SS | HARD400, HARD450, HARD500, HARD600 |
DIN | XAR400, XAR450, XAR500, XAR600, Dillidur400, Dillidur500 |
NBN | QUARD400, QUARD450, QUARD500 |
NF | FORA400, FORA500, Creusabro4800, Creusabro8000 |
JIS | JFE-EH360, JFE - EH400, JFE - EH500, WEL-HARD400, WEL-HARD500 |
SFS | RAEX400, RAEX450, RAEX500 |
It has good mechanical strength,corrosion-resistant and heat-resistance strength.
It is widely used in electric apparatus,chemical machinery,ood processing equipment,rechargeable batteriesomputers, cellular Phone, power tools, camcorders and so on.
Nickel Grade | Ni+Co | Cu | Si | Mn | C | Cr | S | Fe | Mg |
≥ | ≤ | ||||||||
Ni201 | 99.2 | .25 | .3 | .35 | .02 | .2 | .01 | .3 | - |
Ni200 | 99.0 | .25 | .3 | .35 | .15 | .2 | .01 | .3 | - |
Physical Data
Density | 8.89g/cm3 |
Specific Heat | 0.109(456 J/kg.ºC) |
Electrical Resistivity | 0.096×10-6ohm.m |
Melting Point | 1435-1446ºC |
Thermal Conductivity | 70.2 W/m-K |
Mean Coeff Thermal Expansion | 13.3×10-6m/m.ºC |
Typical Mechanical Properties
Mechanical Properties | Nickel 200 |
Tensile Strength | 462 Mpa |
Yield Strength | 148 Mpa |
Elongation | 47% |
Our Production Standard
Bar | Forging | Pipe | Sheet/Strip | Wire | |
ASTM | ASTM B160 | ASTM B564 | ASTM B161/B163/B725/B751 | AMS B162 | ASTM B166 |
Main Composition % | |||
Ni | Mn | Si | |
NiMn2 | Bal. | 1.5-2.5 | 0.3 |
NiMn3 | Bal. | 2.3-3.3 | 0.3 |
NiMn5 | Bal. | 4.6-5.4 | 0.5 |
Code No. | Dia. mm | TS. N/mm2 | Elongation % |
NiMn2 | ≤6.0 | ≥350 | ≥20 |
NiMn3 | ≤6.0 | ≥350 | ≥20 |
NiMn5 | ≤6.0 | ≥350 | ≥20 |
1.standard exporting cartons package
2.Cartons packed with wooden pallet
3.As per customized specifications such as logo or others
