Home > Electrical & Electronics > Relay & Contactor > Relay > IS420PPNGH1A Profinet Gateway Model Mark VIe/Mark VIeS
IS420PPNGH1A Profinet Gateway Model Mark VIe/Mark VIeS
US$ 7390.00
≥1 Pallet
Key Specifications
Get Latest Price
Place of Origin:
America
Communication Interface:
Modubus
Product name:
Profinet Gateway Model
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3BHE023784R1023 PP D113 B01-10-150000 AC 800PEC Excitation SystemsUS$ 15278.00MOQ: 1 Pallet -
PCD230A 3BHE022291R0101 PC D230 A PEC80-CCM Excitation Controller ModuleUS$ 5555.00MOQ: 1 Pallet
-
IS420UCSBH3A Mark VIe Control Mark VIe Turbine Control System SeriesUS$ 16667.00MOQ: 1 Pallet
-
560PSU02 1KGT011900R0001 Industrial-grade Power SupplyUS$ 3960.00MOQ: 1 Pallet
-
P0926GV FBM231 Four Serial I/O Communication Ports Interface Four Direct Connect RS-232US$ 1390.00MOQ: 1 Pallet
Place of Origin
America
Communication Interface
Modubus
Product name
Profinet Gateway Model
Model Number
IS420PPNGH1A
Condition
NEW
Warranty
One Year
Package
Original Packaging
Product Description
nation |
china |
Product Name |
IS420PPNGH1A |
Material |
Profinet Gateway Model Mark VIe/Mark VIeS |
warranty |
One year |
Stock |
In Stock |
Package |
Original |
Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!
Can transport to the world.
（Rule out special circumstances can't transport area！）
If you need, please contact customer service.
【The contact information of the service】
① 24 hours to receive mail reply (12 hours);
② EBAY customer service chat messages, reply within 3 hours.
③ Shipped to countries outside of Asia, please contact the seller.（Part of the international area, free shipping）
【Product properties】
① Type:GR-2C-DC24V
② Inventory quantity: 2
③ The colour：NEW
④ Freight: Different areas of freight, depending on the local freight forwarder shall prevail.
⑤ Whether containing tariffs: Do not include any taxes and fees
⑥ Packing: Use the seller safety packaging
【Friendship tip】
Ⅰ、The mode of transportation and freight:
① , Shipping company according to different regions. (If you need to specify the shipping company, please contact the seller)
② , freight, transport price (not including the national customs charges and other fees), according to the actual seller to provide shipping price shall prevail.
③ , the territory of China (including Hong Kong, Macao and Taiwan), in most of the free shipping. Please contact the staff.
Ⅱ、Payment method:
Buyer please select a payment according to the actual situation, if in doubt contact the seller!!!!!
Ⅲ、Product quality and after-sales service:
1, Consulting the seller's product quality, buy again. If you have any questions, please contact the seller.
2, During the after-sales service, according to the circumstances. If you want to delay the after-sales service, or else the seller after-sale policy shall prevail. Please contact the seller.
IS420PPNGH1A Profinet Gateway Model Mark VIe/Mark VIeS
The IS420PPNGH1A is a PROFINET Gateway module device designed to fit into a Mark VIe system. The Mark VIe was one of the final
Speedtronic turbine control systems developed by General Electric. It is typically used for gas, hydro, and steam turbine systems.
The IS420PPNGH1A is a powerful gateway that connects Mark VIe controllers to a PROFINET LAN (local area network). This allows
high-speed communication to occur between the controller and PROFINET I/O devices.
The IS420PPNGH1A is a single-module component that is designed to be air-cooled. It has no installed battery or fan. The unit
should be installed where fans are not blocked and airflow is not impeded. This model will need to be panel mounted vertically.
It is important to note that IONet and PROFINET cannot be supported simultaneously by the same switch. Each network must be
connected to an independent switch. PPNG boards typically use ESWA 8-port unmanaged switches or ESWB 16-port unmanaged switches.
Cabling can be anywhere from three to eighteen feet.
The IS420PPNGH1A is built upon a 1066 MHz Intel processor (EP80579.) It runs upon a QNX Neutrino operating system and has 256 DDR2
SDRAM. You must use ControlST V05.04 or higher. The weight of this unit is 2.4 pounds. The maximum PROFINET data rate that can be
used with this model is 6 KB per ms.
Speedtronic turbine control systems developed by General Electric. It is typically used for gas, hydro, and steam turbine systems.
The IS420PPNGH1A is a powerful gateway that connects Mark VIe controllers to a PROFINET LAN (local area network). This allows
high-speed communication to occur between the controller and PROFINET I/O devices.
The IS420PPNGH1A is a single-module component that is designed to be air-cooled. It has no installed battery or fan. The unit
should be installed where fans are not blocked and airflow is not impeded. This model will need to be panel mounted vertically.
It is important to note that IONet and PROFINET cannot be supported simultaneously by the same switch. Each network must be
connected to an independent switch. PPNG boards typically use ESWA 8-port unmanaged switches or ESWB 16-port unmanaged switches.
Cabling can be anywhere from three to eighteen feet.
The IS420PPNGH1A is built upon a 1066 MHz Intel processor (EP80579.) It runs upon a QNX Neutrino operating system and has 256 DDR2
SDRAM. You must use ControlST V05.04 or higher. The weight of this unit is 2.4 pounds. The maximum PROFINET data rate that can be
used with this model is 6 KB per ms.
