US$ 3699
20 - 99 Units
US$ 3499
100 - 499 Units
US$ 3299
≥500 Units
Key Specifications
Get Latest Price
Type:
Buggy/Golf Carts
Certification:
DOT
Color:
White
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
30 days
Related Products
Type
Buggy/Golf Carts
Certification
DOT
Color
White
Power
Other
Maximum Speed
20-30 km/h
Power Fuel
Electric
Gradeability
20-30%
Voltage of Battery
48V
Suitable for
Golf Course
Seats
1-2
| 1 | Overall dimensions(mm) | 2400*1200*1800 | ||||
| 2 | (mm) Wheelbase | 1680 | ||||
| 3 | Front wheel tread (mm) |
960 | ||||
| 4 | Rear wheel tread | 1000 | ||||
| 5 |
Mileage(km） |
75-85 | ||||
| 6 |
Max Speed（km/h） |
30 | ||||
| 7 | Climb ability | 20%（≈11°） | ||||
| 8 | Maximum loa（kg） | 250 | ||||
| 9 | Frame | High-strength carbon steel integral frame, phosphating electrophoretic rust prevention treatment surface electrostatic powder spraying | ||||
| 10 | Suspension | Front suspension： MacPherson strut independent suspension |
Rear suspension:Helical spring + cylindrical hydraulic shock absorber | |||
| 11 | Steering system | Self-adjust rack and pinion | ||||
| 12 | Braking system |
Mechanical braking and parking braking |
||||
| 13 | Battery | 48V105Ah lithium iron phosphate battery | ||||
| 14 | 48V150Ah lithium iron phosphate battery | |||||
| 15 | Drive motor | AC motor-4kW（With parking brake） | ||||
| 16 | AC motor-5kW（With parking brake） | |||||
| 17 | Controller | 48V350A | ||||
| 18 | Dashboard | 2-inch round instrument | ||||
| 19 | Charger | 48Vlithium special car charger | ||||
| 20 | Body |
PP injection molding front and rear cover, automotive color baking process, paint surface added UV components |
||||
| 21 | Roof |
Injection molding ceiling |
||||
| 22 | Windshield | foldable | ||||
| 23 | seat | Knit artificial leather | ||||
| 24 | Tire | 18x8.5-8 Iron wheel hub tires 18x8.5 - 8 |
||||
| 25 | 18x8.5-8 Aluminum wheel hub tires 18x8.5 - 8 | |||||
| 26 | 205/50-10 Aluminum wheel hub tires 205/50-10 | |||||
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Year Established
2020
Factory Size
1,000-3,000 square meters
Product Certifications
QS9000, ISO9001
Port of Shipment
shanghai, shenzhen, NingBo, YanTian
