Shenke Instrument VEG20610 INTECONT

Shenke Instrument VEG20610 INTECONT

The INTECONT VEG20610 Continuous Weighing Display Controller, developed using Germany's Schunk's latest core technology (vdb), is a new type of automated control instrument tailored for China's conditions. It features strong functionality, low cost, and user-friendly operation, having withstood various harsh environmental tests while maintaining long-term stable performance and high accuracy. The LCXK-type instrument serves as a measurement and control system for feeding equipment. This instrument applies to the following control systems: 1. Metering Feeder: Controls feeding flow by regulating the belt speed of the feeder. 2. Belt Scale with Pre-Feeder: Adjusts belt load through pre-feeder control to regulate feeding flow. 3. Belt Scale: Regulates feeding flow via belt load control based on belt speed. The INTECONT series continuous weighing display controller offers multilingual human-machine interface capabilities, supporting communication with host computers or PLCs. It includes Xuzhou Weitake printing interfaces and enables keyboard settings, host computer programming, external start/stop functions, fault alarms, and data power-off protection. The software features comprehensive functionalities including automatic belt cleaning, self-calibration, and self-detection systems with strong anti-interference capabilities. LCXK-type: Features VFD LCD display using Samsung LCD screens from South Korea: 57-dot matrix, fluorescent backlight, 2 rows with 20 characters per line, character height 6mm. Upward display: left: running information, right: setting feed rate in kg/h or t/h Downward display: left: event information, right: can be selected as actual flow, belt load, belt speed, etc; essential parameter 1. Suitable for resistive strain gauge weighing sensor (supply bridge: +10V, sensitivity 1-3mV/V load voltage input signal: 0-20mV) 2. Suitable for Hall effect speed sensor (2 lines: +8V,3 lines: +24V speed pulse: low level 0~4V, high level 6~24V) 3 Instantaneous flow range: 0.1~1500t/h; 4 Accumulated flow range: 0~999999t; 5 Speed range: 0~3.3m/s; going 6. Operating environment: Temperature: -40℃~ +70℃, humidity: not more than 95%; 7. Power supply: 24V,50Hz; metering performance 8. Measurement precision: 0.5%; 9. Accuracy: 0.1%F.S; 10. Linearity: 0.06%F.S; 11. Repetitiveness: 0.06%F.S; 12. Short-term stability of zero value: 0.0006% Cmax; 13. Three-hour stability of zero value: 0.0009% Cmax; 14. Detection limit: 0.018% Pmax; functional characteristics 15. Equipped with a print output port: All parallel 25-pin interfaces for keyboard digital calibration and operational parameter settings; 16. Features calibration, preset feeding control, and communication functions; 17. Provides print output ports: Serial (RS232/RS422) or parallel (standard 25-pin) interfaces; 18. Three-channel analog input (A/D); 19. Four-channel analog output (D/A); 20. Cumulative pulse output (unit pulse weight adjustable via parameters); 21 Switch quantity Four-channel inputs: 1. External Start/Stop 2. Release 3. Deviation 4. Emergency Stop; Four-channel outputs: 1. Ready 2. Operating Status 3. Fault Alarm 4. Cumulative Data; 22 Communication: RS232/RS485 serial port output; 23 Supports configuration software: Groupwang, MGCS, Fix, etc.; 24 Features power-off data retention; 25 Power supply with isolation, anti-interference, automatic overvoltage and overcurrent protection; 26 Indicator lights display system operating status;
