HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany

HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany

HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany

HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany

HUADA HAWKER Lithium Battery EV Series

HUADA HAWKER24V, 48V lithium iron phosphate batteries

Nominal voltage: 24V/48V nominal capacity: 20-200AH operating temperature: charging 0-45 ℃, discharging -20-60 ℃ Application areas: AGV, mobile robots, industrial machinery and equipment, emergency power supply, etc

HUADA HAWKER EV24-30 25.6V 30 390 * 199 * 130 9

HUADA HAWKER EV24-40 1.0 25.6V 40 315 * 237 * 165 17.5

HUADA HAWKER EV24-40 2.0 25.6V 40 527 * 155 * 170 17.5

HUADA HAWKER EV24-60 1.0 25.6 60 333 * 241 * 214 25

HUADA HAWKER EV24-60 2.0 25.6 60 325 * 237 * 187 25

HUADA HAWKER EV24-80 25.6 80 356 * 335 * 216 29

HUADA HAWKER EV24-100 25.6 100 356 * 335 * 216 34

HUADA HAWKER EV24-120 25.6 120 400 * 275 * 248 41.5

HUADA HAWKER EV24-200 25.6 200 551 * 210 * 433 65

HUADA HAWKER EV48-20 48 20 315 * 237 * 165 17.5

HUADA HAWKER EV48-30 48 30 380 * 238 * 202 21.4

HUADA HAWKER EV48-40 48 40 356 * 335 * 216 32

HUADA HAWKER EV48-50 48 50 788 * 170 * 170 36

HUADA HAWKER EV48-60 1.0 48 60 567 * 241 * 226 40

HUADA HAWKER EV48-60 2.0 48 60 430 * 350 * 216 40

HUADA HAWKER EV48-100 48 100 614 * 346 * 202 65

HUADA HAWKER EV48-160 48 160 606 * 456 * 255 86.5

HUADA HAWKER EV48-180 48 180 600 * 275 * 517 95

HUADA HAWKER EV48-200 48 200 700 * 555 * 294 130

HUADA HAWKER battery specifications can be customized. For more information, please contact HUADA HAWKER Battery Wang Zelong.

HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany

HUADA HAWKER Battery Type: Lithium Iron Phosphate Battery

Maximum charging current: 2C

Maximum discharge current: 2C

Instantaneous discharge current: 3C

Discharge cut-off voltage: 23.6V/43.5V

Charging temperature: 0-45 ℃

Discharge temperature: -20~60 ℃

Storage temperature: -20~60 ℃

Temperature protection: 65 ℃± 5 ℃

Battery casing: Sheet metal casing

Port Design: Different Ports

Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, etc

Communication interfaces: 485, CANOPEN, CAN, AO (0-5V represents 0-100%), DO (2 channels), DI, etc

Application areas: AGV, mobile robots, industrial machinery and equipment, emergency power supply, etc

Product Features

Fast charging: Supports 2C fast charging, and can be fully charged in up to half an hour.

Dumb plug: Using different plug specifications for charging and discharging can avoid incorrect insertion.

Port design: Charging and discharging port design, supporting simultaneous charging and discharging without disturbing each other.

Self developed BMS:

A battery management system for mobile robots with rich communication interfaces.

It can achieve the function of recording, storing, and exporting fault data.

The control system is designed with extremely low power consumption. Shutdown status 30uA, power on status 30mA

Support customization of various non-standard functions.

Environmentally friendly and long-lasting: using automotive grade power lithium iron phosphate battery cells with high cycle life, in line with the values of low-carbon, energy-saving, and environmental protection;

Professional design: By filling the shock-absorbing structure inside the cold-rolled sheet metal shell, the requirements of strong heat dissipation, high safety, and high reliability are achieved.

HAWKER EV48-100 BATTERY AGV / Forklift Lithium Batteries 48V100Ah Germany
