Specification
Output Channels | 16 channels |
Output Type | 24 V DC sourcing (range 10–50 V) |
Backplane Current Consumption | 0.280 A @ 5 V DC; 0 A @ 24 V DC |
On/Off Response Time | ON: 0.1 ms, OFF: 1.0 ms |
Leakage Current (Output Off) | ≤1 mA |
Continuous Current per Channel | 0.5 A @ 30°C; 0.25 A @ 60°C |
Total Module Continuous Current | 8 A @ 30°C; 4 A @ 60°C |
Surge Current Tolerance | Up to 3 A for 10 ms per channel |
Output Voltage Drop | Approx. 1.2 V @ 0.5 A |
Minimum Load Current | ≥1 mA |
Isolation (I/O) | 1500 VAC isolation to backplane; 500 VDC isolation to communication circuits |
