RVZOT BATTERY 2TPA150 LU SHENG 2V150AH Battery seismic bracket
French RVZOT Battery AGM (TPA) Series
The French RVZOT battery AGM (TPA) series products adopt a thickened electrode plate design to improve durability and extend life, reduce electrolyte density to delay corrosion of the electrode plates, and lower battery height to prevent electrolyte delamination in high-capacity AGM batteries. MirucTM catalytic explosion-proof safety valves are used to increase internal gas recombination rate and extend battery life. The artistic level craftsmanship and computer-controlled testing process enable the TPA series products to perform exceptionally well in high-capacity critical applications.
Parameters
Design float charging life: 20 years at 25 ℃
Floating charging voltage: 2.25-2.30V/section 25 ℃, temperature correction -3mV/℃
Balanced charging: 2.30-2.35 V/section at 25 ℃
Cyclic charging voltage: 2.40-2.50 V/section 25 ℃, temperature correction -5mV/℃
Self discharge rate: ≤ 1.5% per month
80% DOD cycle charging and discharging times: ≥ 1250 times
| 2TPA100 | 2 | 106 | 100 | 59.5 | 170 | 72 | 212 | 6.0 | 1.4 | C | |
|
2TPA150 | 2 | 159 | 150 | 89.3 | 170 | 98 | 212 | 8.5 | 1.1 | C |
|
2TPA200 | 2 | 212 | 200 | 119 | 170 | 110 | 350 | 14.8 | 1.0 | D |
|
2TPA250 | 2 | 266 | 250 | 149 | 170 | 110 | 350 | 15.8 | 1.0 | D |
|
2TPA300 | 2 | 318 | 300 | 179 | 170 | 150 | 350 | 20.2 | 0.9 | D |
|
2TPA350 | 2 | 372 | 350 | 208 | 170 | 150 | 350 | 22.0 | 0.8 | D |
|
2TPA400 | 2 | 424 | 400 | 238 | 210 | 175 | 350 | 26.2 | 0.7 | D |
|
2TPA450 | 2 | 478 | 450 | 268 | 210 | 175 | 350 | 28.5 | 0.65 | D |
|
2TPA500 | 2 | 530 | 500 | 298 | 240 | 175 | 350 | 31.5 | 0.6 | D |
|
2TPA600 | 2 | 636 | 600 | 357 | 300 | 175 | 350 | 40.0 | 0.55 | D |
|
2TPA700 | 2 | 742 | 700 | 417 | 300 | 175 | 350 | 42.0 | 0.5 | D |
|
2TPA800 | 2 | 848 | 800 | 476 | 410 | 175 | 350 | 55.0 | 0.5 | D |
|
2TPA900 | 2 | 954 | 900 | 536 | 410 | 175 | 350 | 57.2 | 0.48 | D |
|
2TPA1000 | 2 | 1060 | 1000 | 595 | 475 | 175 | 350 | 66.0 | 0.45 | D |
|
2TPA1200 | 2 | 1272 | 1200 | 714 | 475 | 175 | 350 | 70.4 | 0.4 | D |
|
2TPA1500 | 2 | 1590 | 1500 | 893 | 403 | 354 | 350 | 106.0 | 0.35 | D |
|
2TPA1800 | 2 | 1908 | 1800 | 1071 | 403 | 354 | 350 | 114.5 | 0.3 | D |
|
2TPA2000 | 2 | 2120 | 2000 | 1190 | 490 | 350 | 350 | 133.0 | 0.28 | D |
|
2TPA2500 | 2 | 2660 | 2500 | 1488 | 709 | 350 | 350 | 151.0 | 0.25 | D |
|
2TPA3000 | 2 | 3180 | 3000 | 1785 | 709 | 350 | 350 | 201.0 | 0.2 | D |
RVZOT battery seismic bracket
Rvzot designs earthquake resistant brackets and cabinets according to different user site conditions (area, load-bearing capacity, layout, maintenance space, earthquake resistance level, etc.), and recommends Rvzot standard earthquake resistant brackets.
The seismic standards for bracket design comply with IBC2006 and NEBS ZONE2 (ZONE4 optional).
The group bracket is a combination type, divided into two types: vertical installation of batteries (pole up) and horizontal installation (pole front), which can be flexibly arranged according to the site area.
Using heavy-duty materials, the factory produces on-site combinations for easy transportation and on-site installation, and is coated with acid resistant epoxy resin paint.
The Rvzot battery pack (2 volts/cell) is connected using dedicated flexible cables or copper bars, which users can choose from.
