Help CenterSeamless/Welded 304 316 201 Cold Rolled Cold Drawn Stainless Steel Tube
Related Products
-
45# 50× 3.5mm Precision Bright Tube for Mechanical ProcessingUS$ 2 - 50MOQ: 1 Ton -
Polished Stainless Steel Precision Tube, ASTM A269 TP304, 1.5mm Wall, 6m, for Aerospace UseUS$ 300 - 4000MOQ: 1 Ton
-
Customized SUS309s Bright Stainless Steel Polished TubeUS$ 2 - 50MOQ: 1 Kilogram
-
304 Stainless Steel Capillary Tube Medical Grade Internal and External Bright TubeNegotiableMOQ: 1 Ton
-
0.15mm 0.2mm 1mm Small Diameter Micro Pipe Stainless Steel Capillary TubeUS$ 2 - 50MOQ: 1 Kilogram
Item |
Stainless Steel Round Pipe / Tube |
|
Steel grade |
200 / 300 / 400 series |
|
Standard |
ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605, GB13296 |
|
Material |
304,304L,309S,310S,316,316Ti,317,317L,321,347,347H,304N,316L, 316N,201,202 |
|
Surface |
Polishing,annealing,pickling,bright(NO.1/NO.2D/NO.2B/BA/NO.3/NO.4/NO.7/NO.8)
|
|
Type |
Hot rolled and cold rolled |
|
Size |
Wall thickness |
0.15-50mm |
Outer diameter |
DN15-DN600 |
|
Delivery time |
7-35 weekdays |
|
Package |
Standard Export Package,Suit for All Kinds of Tran |
|
Application
Lighting,solar reflector plate.
2.Architectural appearance, interior decoration, ceiling, metope,furniture,cabinets and so on.
3.Elevator,nameplate, bags.
4.Automotive interior and exterior decoration.
5. Interior decoration: such as photo frame.etc
Surface treatment of stainless steel coils
| Surface Finish | Definition | Application |
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA/8K mirror | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| Hairline | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe. |
| Normal pipe size |
OD | Normal wall thickness | |||||||||||||
| DN | inch | ASME | SCH10 | SCH20 | SCH30 | STD | SCH40 | SCH60 | XS | SCH80 | SCH100 | SCH120 | SCH140 | SCH160 | XXS |
| 15 | 1/2 | 21.3 | 2.11 | 2.41 | 2.77 | 2.77 | 3.73 | 3.73 | 4.78 | 7.47 | |||||
| 20 | 3/4 | 26.7 | 2.11 | 2.41 | 2.87 | 2.87 | 3.91 | 3.91 | 5.56 | 7.82 | |||||
| 25 | 1 | 33.4 | 2.77 | 2.9 | 3.38 | 3.38 | 4.55 | 4.55 | 6.35 | 9.09 | |||||
| 32 | 1.25 | 42.2 | 2.77 | 2.97 | 3.56 | 3.56 | 4.85 | 4.85 | 6.35 | 9.7 | |||||
| 40 | 1.5 | 48.3 | 2.77 | 3.18 | 3.68 | 3.68 | 5.08 | 5.08 | 7.14 | 10.15 | |||||
| 50 | 2 | 60.3 | 2.77 | 3.18 | 3.91 | 3.91 | 5.54 | 5.54 | 8.74 | 11.07 | |||||
| 65 | 2.5 | 73 | 3.05 | 4.78 | 5.16 | 5.16 | 7.01 | 7.01 | 9.53 | 14.02 | |||||
| 80 | 3 | 88.9 | 3.05 | 4.78 | 5.49 | 5.49 | 7.62 | 7.62 | 11.13 | 15.25 | |||||
| 90 | 3.5 | 101.6 | 3.05 | 4.78 | 5.74 | 5.74 | 8.08 | 8.08 | |||||||
| 100 | 4 | 114.3 | 3.05 | 4.78 | 6.02 | 6.02 | 8.56 | 8.56 | 11.13 | 13.49 | 17.12 | ||||
| 125 | 5 | 141.3 | 3.4 | 6.55 | 6.55 | 9.53 | 9.53 | 12.7 | 15.88 | 19.05 | |||||
| 150 | 6 | 168.3 | 3.4 | 7.11 | 7.11 | 10.97 | 10.97 | 14.27 | 18.26 | 21.95 | |||||
| 200 | 8 | 219.1 | 3.76 | 6.35 | 7.04 | 8.18 | 8.18 | 10.31 | 12.7 | 12.7 | 15.09 | 18.26 | 20.62 | 23.01 | 22.23 |
| 250 | 10 | 273 | 4.19 | 6.35 | 7.8 | 9.27 | 9.27 | 12.7 | 12.7 | 15.09 | 18.26 | 21.44 | 25.4 | 18.58 | 25.4 |
| 300 | 12 | 323.8 | 4.57 | 6.35 | 8.38 | 9.53 | 10.31 | 14.27 | 12.7 | 17.48 | 21.44 | 25.4 | 28.58 | 33.32 | 25.4 |
| 350 | 14 | 355.6 | 6.35 | 7.92 | 9.53 | 9.53 | 11.13 | 15.09 | 12.7 | 19.05 | 23.83 | 27.79 | 31.75 | 35.71 | |
| 400 | 16 | 406.4 | 6.35 | 7.92 | 9.53 | 9.53 | 12.7 | 16.66 | 12.7 | 21.44 | 26.19 | 30.96 | 36.53 | 40.19 | |
| 450 | 18 | 457.2 | 6.35 | 7.92 | 11.13 | 9.53 | 14.27 | 19.05 | 12.7 | 23.83 | 39.36 | 34.93 | 39.67 | 45.24 | |
| 500 | 20 | 508 | 6.35 | 9.53 | 12.7 | 9.53 | 15.09 | 20.62 | 12.7 | 26.19 | 32.54 | 38.1 | 44.45 | 50.01 | |
| 550 | 22 | 558.8 | 6.35 | 9.53 | 12.7 | 9.53 | 22.23 | 12.7 | 28.58 | 34.93 | 41.28 | 47.63 | 53.98 | ||
| 600 | 24 | 609.6 | 6.35 | 9.53 | 14.27 | 9.53 | 17.48 | 24.61 | 12.7 | 30.96 | 38.89 | 46.02 | 52.37 | 59.54 | |
| 650 | 26 | 660.4 | 7.92 | 12.7 | 9.53 | 12.7 | |||||||||
| 700 | 28 | 711.2 | 7.92 | 12.7 | 15.88 | 9.53 | 12.7 | ||||||||
| 750 | 30 | 762 | 7.92 | 12.7 | 15.88 | 9.53 | 12.7 | ||||||||
| 800 | 32 | 812.8 | 7.92 | 12.7 | 15.88 | 9.53 | 17.48 | 12.7 | |||||||
| 850 | 34 | 863.6 | 7.92 | 12.7 | 15.88 | 9.53 | 17.48 | 12.7 | |||||||
| 900 | 36 | 914.4 | 7.92 | 12.7 | 15.88 | 9.53 | 19.05 | 12.7 | |||||||
Stainless Steel Coil is widely used in fields such as tableware, household appliances, machinery manufacturing, building decoration, coal, petrochemical, etc. due to its excellent corrosion resistance, heat resistance, and low temperature resistance.
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
Supported by Machines and Equipment
All our products are manufactured with the latest manufacturing techniques with machines and equipment, which are fitted with the highest technology, to provide products in full conformity with international standards.
Meeting Inspection and Approval Certificates
We have passed the Mill Test certificate, C/W certificate (Calibration works certificate) EN 10204 3.1, DIN 50049 3.1, ISO 10474 3.1, NACE MR-0103/NACE MR-0175/ISO 15156, PED-97/23/EC, AD-2000-WO, with 3.2 certificates duly certified and approved by LRS, GL, BV, DNV, ABS, SGS, TUV, RINA, IRS, NORSOK and more.
Customized Service
We provide product customization services such as shot blasting, precision pipe cutting, cut and roll grooving, custom pipe fabrication, pipe threading, pipe beveling, and coating. They are also approved by Third Party inspection agencies like DNV, BV, SGS, Moody, TuV, ABS, LR, GL, PED, RINA, KR, NKK, AIB-VINEOTTE, CEIL, VELOSI, CCSI, and more. We supply for PetroVietnam, WSF, YPFB, AWH, HMC, PTT, EP PetroEcuador, POD, KNPC, and more.
Establishing Friendly Partnership
Our mission is whether our clients are active in the oil and gas, water supply line, or construction, we endeavor to deliver the highest quality products and value-added services to support our clients' business. We pursue a win-win situation and long-term cooperative relationships with customers, providing specializing service for the old and new customers with better and more economical results.
Package
1.Bundles Packing
Each covered by plastic film, then wraped to be bundles by craft paper.
2.Carton Packing
Each pcs packed by plastic bag, then put in one carton,
3.Wood Pallet packing
Bundles or cartons packing, then put them on wood pallet.
