Help CenterMarine Governor Test Stand HMM50-A(Economic)
Related Products
-
Governor Test Stand UEG Actuator TesterUS$ 1400 - 1430MOQ: 1 Unit -
Governor Test Stand Feedback UnitUS$ 500 - 600MOQ: 1 Unit
-
Marine Governor Test Stand HMM50-AB(Standard)US$ 23000 - 25000MOQ: 1 Unit
-
UG8L UG10L Governor Overhaul Kits Suit for WOODWARD,ZEXEL,YanmarUS$ 70 - 200MOQ: 1 Set
-
1102 Governor Overhaul Kits Suit for REGULATEURS EUROPAUS$ 70 - 200MOQ: 1 Set
MARIWARD has wide-ranging applications and has become the preferred testing and calibration equipment for ship repair yards, marine diesel engine manufacturers, governor manufacturers, specialized repair facilities and petrochemical plants.
WOODWARD: SG,PSG,UG8,UG10,UG15,UG40,3161,PGA-12,PGA-58,PGA-70,PG-PL,PGD,PGG-58,PGG-200,PGG-500,PGA-200,PGA-300,PGA-500,TG-10,TG-13,TG-17,UG-25+;
ZEXEL: RHD6,RHD10,RHD35;
YANMAR: NZ61;
REGULATEURS EUROPA: 1100,1500,1800, etc.
KEY TECHNICAL SPECIFICATIONS:
Power supply: 380V/440V, 50Hz/60Hz
Output power: 5 HP
Speed range: 0-2300 RPM (Accuracy: ±1 RPM)
Gear box speed: 0-6000 RPM (Accuracy: ±1 RPM)
Air Pressure: 0–100 PSI (Accuracy: 0.1 PSI)
Oil Pressure: 0–600 PSI (Accuracy: 1 PSI)
Oil Temperature: 0–100°C (Accuracy: ±1°C)
KEY PERFORMANCE AND FUNCTIONS:
The Governor test stand supports dynamic parameter configuration for speed, pressure, shutdown protection signals, and other critical governor testing requirements. It enables comprehensive testing, including:
1. Run-in Test: Conducted at speeds specified in the governor's Technical Service Procedure (TSP).
2. Pneumatic/AC/DC Motor Speed Setting: Calibration trials for pneumatic and motor-driven speed adjustment systems.
3. Speed Range Calibration: Configures maximum and minimum speed limits tailored to specific governor models.
4. Static Performance Test: Simulates diesel engine no-load conditions to measure static fluctuation rate and droop.
5. Step Speed Change Test: Tests sudden speed increases/decreases, recording transient response and stabilization time.
6. Load Variation Test: Simulates abrupt load application/rejection on diesel engines, evaluating speed deviation and recovery time.
7. Droop Adjustment: Sets governor droop during simulated load-change scenarios.
8. Oil Pressure/Temperature Monitoring: Real-time measurement and display of operating oil pressure and temperature.
