Home > Products > alloy steel > M2 Skh51 High-Speed Steel Round Bar for Cutting Tool Die Stamping Flat Annealed Wear Resistance Milled Surface Four Sides Cut

M2 Skh51 High-Speed Steel Round Bar for Cutting Tool Die Stamping Flat Annealed Wear Resistance Milled Surface Four Sides Cut

FOB Price

US$ 700 - 1200 / Ton

1 Ton(Min. Order)

Port Tianjin Port
Payment TermsT/T L/C Money Gram PayPal D/P Western Union Other
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Alloy Steel Bar	Technique	Other, Forged/Hot Rolled/Cold Drawn
Application	Structural Steel Bar, Tool Steel Bar, Die Steel Bar, Other, Mold & Dies	Surface Treatment	Polished
Standard	AISI, ASTM, GB, JIS, DIN, BS	After-sales Service	Support
Alloy	Alloy	Special Use	Mold Steel, Cold Heading Steel, Other, Structural Steel Bar, Tool Steel Bar
Transport Package	Plywood Pallet/Case, Steel Pallet or as Per Custom	Specification	Customized
Trademark	OEM	Origin	China

Product Description

tool steel

High Speed Steel Round Bar and Plate

High speed tool steel comprises a set of tool steel alloys named for their capacity to cut materials faster than traditional high-carbon steels previously used in cutting tools.
*High alloy content, primarily tungsten or molybdenum, with lesser amounts of chromium, vanadium and cobalt;
*High carbon content-a minimum of 0.65% by weight, but commonly anywhere from 0.8% to 1.5% carbon content;
*Rockwell hardness of at least 64 HRC at room temperature;
*A heat treatment process that produces a high quantity of complex metallic carbides-chiefly tungsten, molybdenum and vanadium carbides-suspended in a steel substrate, which results in hardness and wear resistance.

ASTM

DIN

JIS

1.3343

SKH51

0.78~0.88

0.20~0.45

0.15~0.40

0.030 Max

3.75~4.50

4.50~5.50

1.75~2.20

5.50~6.75

M35

1.3243

SKH55

0.82~0.95

0.2~0.45

0.15~0.4

0.030 Max

3.8~4.5

4.75~5.25

1.75~2.15

5.5~6.5

4.6~5

M42

1.3247

SKH59

1.05~1.15

0.15~0.65

0.15~0.4

0.030 Max

3.5~4.25

9~10

0.95~1.35

1.15~1.85

7.75~8.75

M50

1.3325

0.78~0.88

0.20~0.60

0.15~0.45

0.030 max

3.75~4.50

3.90~4.75

0.80~1.25

1.3355

SKH2

0.62~0.8

0.2~0.40

0.1~0.40

0.030 Max

3.75~4.5

0.9~1.3

17.25~18.75

T15

1.3202

SKH10

1.30~1.45

<0.45

<0.4

0.030 Max

0.031 Max

3.8~4.5

0.7~1.0

3.5~4.0

11.5~12.5

4.5~5.0

1.3255

SKH3

0.7~0.8

0.1~0.4

0.1~0.40

0.030 Max

3.75~4.5

0.4~1

0.8~1.2

17.5~19

4.25~5.75


	AISI	DIN	JIS	Stock	Application
Hot Work Tool Steel	H11	1.2343	SKD6	√	Die Casting Dies,Extrusion Dies, Hammer Dies, Ram Dies, Forging Dies etc.
	H13	1.2344	SKD61	√
	H10	1.2365	SKD7
	--	1.2367	--
	L6	1.2714 / 1.2713	SKT4	√
	H12	1.2606	SKD62
	H21	1.2581	SKD5	√
Cold Work Tool Steel	D3	1.2080	SKD1	√	Cutting Tools, Punching Tools, Shear Bladers, Reamers, Thread Rolling Dies, Calipers, Sockets etc.
	--	1.2601	~SKD11	√
	D2	1.2379	~SKD11	√
	--	1.2379 MOD	DC53 (Daido)	√
	D6	1.2436	--
	O1	1.2510	SKS3	√
	O2	1.2842	--
	A2	1.2363	SKD12
	S1	1.2550	--
	S7	1.2357	--
	--	1.2767	SKT6
	L2	1.2210	--
Plastic Mould Steel	P20	1.2311	--	√	Mold Base, Core & Cavity, Bumper Mold etc.
	P20+Ni	1.2738	--	√
	P20+S	1.2312	--	√
	--	1.2316	--
	420	1.2083	SUS420J2	√
	--	--	NAK80 (Daido)	√
Alloy Steel	4120	25CrMo4 / 1.7218	SCM420		Shafts, Gears, Drillers, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Crankshafts, Connecting Rods, Came, Couplings etc.
	4135	34CrMo4 / 1.7220	SCM435
	4130	34CrMo4 / 1.7220	SCM430	√
	4140	42CrMo4 / 42CrMoS4 / 1.7225	SCM440	√
	4142	41CrMo4 / 1.7223	SCM440
	4145H	--	--
	4330V	--	--
	4340	34CrNiMo6 / 1.6582	SNCM439
	5115	16MnCr5 / 16MnCrS5 / 1.7131
	5120	20MnCr5 / 20MnCrS5 / 1.7147	SMnC420H
	5140	41Cr4 / 41CrS4 / 1.7035	SCr440	√
	8620	21NiCrMo2 / 1.6523	SNCM220
	8640	40NiCrMo2-2 / 1.6546	SNCM240
	--	18CrNiMo7-6 / 17CrNiMo6 / 1.6587	--
	9840	36CrNiMo4 / 1.6511	--
	E71400	41CrAlMo7-10 / 1.8509	SACM1
	--	34CrAlNi7 / 1.8550	--
Bearing Steel	E52100	100Cr6 / 1.3505	SUJ2	√	Bearing, Shafts etc.
	--	100CrMn6 / 1.3520	--
	--	100CrMo7-3 / 1.3536	--
Spring Steel	5155	55Cr3 / 1.7176	SUP9		Springs
	6150	51CrV4 / 1.8159	SUP10
	9261	60CrSi7 / 1.7108	--
Carbon Steel	1010	CK10 / C10E / 1.1121	S10C		Shafts, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Came, Couplings etc.
	1020	C22 / 1.0402	S20C	√
	1040	CK40 / C40E / 1.1186	S40C	√
	1045	CK45 / C45E / 1.1191	S45C	√
	1050	CK50 / C50E / 1.1206	S50C	√
	1055	CK55 / C55E / 1.1203	S55C
	1064	CK60 / C60E / 1.1221	S58C
High Speed Tool Steel	M2	1.3343	SKH51	√	Reamer, End-mill, Hob, Cutter, Bite, Drill, Punch, Tap, Brooch etc.
	M7	1.3348	--
	M42	1.3247	SKH59	√
	M35	1.3243	SKH55	√
	T1	1.3355	SKH2
	T15	1.3202	--
	T42	1.3207	SKH57
