Nickel Based Alloy Inconel 690 Corrosion Resistant Steel Plates Can Be Used in Engines
US$ 2800 - 3000
MOQ: 1 Ton
Key Specifications
Get Latest Price
Type:
Stainless Steel Pipes
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Premium Corrosion-Resistant Stainless Steel Plate for Industrial DurabilityUS$ 2800 - 3000MOQ: 1 Ton -
AISI Wholesale 201/304/310/316 Round Bars With Different Diameters Stainless Steel BarUS$ 692 - 700MOQ: 1 Ton
-
Long-Lasting ASME SA778 904L DN200 18/8 Aus Cold Drawn Stainless Steel Pipe for PetroleumUS$ 2800 - 3000MOQ: 1 Ton
-
ASTM A312/A312M TP321H Stainless Steel Seamless Pipe/TubeUS$ 1200 - 1600MOQ: 1 Ton
-
Esang Ss Tube Manufacturer Handrail Polished Brushed Round 2 Inch Welded 304 Stainless Steel PipeUS$ 1200 - 1600MOQ: 1 Ton
Type
Stainless Steel Pipes
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape
Round
Grade
Other
Technique
Other
Surface Treatment
Polished
Standard
ASTM, AISI, GB, JIS, DIN, EN, Other
Specification
OEM
Trademark
ZHONGZHENG INTERNATIONAL
Origin
China
Basic Info.
Model NO.
S32750 SMLS
Grade
300 Series
Certification
ISO
Shape
Round
Technique
Cold Rolled, Cold-Drawing
Surface Treatment
Ap/Ba/Polishing/Sand Blasting/Shot Blasting
Material
Stainless Steel
Section Shape
Round
Test
Ht/Et/Ut
Delivery Time
Stock 7 Days; Mto 30 Days
Trade Terms
EXW, Fob, CFR, CIF etc.
Markings
According to A999/A999m
Transport Package
Packed in Bundles or Plywooden Box
Specification
S32750
Trademark
ZHONGZHENG
Origin
China
HS Code
7304419000
Production Capacity
2000ton Per Month
| Product Name | Seamless Stainless Steel Pipes /Tubes | |
| Company Inform | 1.Name:ZHONGZHENG STAINLESS STEEL., LTD 2.Type: Manufacturer |
|
| Material | Duplex : UNS S31803, UNS S322050, NS S32750, UNS S32760 Austenitic :TP304, TP304L, TP304H, TP309S, TP310S, TP316L, TP316Ti, TP317L, TP321, TP321H, TP347H , 904L, 254SMO GOST Grade: 08х18н10т,12х18н10т(AISI 321), 10х17н13м2т(AISI 316Ti), , 20х23н18(AISI 310S), 06хн28мдт(AISI 904L), 08х18н10(AISI304) Nickel Alloy: Incoloy: 800/800H/800HT 825 926 20 28 201 200 Inconel :718 600 601 625 Hastelloy: C-22 C-276 B-2 B-3 GH3030 GH3039 Cr20Ni80 ; Monel400,K-500 |
|
| Standard | ASTM A312,ASTM A213,ASTM A269,ASTM A511, ASTM A789,ASTM A790,EN 10216-5,DIN 17456,DIN14975,GB/T 14976,GB13296, GB5310, GB9948,GOST 9940,GOST 9941,ASTM B161,ASTM B163,ASTM B167,ASTM B407, ASTM B444,ASTM B622,ASTM B677 |
|
| Specification | Outer diameter | 6mm-630mm |
| Wall thickness | 1mm-40mm | |
| Length | Single random length/ Double random length or as customer's actual request | |
| Surface | Annealing&Pickling, Polishing180#-600#), Bright Annealing, Sand Blasting,Shot Blasting | |
| Markings | Markings will adhere to prescribed specifications in A999/A999M and shall include the NPS or OD and schedule number or average wall thickness, heat number, and NH (when hydrotesting is not performed) and ET (when eddy-current testing is performed) or UT (when ultrasonic testing is performed). The marking shall also include the manufacturer's private identifying mark, the marking requirement of section 12.3 on Hydrostatic or Nondestructive Electric Test, if applicable, and whether seamless (SML), welded (WLD), or heavily cold-worked (HCW). For Grades TP304H, TP316H, TP321H & TP347H, the marking shall also include the heat number and heat-treatment lot identification. | |
| Flattening Test | For material heat treated in a continuous furnace flattening tests shall be made on a sufficient number of pipes to constitute 5% of the lot, but in no case less than 2 lengths of pipe. | |
| Hydrostatic or Nondestructive Testing | Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test | |
| Delivery Time | 1.for ready stock :7 days after receiving the deposit of T/T 2.For MTO: 35 days after receiving the deposit of T/T |
|
| Loading Port | Ningbo/Wenzhou/Shanghai | |
| Container | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
|
| Referenced Documents | ASTM Referenced Standards A262 Practices for Detecting Susceptibility to Intergranular Attack in Austenitic Stainless Steels A370 Test Methods and Definitions for Mechanical Testing of Steel Products A941 Terminology Relating to Steel, Stainless Steel, Related Alloys, and Ferroalloys A999/A999M Specification for General Requirements for Alloy and Stainless-Steel Pipes A1016/A1016M Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stainless-Steel Tubes E112 Test Methods for Determining Average Grain Size E381 Method of Macroetch Testing Steel Bars, Billets, Blooms, and Forgings E527 Practice for Numbering Metals and Alloys in the Unified Numbering System (UNS) |
|
1. Seamless Hot Rolling Processes
Round Pipe Billet → Heating → Perforation → Three Roll Skew Rolling, Continuous Rolling or Extrusion → Off Pipe → Sizing (Or Reducing Diameter)→ Cooling → Billet → Straightening → Water Pressure Test ( Or Flaw Detection) → Marking → Storage
2. Seamless Cold Rolling (Cold drawn) Processes
Round Pipe Billet → Heating → Perforation → Head → Annealing → Pickling → Oil (Copper) → Multi Pass Drawing (Cold Rolling) → Billet → Heat Treatment → Straightening → Water Pressure Test → Marking → Storage
3. Longitudinal welding (Straight seam welding) processes
Chemical Composition For A789 S32750 Duplex Stainless Steel Pipes
| Elements | C | Cr | Cu | Fe | Mo | Mn | N | Ni | P | S | Si | W |
| Minimum | 24.0 | REMAINDER | 3.00 | 0.24 | 6.00 | 0.20 | 0.50 | |||||
| Maximum | 0.030 | 26 | 0.50 | 5.00 | 1.20 | 0.32 | 8.00 | 0.035 | 0.020 | 0.80 | 1.00 |
Mechanical Properties For A789 S32750 Duplex Stainless Steel Pipes
| 0.2% Proof Stress (N/mm2 ) [ksi] minimum | 550[79.8] |
| Ultimate Tensile Strength (N/mm2) [ksi] minimum | 800 [116] |
| Elongation (%) minimum | 25 |
| ardness (HBN) | 270 max |
| Reduction of Cross Section Area (%) | 45 |
| Charpy V-notch Impact at ambient Temp (J) [ft.lb] | 80min [59min] |
| Charpy V-notch Impact at -46°C (J) [ft.lb] | 45av, 35min [33av, 25.8min] |
| Additional Testing | |
| ASTM G48A Corrosion test at 40°C | No pitting and weight loss |
| Ultrasonic Testing | According to ASTM A388 |
| Ferrite Content | 35%-55% |
| Microstructure | Microstructure certified free from grain boundary carbides, sigma, chi and laves phases |
Physical Properties For A789 S32750 Duplex Stainless Steel Pipes
| Density (Kg.m-1) | 7810 |
| Magnetic Permeability | 33 |
| Young's Modulus (N/mm2) | 199 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 475 |
| Fracture Toughness, Kq (MPa.m) | 475 |
| Specific Electrical Resistance, 20°C (µO.m) | 0.80 |
| Thermal conductivity, 20°C (W.m-1.°K-1) | 14.2 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 11.1 x 10-6 |
ASTM A789 ASME SA789 PERMISSIBLE VARIATIONS IN DIMENSIONS
| Group | Size,Outside Diameter,in.[mm] | Permissible Variations in Outside Diameter,in.[mm] | Permissible Variations in Wall Thinckness | Permissible Variations in Cut Length,in[mm] | Thin Walled Tubes | |
| Over | Under | |||||
| 1 | up to 1/2[12.7],excel | ±0.005[0.13] | ±15% | 1/8"[3] | 0 | ... |
| 2 | 1/2" to 1-1/2"[12.7 to 38.1],excl | ±0.005[0.13] | ±10% | 1/8"[3] | 0 | less than 0.065 in.[1.6mm] nominal |
| 3 | 1-1/2" to 3-1/2"[38.1 to 88.9],excl | ±0.010[0.25] | ±10% | 3/16"[5] | 0 | less than 0.095 in.[2.4mm] nominal |
| 4 | 3-1/2" to 5-1/2"[88.9 to 139.7],excl | ±0.015[0.38] | ±10% | 3/16"[5] | 0 | less than 0.150 in.[3.8mm] nominal |
| 5 | 5-1/2" to 8"[139.7 to 203.2],incl | ±0.030[0.76] | ±10% | 3/16"[5] | 0 | less than 0.150 in.[3.8mm] nominal |
Application:
The seamless stainless steel pipes & tubes have been widely used in petrochemical, boilers, nuclear power,machinery, shipping industry and water industry, etc.
The welded steel pipes & tubes have been widely used in chemical, machinery, gas or oil transformation, shipping industry and water industry, etc.
