MVI56-MNETR PROSOFT Industrial Communication Module

MVI56-MNETR PROSOFT Industrial Communication Module thumbnail-1
MVI56-MNETR PROSOFT Industrial Communication Module thumbnail-2
MVI56-MNETR PROSOFT Industrial Communication Module thumbnail-3
MVI56-MNETR PROSOFT Industrial Communication Module thumbnail-4
MVI56-MNETR PROSOFT Industrial Communication Module photo-1
MVI56-MNETR PROSOFT Industrial Communication Module photo-2
MVI56-MNETR PROSOFT Industrial Communication Module photo-3
MVI56-MNETR PROSOFT Industrial Communication Module photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Guizhou Yuanmiao Automation Equipment Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.




MVI56-MNETR is an industrial communication module launched by ProSoft Technology, specifically designed for Rockwell Automation's ControlLogix platform. It is mainly used to realize the conversion between Modbus TCP/IP protocol and Ethernet/IP protocol. Here are its detailed information:

  • Product Overview:

    • Brand and Model: ProSoft Technology MVI56-MNETR.

    • Applicable Platform: Allen-Bradley ControlLogix 5570 and 5580 series controllers.

    • Functional Positioning: Acts as a Modbus TCP master or slave to exchange data with devices supporting Modbus protocol (such as PLCs, instruments, frequency converters, etc.) and integrate them into Ethernet/IP networks.

  • Technical Parameters:

    • Supports up to 32 concurrent Modbus connections.

    • Configurable I/O mapping table, supporting up to 4096 input registers and 4096 output registers.

    • Communication Protocols: Supports Modbus TCP/IP, RTU (encapsulated via TCP), and Ethernet/IP protocols.

    • Interface Type: 2 RJ45 Ethernet ports, supporting 10/100Mbps auto-negotiation and ring network redundancy (requires software configuration).

    • Data Transmission:

  • PROSOFT MVI56-MNETR(7)_1



    • Power Requirements: 24VDC (±10%), with a typical power consumption of 4.0W.

    • Operating Environment: Operating temperature range of -20°C to +60°C; relative humidity of 5% - 95% (non-condensing).

    • Mechanical Specifications: Approximately 120mm × 75mm × 30mm in size, weighing about 200g.

  • Product Features:

    • Protocol Conversion: Enables bidirectional data conversion between Modbus TCP and Ethernet/IP protocols, supporting multi-master and multi-slave configurations.

    • Flexible Configuration: Configurable via the built-in web interface or RSLogix 5000 software, with support for importing and exporting configuration files.

    • Redundant Design: Supports dual-network port redundancy and ring network redundancy to improve system reliability.

    • Diagnostic Function: Provides real-time communication status monitoring and fault diagnosis functions, with LED indicators showing operating status.

    • Safety Certifications: Complies with industrial safety standards such as UL, CSA, CE, and ATEX Zone 2.

  • Application Scenarios:

    • Industrial Automation: Connects PLCs, HMIs, and on-site devices of different brands to achieve system integration.

    • Energy Management: Collects data from power meters and intelligent sensors for energy monitoring and analysis.

    • Process Control: Communicates with Modbus devices to realize automatic control of production processes.

    • Device Networking: Connects traditional Modbus devices to industrial Ethernet to achieve digital transformation.


PROSOFT MVI56-MNETR(8)_1







Related products:


PROSOFT MVI56-GSC
PROSOFT MVI56-PDPS
PROSOFT PTQ-PDPMV1
PROSOFT MVI56-MNETR
PROSOFT AN-X2-AB-DHRIO
PROSOFT MVI56E-MNET






Product Tags: MVI56-MNETR , PROSOFT , Industrial communication module
