Home > Electrical & Electronics > Electrical Control System > MVI94-GSC PROSOFT Industrial Communication Module

MVI94-GSC PROSOFT Industrial Communication Module

MVI94-GSC PROSOFT Industrial Communication Module thumbnail-3

MVI94-GSC PROSOFT Industrial Communication Module thumbnail-4

MVI94-GSC PROSOFT Industrial Communication Module thumbnail-5

MVI94-GSC PROSOFT Industrial Communication Module photo-1

MVI94-GSC PROSOFT Industrial Communication Module photo-2

MVI94-GSC PROSOFT Industrial Communication Module photo-3

MVI94-GSC PROSOFT Industrial Communication Module photo-4

MVI94-GSC PROSOFT Industrial Communication Module photo-5

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Contact Supplier Request Quote Chat Now

Guizhou Yuanmiao Automation Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating temperature -40℃~+85℃

Humidity 5%~95% (non-condensing)

Many products are not on the shelves yet, please contact us for more models.

MVI94-GSC is a general-purpose serial communication module produced by ProSoft Technology, belonging to the Flex I/O series. Here are its detailed information:

Functional Features:

Protocol Conversion: Supports multiple industrial communication protocols such as RS-232, RS-422, RS-485, ASCII, and MODBUS RTU. It can convert PLC internal protocols into protocols required by serial devices, enabling seamless connection between different devices.
Data Buffering: Equipped with a data buffering function, with a buffer size of 4096 characters, which can ensure the stability and reliability of data transmission.
Automatic Detection: Supports automatic detection of device connections, which can simplify the communication configuration process in industrial automation systems.
Remote Monitoring: Supports remote monitoring and control functions. Parameter settings, program uploading, and downloading can be performed through host computer software, facilitating maintenance and management.

Technical Parameters:

Communication Interfaces: Supports RS-232, RS-422, RS-485 interfaces, which can be set via jumpers.
Baud Rate: Up to 115,200 bits per second.
Power Requirements: 9-30V DC.
Operating Temperature Range: -40°C to 85°C.
Physical Dimensions: 120mm x 80mm x 40mm.
Weight: Approximately 200g.
Installation Method: DIN rail mounting.

Product Applications:

Industrial Automation: Can connect serial devices of different brands and types, such as PLCs, sensors, and instruments, to realize the coordinated operation of industrial automation systems.
Production Line Control: Used for data exchange between serial devices in manufacturing, enabling coordination and optimization of production lines.
Process Control: Applied in process industries such as chemical plants or petroleum industries for real-time data transmission between serial devices to monitor and control production processes.
Warehousing and Logistics: Can connect and integrate serial devices in warehousing and logistics systems to realize inventory management, order processing, and logistics control.
Traffic Control Systems: Used for communication between serial devices in traffic management and control systems to realize the coordinated operation of traffic lights, signals, and monitoring equipment.
