Seamless Stainless Steel Pipe ASTM A213 316L Seamless Stainless Steel Tube

SA213 Tp316l is a specification of heat exchanger tube produced from the 316l austenitic stainless steel. Oshwin Overseas is a large supplier and manufacturer of all kinds of stainless steel pipes. The SA 213 standard covers tube for heat exchangers in ferritic and austenitic steels. The SA213 316l is a lower carbon version of the 316 material. Therefore the SA213 Tp 316l has more toughness but less strength compared to the 316 grade pipes. The SA 213 Tp 316l Tube could be produced under electric resistance weld, electric fusion weld or by cold drawing.

Supplier of ASTM A213 TP 316L ERW Tube, AISI 316L Welded Tube according to ASME SA213 / ASTM A213/ ASTM A632 / ASTM A269/ ASTM A312/ NFA 49-117 and BS 10216

The ASME SA 213 Tp 316l pipes range from ½ inches to 100 inches in diameter. The ASTM A 213 Tp 316l ERW Tube and the cold drawn seamless pipes are usually produced up to 24 inches outer diameter whereas the 316l Stainless Steel Tube through electric fusion weld are made from 6 inches to 100 inches in diameter. The 316l Stainless Steel Square Tube is used in structural applications and in high pressure applications such as the hydraulics of high temperature services. The pipes are used in high heat applications like heat exchangers and in exhausts. The 316l Stainless Steel Rectangular Tube is used along with the square tubes. The 316l Stainless Steel Seamless Tubeis applicable in sensitive and accuracy demanding applications. We provide 316l SS Tubing in electric fusion welded (EFW), 316l Seamless Tube and in 316l Welded Tube types. Our products are manufactured according to international standards and are tested to assure the quality.

SA 213 Gr 316L Tube sizes

SA 213 Gr 316L Seamless Tube

• Size: 1/2" OD - 12" OD

• OD: 3.00 - 219.10 mm

• Thickness : 0.40 - 12.70 mm

• Length: Single, Double Random & Cut Length

SS 316L Erw / Welded Tube

• Size: 1/2" - 12" OD, Guage: 25 SWG - 10 SWG

• OD: 6.35 to 114.3 mm O.D

• Thickness : 0.8 - 12.7 mm

• Length: up to 26 Meters

316L Stainless Steel Tube SpecificationCheck 316L Stainless Steel Square/ Rectangular Tube latest price list

Types of SA 213 TP 316L Stainless Steel Tube

perties, which improve high temperature resistance and corrosion resistance, then tubes should be under pickling passivation condition.
