Help CenterASME Sb622 Uns N10276 Hastelloy C-276 Hot Finished 4 Inch Schedule 20 Nickel Alloy Pipe for Gas Desulfurization Systems
Related Products
-
Good Prices C-276 Pipe ASTM B622 N10276 2.4819 Hastelloy C276 TubesUS$ 22 - 30MOQ: 100 Kilograms -
Hastelloy C-276 Reactor Coolant Pipes – ASTM B622, Uns N10276, Extreme Corrosion & Pitting Resistance High QualityUS$ 22 - 30MOQ: 100 Kilograms
-
ASME Sb622 Uns N10276 Hastelloy C-276 Seamless Hot Rolled 4 Inch Schedule 160 Nickel Alloy Pipe for Acid ProductionUS$ 5200 - 6000MOQ: 1 Ton
-
ASTM B574 Uns N10276 Hastelloy C-276 Bright Finished & Solution Treated 50 mm Diameter Nickel Alloy Bar for Power GenerationUS$ 5200 - 6000MOQ: 1 Ton
-
ASTM B574 Uns N10276 Hastelloy C-276 Cold Finished & Annealed 10 mm Diameter Nickel Alloy Bar for Chemical ProcessingUS$ 5200 - 6000MOQ: 1 Ton
Product Description
400Series:UNS N04400
600Series:UNS N06600,UNS N06601,UNS N06625
800Series:UNS N08800,UNS N08810,UNS N08811,UNS N08825
Pure Nickel Alloy Tube:UNS N02200,UNS N02201
UNS N10276,UNS N06022,UNS N06200,UNS N10665,UNS N10675
High Temperature Alloy:GH3030,GH3039
Other type Alloy:UNS N08020,UNS N08028
| Material | Nickel Alloy tube and as customized |
| Wall Thickness | 0.028inch - 0.083 inch |
| Length | 6000mm(optional:4000mm),(+/-10% possible) |
| Inside Surface Roughness |
BA grade:Ra≤0.6μm EP grade:Ra≤0.25μm |
| Size | 1/8"- 6" |
Heat Exchanger Pipe
ASTM A249 TP201/TP202/TP304/TP304H/TP310/TP36L/TP317
ASTM A554,DIN2248,JIS
1. OD: 8"-72"(DN200-DN1800)/219.1mm-1829mm
2. WT: SCH5/SCH10/SCH40/SCH80/SCH160/XXS (1.65mm-30.75mm)
3. Length: 6m or as required
4.316 Stainless steel pipes have been qualified by ISO9001 (dual-certified by IQ Net and CQM), GL, DNV, BV, ABS and PED (TUV certificate for Pressure Vessel).
5. Package: Bundles, seaworthy wooden (Plywood) boxes or according to customers' requirements.
6. Application
A) General service industries (petroleumfood chemicalpaper fertilizerfabricaviation and nuclear)
B) Fluid, gas and oil transport
C) Pressure and heat transmission
D) Boilerpressure vesselheat exchanger and condenser.
If you are really interested in our products, you can feel free to contact us directly. Your specific enquiry will be highly treated. We will quote you our most favorable price.
| Chemical composition of stainless steel | ||||||||||||
| standard name | chemical composition | |||||||||||
| ASTM | EN | GB | JIS | KS | C(carbon) | Si(silicon) | Mn(manganese) | Cr(chromium) | Ni(nickel) | S(sulfur) | P(phosphorus) | others |
| 201 | 1.4372 | 1Cr17Mn6Ni5N | SUS201 | STS201 | ≤0.15 | ≤1.0 | 5.5~7.5 | 16.0~18.0 | 3.5~5.5 | ≤0.030 | ≤0.060 | N:≤0.025 |
| 202 | 1.4373 | 1Cr18Mn8Ni5N | SUS202 | STS202 | ≤0.15 | ≤1.0 | 7.5~10.0 | 17.0~19.0 | 4.0~6.0 | ≤0.030 | ≤0.060 | N:≤0.025 |
| 301 | 1.4319 | 1Cr17Ni7 | SUS301 | STS301 | ≤0.15 | ≤1.0 | ≤1.0 | 17.0~18.0 | 6.0~8.0 | ≤0.200 | ≤0.020 | - |
| 304 | 1.4301 | 0Cr18Ni9 | SUS304 | STS304 | ≤0.08 | ≤1.0 | ≤2.0 | 17.0~19.0 | 8.0~11.0 | ≤0.030 | ≤0.035 | - |
| 321 | 1.4541 | 1Cr18Ni9Ti | SUS321 | STS321 | ≤0.12 | ≤1.0 | ≤2.0 | 17.0~19.0 | 8.0~11.0 | ≤0.030 | ≤0.035 | Ti:5C~7.0 |
| 304L | 1.4306 | 00Cr19Ni10 | SUS304L | STS304L | ≤0.03 | ≤1.0 | ≤2.0 | 18.0~20.0 | 8.0~12.0 | ≤0.030 | ≤0.035 | - |
| 309S | 1.4833 | 0Cr23Ni13 | SUS309S | STS309S | ≤0.08 | ≤1.0 | ≤2.0 | 22.0~24.0 | 12.0~15.0 | ≤0.030 | ≤0.035 | - |
| 310S | 1.4845 | 0Cr25Ni20 | SUS310S | STS310S | ≤0.08 | ≤1.0 | ≤2.0 | 24.0~26.0 | 19.0~22.0 | ≤0.030 | ≤0.035 | - |
| 316 | 1.4401 | 0Cr17Ni12Mo2 | SUS316 | STS316 | ≤0.08 | ≤1.0 | ≤2.0 | 16.0~18.0 | 10.0~14.0 | ≤0.030 | ≤0.035 | Mo:2.0~3.0 |
| 316L | 1.4404 | 00Cr17Ni14Mo2 | SUS316L | STS316L | ≤0.03 | ≤1.0 | ≤2.0 | 16.0~18.0 | 12.0~15.0 | ≤0.030 | ≤0.035 | Mo:2.0~3.0 |
Our Advantages
Customized service :
1.We are exporters and manufacturers of high-quality metal products in China.
2. We can provide a complete set of metal products for different markets.
3. We have the ability to serve customers with the most reliable quality and reasonable prices.
4. We can OEM and produce products based on the given design, and mass produce the designed goods.
5. We regularly export to buyers around the world. These products are widely popular in the market.
6. We hope to win more customers with high-quality products and reasonable prices.
