Home > Products > Steel coil sheet and plate > ASME SA240 2000mm Width Alloy 321/S32168 Heat Resistant Stainless Steel Plate

ASME SA240 2000mm Width Alloy 321/S32168 Heat Resistant Stainless Steel Plate

FOB Price

US$ 2.5 - 9 / Kilogram

100 Kilograms(Min. Order)

Payment TermsT/T L/C PayPal D/P Western Union Other
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Stainless Steel Sheets	Certification	ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape	Square	Grade	Other
Technique	Other	Surface Treatment	Polished
Standard	ASTM, AISI, GB, JIS, DIN, EN, Other	Specification	OEM
Trademark	ZHONGZHENG INTERNATIONAL	Origin	China

Product Description

stainless steel roll

Basic Info.

Model NO.

321

Certification

AISI

Shape

Flat

Technique

Cold Rolled

Surface Treatment

Bright

Transport Package

Wooden Pallet

Specification

1220*2440, 1500*3000, 1500*6000, 2000*6000mm

Trademark

ZHONGZHENG

HS Code

7219340000

Production Capacity

50000kgs

Product Description

Grade 321 / 321H Stainless Steel Sheet UNS S32100

Grade 321 / 321H Stainless Steel Sheet UNS S32100 overview

321 stainless is a titanium stabilized grade commonly used for service in the 1000-1600°F temperature range. For service temperatures up to about 1600°F, a stabilizing treatment at 1550-1650°F, air cool, may be used to provide optimum resistance to intergranular corrosion and to polythionic acid stress corrosion cracking.

321 stainless is readily welded by all common methods including submerged arc. Appropriate weld fillers are AWS ER347 bare wire and E347 covered electrodes. 321 stainless is similar in machinability to 304 stainless steel. It has a machinability rating of 45% relative to AISI B1112.

Produc Forms : Sheet, plate , Coil , Strip .wire , Pipe, Tube ,Bar , Profile, Round, Flat, Square, Hexagonal

Grade 321 / 321H Stainless Steel Sheet UNS S32100 Specification and Dimension Ranges

Grade 321/321H
ASTM A240, ASME SA240, BS EN 10028-7, BS EN 10088-2 and BS EN 10088-4
EN 10088/2, EN 10088/4 and CE Marking
NACE MR 0175/ISO 15156 Certification

Product Type	321 Stainless Steel Sheet, 321 Stainless Steel Plate
Specification	ASTM A240 / ASME SA240
Tolerances (width / thickness)	EN 10258/ DIN 59381)
	EN 10151 ASTM A240 Grade 321 Strips
	EN 10088 A240 Tp 321 strips
International Standard	ASTM A 480
	ASTM A 959
	ASME IID
	EN ISO 9445
	EN ISO 18286
	EN 10051
	EN 10088-1
	ISO 15510
Dimensions	Cold rolled 321 Stainless Steel Plate 0.5-6.4 mm
Dimensions	Hot rolled 321 Stainless Steel Plate 3.0-10.0 mm
Thickness	0.1 to 100 mm Thk
Width	10-2500mm
Length	2m, 2.44m, 3m, or as required
Finish	SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc.
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Forms / Shapes	Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate
Other Trade Name of 321 Stainless Sheet	SS 321, SUS 321, Inox 321, DIN 1.4541, UNS S32100, AISI 321, SAE 321 Sheet

Dimension Ranges:

Width: 600mm~2030 mm
Thickness: 0.1~120.0 mm
Length: 300~6000 mm , Max 18000 mm

Surface Finish: No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating,color-coating ,embossing .

Grade 321 / 321H Stainless Steel Sheet UNS S32100 ApplicationTypical applications include:

Aircraft piston engine manifolds
Expansion joints
Firearms production
Thermal oxidizers
Refinery equipment
High temperature chemical process equipment

Grade 321 / 321H Stainless Steel Sheet UNS S32100 Equivalent

AISI 321 equivalents
ASTM A182 Grade F321	ASTM A580 Grade S32100	SAE 321
ASTM A193 Grade B8T Class 1	ASTM A632 Grade TP321	JIS SUS321
ASTM A193 Grade B8T Class 2	ASTM A774 Grade TP321	JIS SUS321TPY
ASTM A193 Grade B8TA Class 1A	ASTM A778 Grade TP321	JIS SUS321TP
ASTM A194 Grade 8T	ASTM A813 Grade TP321	JIS SUS321TF
ASTM A194 Grade 8TA	ASTM A814 Grade TP321	JIS SUS321TB
ASTM A213 Grade TP321	ASTM A943 Grade TP321	EN X6CrNiTi18-10
ASTM A240 Grade S32100	ASTM A959 Grade S32100	EN 1.4541
ASTM A249 Grade TP321	ASTM A965 Grade F321	GOST 06Ch18N10T
ASTM A269 Grade TP321	ASTM F2281 Grade S32100	GOST 08X18H10T
ASTM A276 Grade S32100	ASTM F2281 Type II	GOST 12X18H10T
ASTM A312 Grade TP321	ASTM F593 Grade S32100	GB 0Cr18Ni11Ti
ASTM A313 Grade S32100	ASTM F593 Grade Alloy Group 3	UNS S32100
ASTM A314 Grade S32100	ASTM F594 Grade S32100	DIN 1.4544
ASTM A320 Grade B8T Class 1	ASTM F594 Grade Alloy Group 3	DIN 1.4544.9
ASTM A320 Grade B8T Class 2	ASTM F738M Grade S32100	AFNOR 9160/C 63
ASTM A320 Grade B8TA Class 1A	ASTM F738M Grade Alloy Group A2	AFNOR 9160C201
ASTM A336 Grade F321	ASTM F836M Grade S32100	AFNOR Z 10 CNT 18-11
ASTM A336 Grade F321H	ASTM F836M Grade Alloy Group A4	BS S524
ASTM A358 Grade A240 Type 321	DIN 1.4541	BS S526
ASTM A376 Grade TP321	DIN X6CrNiTi18-10	BS 2 S129
ASTM A409 Grade TP321	DIN X10CrNiMoTi18-10	AISI S32100
ASTM A473 Grade 321	AFNOR Z6CNT18-10	SAE S32100
ASTM A479 Grade S32100	BS 321S12	EN FE-PA 13
ASTM A511 Grade MT321	BS 321S51	EN 1.4544
ASTM A554 Grade MT321	UNI X6CrNiTi1811	GOST 08Ch18N12T
UNE F.3523	SS 2337	JIS SUSF321
		UNE F.3553

Grade 321 / 321H Stainless Steel Sheet UNS S32100 Technical datasheet

Chemical Composition
Chemical Composition (wt%) limits as specified in ASTM A240 and ASME SA240*.

Element	321
Carbon	0.08
Chromium	17.0-19.0
Nickel	9.0-12.0
Manganese	2.00
Silicon	0.75
Nitrogen	0.10
Phosphorus	0.045
Sulfur	0.030
Titanium	5(C+N) min / 0.70 max

* Maximum, unless range is indicated

Mechanical Properties
Mechanical property requirements for annealed product as specified in ASTM A240 and ASME SA240.

Property	321
Yield Strength, min. (ksi)	30
Tensile Strength, min. (ksi)	75
Elongation, min. (%)	40
Hardness, max. (Rb)	95

Physical Properties
Physical properties for Type 321 stainless steel

Property	321 Data
Density, lb/in3	0.286
Modulus of Elasticity, psi	28.0 x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F	9.2 x 10-6
Thermal Conductivity, Btu/ft hr ˚F	9.3
Specific Heat, Btu/lb ˚F	0.12
Electrical Resistivity, Microohm-in	28.4

Standards
Typical standards for Type 321 stainless steel

Property	321 Data
Density, lb/in3	0.286
Modulus of Elasticity, psi	28.0 x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F	9.2 x 10-6
Thermal Conductivity, Btu/ft hr ˚F	9.3
Specific Heat, Btu/lb ˚F	0.12
Electrical Resistivity, Microohm-in	28.4

Grade Specification Comparison

Approximate grade comparisons for 321 stainless sheets of steel are given in table 4.

Grade	UNS No	Old British	Euronorm	Swedish SS	Japanese JIS
BS	En	No	Name
321	S32100	321S31	58B, 58C	1.4541	X6CrNiTi18-10	2337	SUS 321
321H	S32109	321S51	-	1.4878	X10CrNiTi18-10	-	SUS 321H
347	S34700	347S31	58G	1.4550	X6CrNiNb18-10	2338	SUS 347

Possible Alternative Grades

Possible alternative grades to grade 321 stainless sheets of steel are given Belows

Grade	Why it might be chosen instead of 321
304L	The requirement is for resistance to intergranular corrosion, not for high-temperature strength
3CR12	Only a mild "high temperature" environment is present… up to about 600 °C.
304H	Only a mild "high temperature" environment is present… up to about 800 °C.
310	The temperature of the operating environment is up to about 1100 °C - too high for 321 or 321H.
S30815 (253MA)	The temperature of the operating environment is up to about 1150 °C- too high for 321 or 321H.

Company Profile

Zhongzheng Stainless Steel Co., Ltd.

Zhongzheng Stainless Steel Co., Ltd. is a China-based manufacturer specializing in R&D, production, and distribution of stainless steel products. Established in the early 2000s, it serves industries including construction, machinery, food/medical equipment, and energy with precision tubes, sheets, profiles, and custom components.
