Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > Manufacture ASTM A276/Uns S32750/ASTM A240 Stainless Steel Rod for Flue Gas Scrubbing Equipment Duplex Steel 2507 Bar
Manufacture ASTM A276/Uns S32750/ASTM A240 Stainless Steel Rod for Flue Gas Scrubbing Equipment Duplex Steel 2507 Bar
US$ 35 - 50
MOQ: 100 Tons
Key Specifications
Get Latest Price
Type:
Stainless Steel Bars
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Industrial-Grade Seamless Stainless Steel Pipe - ASTM Certified for Extreme Service ConditionsUS$ 1100MOQ: 1 Ton -
ASTM AISI 201 304 316 316L 430 Pickling Ba 2b Stainless Steel Seamless Welded Pipe for Building MaterialsUS$ 1200MOQ: 1 Ton
-
High-Pressure Seamless Ss Pipes - Industrial-Grade Reliability for Critical Process SystemsUS$ 1000MOQ: 1 Ton
-
GB/T 12771-2008 Welded Stainless Steel Pipe for Industrial Fluid Transportation and Structural ApplicationsUS$ 1200MOQ: 1 Ton
-
ASTM A790 S32750/2205/31803 Stainless Steel TubingUS$ 3500 - 5000MOQ: 3 Tons
Type
Stainless Steel Bars
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape
Round
Grade
Other
Technique
Other
Surface Treatment
Polished
Standard
ASTM, AISI, GB, JIS, DIN, EN, Other
Specification
OEM
Trademark
ZHONGZHENG INTERNATIONAL
Origin
China
Basic Info.
Type
Alloy Steel Bar
Standard
AISI, ASTM, GB, JIS, DIN, BS
Technique
Hot Rolled
Application
Structural Steel Bar, Tool Steel Bar, Die Steel Bar
Surface Treatment
Polished
Alloy
Non-alloy
Key Words
2507 S32750 Bar/Rod
Diameter
0.5mm-600mm
Length
as Your Requirments
Diameter Tolerance
H9, H11, H13, K9, K11, K13 etc
Sample
Free-Sample
Surface
Lack, Peeled, Polishing, Bright, Sand Blast, Hl
MOQ
100kgs
Stock
in Stock
Transport Package
Wooden Package
Specification
2507 tube
Trademark
ZHONGZHENG
Origin
China
HS Code
7218990000
Production Capacity
50000kg/Month
Product Description
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO., LTD is a special stainless steel manufacturer with 20 years of manufacturing experience.
Stainless steel Super Duplex 2507 is designed to handle highly corrosive conditions and situations were high strength is required. High molybdenum, chromium and nitrogen content in Super Duplex 2507 help the material withstand pitting and crevice corrosion. The material is also resistant to chloride stress corrosion cracking, to erosion corrosion, to corrosion fatigue, to general corrosion in acids. This alloy has good weldability and very high mechanical strength.
Duplex Stainless 2507 Applications
▪ Oil and gas industry equipment
▪ Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
▪ Chemical process industries, heat exchangers, vessels, and piping
▪ Desalination plants, high pressure RO-plant and seawater piping
▪ Mechanical and structural components, high strength, corrosion-resistant parts
▪ Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping
▪ Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
▪ Chemical process industries, heat exchangers, vessels, and piping
▪ Desalination plants, high pressure RO-plant and seawater piping
▪ Mechanical and structural components, high strength, corrosion-resistant parts
▪ Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping
2507 Standards
2507 -S32750-SAF2507-00Cr25Ni7Mo4N
2507 -S32750-SAF2507-00Cr25Ni7Mo4N
ASTM/ASME ...…. A240 - UNS S32750
EURONORM...... 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR......... Z3 CN 25.06 Az
EURONORM...... 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR......... Z3 CN 25.06 Az
Welding
2507 possesses good weldability and can be joined to itself or other materials by shielded metal arc welding (SMAW), gas tungsten arc welding (GTAW), plasma arc welding (PAW), flux cored wire (FCW), or submerged arc welding (SAW). 2507/P100 filler metal is suggested when welding 2507 because it will produce the appropriate duplex weld structure.
Preheating of 2507 is not necessary except to prevent condensation on cold metal. The interpass weld temperature should not exceed 300°F or the weld integrity can be adversely affected. The root should be shielded with argon or 90% N2/10% H2 purging gas for maximum corrosion resistance. The latter provides better corrosion resistance.
Chemical Composition
| Element | Content (%) |
| Chromium, Cr | 24 - 26 |
| Nickel, Ni | 6 - 8 |
| Molybdenum, Mo | 3 - 5 |
| Manganese, Mn | 1.20 max |
| Silicon, Si | 0.80 max |
| Copper, Cu | 0.50 max |
| Nitrogen, N | 0.24 - 0.32 |
| Phosphorous, P | 0.035 max |
| Carbon, C | 0.030 max |
| Sulfur, S | 0.020 max |
| Iron, Fe | Balance |
Mechanical Properties
| Ultimate Tensile Strength, ksi | 116 min. |
| 0.2% Offset Yield Strength 0.2%, ksi | 80 min. |
| 0.1% Offset Yield Strength 0.2%, ksi | 91 min. |
| Elongation in 2 inches, % | 15 min. |
| Hardness Rockwell C | 32 max. |
| Impact Energy, ft.-lbs. | 74 min. |
Available Sizes And Specification
| 2507/S32750 stainless steel pipe sizes and specifications | |
| Grade | 2507/S32750 |
| Stainless steel seamless pipe | Outside diameter: 4.0 - 1219mm, Thickness: 0.5 -100mm,Length: 24000mm |
| Stainless steel welded pipe | Outside diameter: 6.0 - 2800mm, Thickness: 0.3 -45mm,Length: 18000mm |
| Stainless steel capillary pipe | Outside diameter: 0.4 - 16.0mm, Thickness: 0.1 -2.0mm,Length: 18000mm |
| Stainless steel welded sanitary pipe | Outside diameter:8.0- 850mm, Thickness: 1.0 -6.0mm |
| Stainless steel seamless sanitary pipe | Outside diameter: 6.0- 219mm, Thickness: 1.0 -6.0mm |
| Stainless steel square pipe | Side Length: 4*4 - 300*300mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel rectangular pipe | Side Length: 4*6 - 200*400mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel coil pipe | Outside diameter: 0.4 - 16mm, Thickness: 0.1 - 2.11mm |
| Standard | American Standard: ASTM A312, ASME SA269, ASTM A269, ASME SA213, ASTM A213 ASTM A511 ASTM A789, ASTM A790, ASTM A376, ASME SA335, B161, SB163, SB338, SB667/668 Germany Standard: DIN2462.1-1981, DIN17456-85, DIN17458-85· European Standard: EN10216-5, EN10216-2 Japanese Standard: JIS G3463-2006, JISG3459-2012 Russian Standard: GOST 9941-81; |
40ft container:2.2mm width * 2.2m height * 11.6m Length , each container loading 25 Tons
Q3: How do you control the quality ?
A3: MTC and PMI will be sent before shipment,any 3rd party inspection if need .
Q4: How about your delivery time ?
A4: Generally delivery time is 15 working days .
Q5: How can I quickly get the price list ?
A5: Directly click "chat now" or send us email with detail specifications,you will get the official price list in 1 hour .
Q1: Do you accept the trial order ?
A1: Yes,if we have the exactly size in stock.we can delivery even 1 piece/meter .
Q2: Can I have free sample before making orders?
Q3: How do you control the quality ?
A3: MTC and PMI will be sent before shipment,any 3rd party inspection if need .
Q4: How about your delivery time ?
A4: Generally delivery time is 15 working days .
Q5: How can I quickly get the price list ?
A5: Directly click "chat now" or send us email with detail specifications,you will get the official price list in 1 hour .
