KJ2201X1-BA1 EMERSON DeltaV Series Logic Solver Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating temperature -40℃~+85℃

Humidity 5%~95% (non-condensing)

Many products are not on the shelves yet, please contact us for more models.

SLS1508 KJ2201X1-BA1.it is a logic solver module in Emerson's DeltaV series. The following is an introduction to its related information:

Logic Solving: Can execute Safety Instrumented Function (SIF) logic and respond to abnormal process conditions to ensure operational safety.
Multi-Channel I/O: Supports 16 configurable input and output channels, including discrete inputs/outputs, analog inputs (HART), and HART two-state outputs.
Redundancy Capability: Can be configured as a redundant pair to enhance fault tolerance and process availability.
Communication Function: Enables reliable data exchange via a dual-channel SISnet bus, supporting local communication within the same DeltaV controller and remote communication by connecting to separate controllers.

Power Supply: Input power is 24VDC, 1A; field power is up to 4A.
Operating Temperature: -40°C to 70°C.
Shock and Vibration Resistance: Can withstand a shock of 10g, ½ sine wave, with a duration of 11ms; vibration resistance is 1mm peak-to-peak at 5-16Hz and 0.5g at 16-150Hz.
Humidity: 5% to 95% non-condensing.
Contaminant Tolerance: Complies with ISA-S71.04-1985 standard, Grade G3 contaminants.
I/O Channels: 16 configurable channels.
Installation Method: Installed in a standard 8-slot carrier, occupying odd slots (1, 3, 5, 7); a redundant pair uses four slots.
