Basic Info.
| Products | Stainless Steel Sheet and Plate |
| Thickness | 0.3 - 40.0mm |
| Length: | 2000mm, 2438mm, 3000mm, 5800mm, 6000mm,12000mm, etc |
| Width | 40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Standard: | ASTM,AISI,JIS,GB, DIN,EN |
| Surface: | BA,2B,NO.1,NO.4,4K,HL,8K |
| Application: | It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, and ship components. It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen mesh etc. |
| Certification: | ISO, SGS,BV |
| Technique: | Cold Rolled Hot Rolled |
| Edge: | Mill Edge \ Slit Edge |
| Grade (ASTM UNS) | 201,304,304L,321,316,316L,317L,347H,309S,310S,904L, S32205,2507,254SMOS,32760,253MA,N08926,etc |
Incoloy 926 (N08926) nickel alloy is a high corrosion resistant super austenitic stainless steel containing high Cr and high Mo. It maintains good corrosion resistance in harsh environments such as high temperature, sea water or flue gas desulfurization equipment. In some cases, it is even comparable to Hastelloy and titanium.
As a highly economical stainless steel featuring high corrosion resistance, Incoloy 926 (N08926) is highly resistant to pitting and crevice corrosion in halide media and sulfur-containing hydrogen environments. Incoloy 926 is also resistant to chloride stress corrosion, with good corrosion resistance in both oxidizing and reducing media. It has excellent stability and slightly better mechanical properties than 904L, suitable to be used for pressure vessel manufacturing under temperatures from -196°C to 400 °C.
Incoloy 926 (N08926) nickel-based alloy contains 14.0-18.0% Cr and 24.0-26.0% Ni. It is a nickel-based alloy containing titanium and aluminum, with enough chromium to form and maintain a sufficient scale of chromium oxide to protect it under high temperature conditions. Incoloy 926 is more heat resistant than typical chrome-nickel stainless steel such as 304. The high nickel contained within gives it better oxidation resistance than the standard 18-8 type stainless steel. Its oxidation resistance is equivalent to (if not higher than) the higher-grade alloys used at temperatures up to 1900 degrees Fahrenheit (1038 °C).
The chemical components of grade UNS N08926 stainless steel strip is summarized in the following table:
| Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
| UNS N08926 | ASTM | ≤0.02 | ≤0.50 | ≤1.00 | ≤0.030 | ≤0.010 | 19.00-21.00 | 24.00-26.00 | 6-7 |
Main features of Incoloy 926 (N08926) nickel base alloy are listed as below.
1) Incoloy 926 (N08926) features high resistance to pitting and crevice corrosion in halide media and acidic media containing H2S.
2) It can effectively resist chloride ion stress corrosion cracking (SCC) in practical applications.
3) It is resistant to various corrosions in the usual oxidation and reduction environments.
4) It has enhanced mechanical performance in contrast to Cronifer 1925 LC-Alloy 904L.
5) It features improved metallurgical stability compared with Ni18 alloys.
6) It is certified to the application of pressure vessel manufacturing (VdTUV-196 ~ 400 °C and ASME certification).
1) Reverse osmosis seawater desalination device, seawater heat exchanger, capacitor tube, etc.;
2) Pulp and paper industry, various bleaching devices, etc.;
3) Resin production device, reaction containers for drugs, piping, etc.;
4) Firefighting systems, seawater purification systems, hydraulic and perfusion piping;
5) Systems in marine engineering;
6) Hose system in marine engineering;
7) Pipes, joints, airflow systems, etc. in the production of acid gases;
8) Parts in flue gas desulfurization systems;
9) Evaporators, heat exchangers, filters, mixers, etc. in the production of phosphoric acid;
10) Sulfuric acid separation and condensation system;
11) Cooling-water pipe systems in Power plant;
12) Storage tank for corrosive chemical transportation;
13) Halogen acid catalyzed organic production equipment;
14) Others.
