24 Inch Diameter 1.65mm Thickness Stainless Steel A312 Pipe
US$ 1600
≥1 Ton
Key Specifications
Get Latest Price
Type:
Stainless Steel Pipes
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI/WENZHOU/TIANJIN
Delivery Detail:
10 days
Related Products
-
ASTM B407 UNS N08810 Alloy 800H Incoloy 800H Seamless Nickel Alloy Tube Pipe PriceUS$ 500 - 1500MOQ: 1 Ton -
N08810 Incoly718 Gh4169 Nickel Alloy 304 Stainless Steel Seamless Pipe for Pipeline TransportationUS$ 2600 - 5900MOQ: 1 Ton
-
Great Quality304 316 321 201 314 310 2205 Stainless Steel Pressure Bearing Tube Industrial Grade Seamless Pipe ASTM GB En AISI JIS DIN ISOUS$ 2000MOQ: 2 Tons
-
Steel Seamless Stainless Steel Pipe 08X18h10/12X18h10t (AISI304, AISI321) , 10X17h13m2t (AISI316Ti) Cold-Formed+Heat Treatment, Customized SizeUS$ 800 - 1100MOQ: 1 Ton
-
304 Grade TIG Welded Stainless Steel Industrial Pipe for DischargeUS$ 1900MOQ: 1 Ton
Type
Stainless Steel Pipes
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Shape
Round
Grade
300 Series
Technique
Cold-Drawing
Surface Treatment
Pickling
Standard
ASTM, AISI, GB, JIS, DIN, EN
Transport Package
Woven Bag Wooden Box
Origin
CHINA
Product Description
What you are looking for is
24 Inch Diameter 1.65mm Thickness Stainless Steel A312 Pipe
If you are still suffering from the inconvenience caused by the corrosion and cracking of the pipeline, or you are suffering from the failure to find a suitable stainless steel industrial tube supplier. Please read the following content in 3 minutes. I hope it can be helpful for you.
24 Inch Diameter 1.65mm Thickness Stainless Steel A312 Pipe
If you are still suffering from the inconvenience caused by the corrosion and cracking of the pipeline, or you are suffering from the failure to find a suitable stainless steel industrial tube supplier. Please read the following content in 3 minutes. I hope it can be helpful for you.
Basic Info.
Model NO.
YLGD-IP-153
Grade
300 Series
Certification
ISO, GB, EN, TUV, SGS, EN 10204 3.1
Shape
Round
Technique
Welded
Surface Treatment
No.1,No.4,2b,Ba,Hl,8K,Polish,Pickling
Outer Diameter
16mm - 2000mm
Thickness
0.8mm - 20mm
Length
5.8m - 18.3m
MOQ
2 Tons
Visit Our Factory
Welcome
Transport Package
Woven Bag; Wooden Box;
Trademark
Yaolong
Origin
Foshan or Nantong
HS Code
7326909000
Production Capacity
150 Ton Per Month
| Material | Stainless Steel 304/304L/316/316L |
| Shape | Round |
| Production Standards | ASTM A269, ASTM A312, ASTM A778, EN 10217-7, JIS G3459 and so on. |
| Size | Outer diameter = 16 - 2000mm ; Thickness = 0.8 - 20 mm ; Length = 6 - 18.3 meter ; Or as customer' s request. |
| Tolerance | According to the Standard , +/-10% Commonly ; |
| Surface Treatment | Mill Finish; Bright Anneal; Pickle |
| Process Characteristics | Inner Welded Seam Removed ; Online Bright Solution Anneal ; Inner Electro Polish And Mechanical Polish ; |
| Application | Paper Mill; Carton Factory; Purification Equipment Factory; Chemical Industry; Waste Gas Discharge; Sewage Treatment Plant and so on. |
| Test | Squash Test; Extended Test; Water Pressure Test; Crystal Rot Test; Heat Treatment; NDT |
| Design | OEM / ODM / Customized |
| Certificate | ISO9001:2015; AD 2000Merkblatt W0; PED 2014/68/EU; SGS |
| ASTM A312/ASTM A778 Specification | ||||||
| Nomina Diameter | Outside Diameter | Nomina Wall Thickness | ||||
| mm | inch | mm | SCH 5S | SCH 10S | SCH 20S | SCH 40S |
| 350 | 14 | 355.6 | 3.96 | 4.78 | 7.92 | 11.13 |
| 400 | 16 | 406.4 | 4.19 | 4.78 | 7.92 | 12.7 |
| 450 | 15 | 457.2 | 4.19 | 4.78 | 7.92 | 14.27 |
| 500 | 20 | 508.0 | 4.78 | 5.54 | 9.53 | 15.09 |
| 550 | 22 | 558.8 | 4.78 | 5.54 | 9.53 | 15.09 |
| 600 | 24 | 609.6 | 5.54 | 6.35 | 9.53 | 17.48 |
| 650 | 26 | 660.4 | 5.54 | 7.92 | 12.7 | 17.48 |
| 700 | 28 | 711.2 | 5.54 | 7.92 | 12.7 | 17.48 |
| 750 | 30 | 762.0 | 6.35 | 7.92 | 12.7 | 17.48 |
| 800 | 32 | 812.8 | 7.92 | 12.7 | 17.48 | |
| 850 | 34 | 863.6 | 7.92 | 12.7 | 17.48 | |
| 900 | 36 | 914.4 | 7.92 | 12.7 | 19.05 | |
| 1000 | 40 | 1016.0 | 9.53 | |||
| Dimension Tolerance Table | ||||
| Standard | Outside diameter(mm) | Thickness(mm) | Length(mm) | |
| ASTM A312 | ≤48.26 | +0.40 -0.80 | +unspecified -12.50% | Definite cut lenght +6.40 -0 |
| >48.26~114.30 | +0.80 -0.80 | |||
| >114.30~219.08 | +1.60 -0.80 | |||
| >219.08~457.20 | +2.40 -0.80 | |||
| >457~660 | +3.20/ -0.80 | |||
| >660~864 | +4.00/ -0.80 | |||
| >864~1219 | +4.48/ -0.80 | |||
| EN 10217-7 | D1±1.50% with ±0.75mm(min) D2±1.00% with ±0.50mm(min) D3±1.75% with ±0.30mm(min) D4±0.50% with ±0.10mm(min) EN ISO 1127 |
T1±15.00% with ±0.60mm(min) T2±12.5% with ±0.40mm(min) T3±10.00% with ±0.20mm(min) T4±7.50% with ±0.15mm(min) T5±5.00% with ±0.10mm(min) EN ISO 1127 |
≤6000: +5.00 -0 6000~12000: +10.00 -0 |
|
