304 Grade TIG Welded Stainless Steel Industrial Pipe for Discharge
US$ 1860
≥1 Ton
Key Specifications
Get Latest Price
Type:
Stainless Steel Pipes
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI/WENZHOU/TIANJIN
Delivery Detail:
10 days
Related Products
-
316/316L 022Cr17Ni12Mo2 Stainless Steel Seamless Pipe for Industrial Grade Strength and ResistanceUS$ 1650MOQ: 1 Ton -
ASTM A312m Hot Rolled S31803 DN80 Sch40 Super Duplex 2507 Square/Round Tubes 321 Stainless Steel Pipes PriceNegotiableMOQ: 1 Ton
-
Super Duplex Stainless Steel Pipes for The Mechanical/Chemical Industries/MiningUS$ 1600 - 1900MOQ: 1 Ton
-
Stainless Steel Seamless Tube GOST 9941-91, DIN 17456, DIN 17458, En10216-5, ASME SA213 Pickled and Annealed Plain EndUS$ 1870MOQ: 1 Ton
-
ASTM AISI A312 Super Stainless Steel Welded Pipe Inox Tube DN8mm-DN2000mm 904L 254smo Al6xn 1.4529 654smo (welcome to Visit Us)US$ 2400 - 9000MOQ: 1 Ton
Type
Stainless Steel Pipes
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Shape
Round
Grade
300 Series
Technique
Cold-Drawing
Surface Treatment
Pickling
Standard
ASTM, AISI, GB, JIS, DIN, EN
Transport Package
Woven Bag; Wooden Box;
Origin
CHINA
| Material | Stainless Steel 304/304L/316/316L |
| Shape | Round |
| Production Standards | ASTM A269, ASTM A312, ASTM A778, EN 10217-7, JIS G3459 and so on. |
| Size | Outer diameter = 16 - 2000mm ; Thickness = 0.8 - 20 mm ; Length = 6 - 18.3 meter ; Or as customer' s request. |
| Tolerance | According to the Standard , +/-10% Commonly ; |
| Surface Treatment | Mill Finish; Bright Anneal; Pickle |
| Process Characteristics | Inner Welded Seam Removed ; Online Bright Solution Anneal ; Inner Electro Polish And Mechanical Polish ; |
| Application | Paper Mill; Carton Factory; Purification Equipment Factory; Chemical Industry; Waste Gas Discharge; Sewage Treatment Plant and so on. |
| Test | Squash Test; Extended Test; Water Pressure Test; Crystal Rot Test; Heat Treatment; NDT |
| Design | OEM / ODM / Customized |
| Certificate | ISO9001:2015; AD 2000W0; PED 2014/68/EU; SGS |
| ASTM A312/ASTM A778 Specification | ||||||
| Nomina Diameter | Outside Diameter | Nomina Wall Thickness | ||||
| mm | inch | mm | SCH 5S | SCH 10S | SCH 20S | SCH 40S |
| 350 | 14 | 355.6 | 3.96 | 4.78 | 7.92 | 11.13 |
| 400 | 16 | 406.4 | 4.19 | 4.78 | 7.92 | 12.7 |
| 450 | 15 | 457.2 | 4.19 | 4.78 | 7.92 | 14.27 |
| 500 | 20 | 508.0 | 4.78 | 5.54 | 9.53 | 15.09 |
| 550 | 22 | 558.8 | 4.78 | 5.54 | 9.53 | 15.09 |
| 600 | 24 | 609.6 | 5.54 | 6.35 | 9.53 | 17.48 |
| 650 | 26 | 660.4 | 5.54 | 7.92 | 12.7 | 17.48 |
| 700 | 28 | 711.2 | 5.54 | 7.92 | 12.7 | 17.48 |
| 750 | 30 | 762.0 | 6.35 | 7.92 | 12.7 | 17.48 |
| 800 | 32 | 812.8 | 7.92 | 12.7 | 17.48 | |
| 850 | 34 | 863.6 | 7.92 | 12.7 | 17.48 | |
| 900 | 36 | 914.4 | 7.92 | 12.7 | 19.05 | |
| 1000 | 40 | 1016.0 | 9.53 | |||
| Dimension Tolerance Table | ||||
| Standard | Outside diameter(mm) | Thickness(mm) | Length(mm) | |
| ASTM A312 | ≤48.26 | +0.40 -0.80 | +unspecified -12.50% | Definite cut lenght +6.40 -0 |
| >48.26~114.30 | +0.80 -0.80 | |||
| >114.30~219.08 | +1.60 -0.80 | |||
| >219.08~457.20 | +2.40 -0.80 | |||
| >457~660 | +3.20/ -0.80 | |||
| >660~864 | +4.00/ -0.80 | |||
| >864~1219 | +4.48/ -0.80 | |||
| EN 10217-7 | D1±1.50% with ±0.75mm(min) D2±1.00% with ±0.50mm(min) D3±1.75% with ±0.30mm(min) D4±0.50% with ±0.10mm(min) EN ISO 1127 |
T1±15.00% with ±0.60mm(min) T2±12.5% with ±0.40mm(min) T3±10.00% with ±0.20mm(min) T4±7.50% with ±0.15mm(min) T5±5.00% with ±0.10mm(min) EN ISO 1127 |
≤6000: +5.00 -0 6000~12000: +10.00 -0 |
|
"The pursuit of quality is our persistence"
We chose austenitic stainless steels from BAOSTEEL or TISCO as raw materials. Because these raw materials have high-quality properties, the effects after surface treatment will be more diversified. Pickling, polishing, mirror polishing, satin brushing, powder coating, you can choose the effect you want according to actual needs, we will try our best to help you complete.
"Stainless steel industrial pipes with a outer diameter of 21.60mm to 1016mm meters can meet 80% of the market requirements"
The outer diameter range of the stainless steel industrial tubes that our company has currently made is 15.88 mm to 2000 mm, if you need a bigger one, we can also complete it.
"The products we do the most are round pipes , rectangular pipes and square pipes. In this respect, our production line and workmanship are very mature."
If you need a profiled tube, please consult us with engineering drawings with parameters. Our engineers will analyze the technical difficulties and discuss cooperation plans with you.
