Forever reinforcing bar heat line is for the high-end market with reasonable price,the details is showing that:
1. No matter what is induction coil or wiring, there is a protective shell to protect, which is safe and beautiful;
2. Intelligent control system to protect the equipment working – water, lack of phase, overcurrent and other protection settings;
3. Water-cooled system with air-cooled design can get better cooling effect for long-term use.
Forever reinforcing bar heat line technical details
1.All the circuit is digital, and all parameters can be set and modified in the touch screen or remote devices with high reliability, anti-interference ability, fast response and so on.
2.According to different diameter of reinforcing bars, Forever will design different induction heater. Wide range can meet wide range of reinforcing bars heat treatment to get higher heating efficiency. The length of induction heaters for tempering is longer than induction heater for quenching, which can make deformed bars get uniform and better induction heat treating effect. The internal structure will be uniform and stable ensure that the reinforcing bars performance to meet the requirements.
3.The pressure roller and the rollers between each induction heating coils are made of 304 non-magnetic stainless steel, inclined and water cooling, greatly extending the life of the roller.
4.Forever new design of adopting ceramic roller can reduce the deformed bars wear and no burning during reinforcing bars running on the roller table.
5.The reinforcing bars hardening and tempering line spray system is using multi-stage stainless steel water ring, and the pressure and flow of the water ring can be automatically adjusted to meet the requirements of different hardenability.
6. The reinforcing bars after hardening and tempering doesn’t need straightening, no bending and no deformation. So the customer doesn’t need to buy special straightening machine.
| Steel bar diameter | Automatic Control | Power Design |
| Ø10-Ø28 mm | IPC Control | KGPS350KW Quenching+KGPS160KW Tempering |
| Ø42-Ø48 mm(Anchor Bolt) | PLC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø30-60 mm | IPC Control | IGBT250KW Quenching+IGBT160KW Tempering |
| Ø30-Ø60 mm | PLC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø35-Ø60 mm | IPC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø30-Ø110 mm | IPC Control | KGPS400KW Quenching+KGPS400KW Tempering |
| Ø80-Ø110 mm | PLC Control | KGPS600KW Quenching+KGPS160KW Tempering |
| Pipe diameter | Automatic control | Power design |
| Ø95，Ø114 mm | PLC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø73.2,Ø88.9,139.7 mm(Drill pipe) | IPC Control | KGPS500KW Quenching+KGPS100KW Tempering |
| Ø30-Ø60 mm | PLC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø35-Ø60 mm | IPC Control | KGPS250KW Quenching+KGPS160KW Tempering |
| Ø30-Ø110 mm | IPC Control | KGPS400KW Quenching+KGPS400KW Tempering |
| Ø80-Ø110 mm | PLC Control | KGPS600KW Quenching+KGPS160KW Tempering |
Overseas manager: Tom Wang
Email:tom@foreverfurnace.com
Phone: 0086-13303078975(whatsapp, wechat,line)
Specialist of induction heating equipment and system in China; Glad to be your business partner in induction heating field.
