Stationary manual Fire Monitor YAPS20-40 can be installed on the fire pipelines of various fire trucks, fire boats and large storage docks.
The monitor/fire fighting cannon has a compact design structure, beautiful appearance, concentrated jet flow, adjustable flow rate, direct current spray and other kinetic energy conversion, especially the horizontal rotation and gun head pitch are driven by worm and worm gear, which is extremely light and stable when working. With its Self-locking function, high safety factor, high quality foam could be produced with a special foam tube. it is an ideal product for fire fighting.
The monitor/fire fighting cannon has a compact design structure, beautiful appearance, concentrated jet flow, adjustable flow rate, direct current spray and other kinetic energy conversion, especially the horizontal rotation and gun head pitch are driven by worm and worm gear, which is extremely light and stable when working. With its Self-locking function, high safety factor, high quality foam could be produced with a special foam tube. it is an ideal product for fire fighting.
Stationary Manual Fire Monitor water cannons PS20-40 Technical data
| Model | PS20-40 |
| Working pressure | 0.8Mpa |
| Flow | 20-30-40L/S |
| Shooting distance | ≥65m |
| Tolerance | ±10% |
| Horizontal Angle | 0~360° |
| Vertical Angle | -45°~+75° |
| Max Fog Angle | 120° |
| Material | Head: Aluminium Alloy |
| Weight | 11KG |
| Inlet size | DN80（GB/T 9112~9124-2010； PN16） |
