Home > Products > Axial Fan > 200 Circular Single-Flange AC Axial Fan 230V 400V Cabinet Heat Dissipation Welding Machine Smoke Exhaust Fan
200 Circular Single-Flange AC Axial Fan 230V 400V Cabinet Heat Dissipation Welding Machine Smoke Exhaust Fan
US$ 15
1 - 499 Pieces
US$ 14
≥500 Pieces
- shanghai
- T/T L/C PayPal Western Union Other
- 20 days
You May Like
-
200 Single-Flange External Rotor AC Axial Fan 230V 380V Cabinet Cooling Fan
-
200 Single-Flange External Rotor AC Axial Fan 230V 380V Cabinet Cooling Fan
-
250fzy-D 230V 400V 1300RPM Industrial Frequency Axial Flow Fan for Industrial Air Suction Type Small AC Cooling Fan
-
250fzy-D 230V 400V 2500RPM Industrial Frequency Axial Flow Fan for Industrial Air Suction Type Small AC Cooling Fan
-
Square Fan Motor 250mm 1300rpm 230V 400V AC Industrial Ventilation Exhaust Axial Flow Air Cooling Radiator Fan
-
250fzy-DA 230V 400V 2500RPM Industrial Frequency Axial Flow Fan for Industrial Air Suction Type Small AC Cooling Fan
Product Details
| Brand Name | surke | Place of Origin | China | |
| Model Number | 200FZY22-D | Certification | CCC, CE, ROHS | |
| Voltage | 230/400V | Power | 65W | |
| Speed | 2600r/min | Air Volume | 1020m³/h | |
| Blade Material | Cast Iron | Mounting | Duct Fan | |
| Electric Current Type | AC |
Product Description
This series of fans consists of a metal double flange cylindrical shell, an AC asynchronous motor with an inner or outer rotor, and plastic or metal blades. Its products have the characteristics of high air volume, low noise, low vibration, reliable operation, easy installation, and long service life. The modified series of fans are mainly used for ventilation and heat dissipation in industries such as computer systems, ground automation equipment, electronic instruments, office automation equipment, medical equipment and welding machines, cabinet heat dissipation, and photovoltaic new energy.
Usage environment:
Environmental temperature:- 10ºC~+40ºC(H) -20ºC~+55ºC(G)
Air pressure: 74.8KPa (H) 55KPa (G)
Bearing structure: H-oil bearing G-ball bearing
