160mm AC Forward Curved Centrifugal Fan for Extractor Hood
US$ 22
≥1 Pieces
- shanghai
- T/T L/C PayPal Western Union Other
- 20 days
You May Like
-
180mm Ac Stable and Efficient Centrifuge Air Blower Fan
-
180× 180× 60mm Ball Bearing Fan Round 18060 Fan AC 230V Electronics Cooling Motor for Industrial Machinery Systems Computers
-
220X220X60mm Ball Bearing Fan Round 22060 Fan 220V Electronics Cooling Motor for Industrial Machinery HVAC Systems Computers
-
15050 Industrial Cooling Fan 150mm Vending Machine 230V 120V 150X150X50mm AC Axial Flow Fans
-
High Efficiency Axial Fan AC Fan 110V 230V 400V 50/60Hz for Energy Storage (K-AC13532-Series) Industrial Axial Exhaust Cooling Fan
-
110*110*25mm Square Fan Motor 11025 Industrial AC 110V 230V 400V Axial Exhaust Cooling Fan110V 230V 400V
Product Details
| Brand Name | surke | Place of Origin | China | |
| Model Number | 160FLQ | Certification | CCC, CE | |
| Voltage | 230/400V | Power | 127W | |
| Speed | 2500r/min | Air Volume | 550m³/h | |
| Blade Material | Cast Iron | Mounting | Duct Fan | |
| Electric Current Type | AC |
Product Description
FLQ and FLJ Series
The FLQ centrifugal fans use external rotor or internal rotor AC asynchronous motors, or DC and EC external rotor motors. They are designed with multi-vane forward-curved centrifugal impellers. They have the characteristics of compact structure, small size, high efficiency, large air volume, and high static pressure. The FLJ series is designed with a matching volute on the basis of the FLQ series, making the product installation more convenient! It is widely used in the ventilation and heat dissipation of ground control facilities and electronic equipment, pipeline dust removal, exhaust air discharge, heat dissipation of air purification equipment in the fresh air system, inflatable dolls, blow molding machinery, smoke machinery, drying equipment, kitchen equipment, etc., with a wide range of applications.
Operating Environment:
Ambient temperature: -10°C～+40°C (H), -20°C～+55°C (G)
Atmospheric pressure: 74.8KPa (H), 55KPa (G)
Relative humidity: 90%-95%
