Semi Automatic Stitch Box Machinery

Semi Automatic Stitching Machine

♦ Mitsubishi dual servo drive, precision, mechanical transmission part reduction. can effectively reduce the mechanical failur rate.

♦ weilun touch screen operation, parameters (nail distance, nail number, nail type, backboard) easy to change.

♦ the whole control system adopts Japanese omron PLC control system

♦ rear electric baffle, driven by stepping motor, accurate size, more convenient and fast size conversion.

♦ the full contactor in the control box adopts the brand of Siemens.

♦ relays are all made by schneider.

♦ photoelectric and proximity switches adopt Japanese omron brand.

♦ bottom die, the blade is made of Japanese tungsten steel (wear-resisting).

♦ the whole set of nail head are all made of special steel, computer gong precision processing.

♦ single stitching/, double stitching//, reinforcing stitching(// // // /double stitching at both ends and single stitching at the middle part)can be finished in one time, which can meet different requirements of different customers.

♦ it only takes one minute to change the carton size and adjust the carton stitching distance, which greatly saves time and is convenient to operate.

♦ the front feeding part is automatically counted, and the feeding table is equipped with photoelectric induction device, which automatically rises when feeding.

♦ the back section is equipped with automatic counting function, and the finished pieces can be stacked and sent to the end of the transmission machine according to the set quantity(2-99), which is convenient for packing and binding

♦ electric adjustment of the clearance of the paper press rubber wheel.

♦ machine order type adjustment, can store 100 orders.

♦ protection function of isolating transformer for the whole machine;

♦ automatic wire feeding svstem, 20KG flat wire, save time.

♦ front and rear two-way baffle configuration,can order lideless carton and small cardboard box. color box.
