Recycling Washing Tank Machine Washing Line Small Floating Tank for ABS PET PP PE

Standard transport package

Plastic sink and float tank

Working principle

Put the plastic material into the front end of the rinsing tank, the rinsing wheel rotates to drive the material rinsing and forward, under the action of the reducer, the bottom screw pushes the material to clean while feeding. Because the density of different plastics is different, it will naturally sink and float in the sink, so as to achieve separation, such as PET is a sinking material, and the beverage bottle cap is a floating material, which can be separated in this way.

Structural characteristics

 Material: Mostly made of high-quality stainless steel or carbon steel material, stable and durable, corrosion resistant, such as the use of bearing external design, can avoid long-term contact with water immersion caused by corrosion.

 style: single screw and twin screw two kinds of structure, can be used with the whole assembly line can also be used alone.

 Internal components: usually equipped with rinsing wheel, spiral blade, material plate, dredge machine, drainage screen, drainage valve, etc., the bottom can also be equipped with spiral charging machine, convenient for quick separation of sinking and floating materials.

Functional advantage

 separation and cleaning: suitable for rinsing pp, pe, pet and other sheets, can automatically separate bottle caps and other floating debris, effectively separate the sand and paper in various sheet materials, remove the cleaning agent, stain, glue and dust on the bottle sheet, make the broken sheet cleaner and whiter.

 Cycle filtration: The cycle filtration system is comprehensively upgraded to improve the filtration and precipitation efficiency, ensure the recycling of cleaning agents, save the amount of cleaning agents and water consumption, and reduce secondary pollution.

 Safety protection: equipped with anti-sound partition, which can effectively prevent shock and reduce noise, the motor is equipped with over-load protection device, and the power supply chain protection system, the operation is safer.

 Non-standard customization: Supports non-standard customization, and can accurately match the width, length, height and power according to the actual needs of customers' projects to meet different production and process requirements.

Application field

Mainly used in plastic recycling industry, widely used in ABS, PS separation and PET bottle recycling cleaning process, is the plastic broken sheet, block plastic cleaning, multi-material material mixed sorting and cleaning necessary equipment.

About us

Dongguan Xinbao Machinery Co., Ltd. is a set of independent development and design, manufacturing, sales, maintenance, plastic machinery equipment, plastic, chemical, food mixing equipment as the main production enterprises. Our company mainly produces and sells: Automatic powder/liquid mixer (feeding, mixing, filling one), stainless steel mixer, chemical reaction kettle, electric heating mixing tank, high-speed dispersing machine, high-speed emulsifying machine, horizontal mixer, vertical mixer, color mixing machine, weighing and baling machine, spiral feeding machine, suction machine, belt conveyor, centrifugal dewatering machine, plastic friction machine, grinder, a whole set of plastic cleaning equipment Side auxiliary equipment.

Through more than 10 years of market training and experience accumulation, our company has cultivated a group of highly skilled welding, design, sales and after-sales teams. With advanced production equipment, high-level management mode and humanized pre-sales and after-sales service, we have won the high trust and recognition of new and old users. The products are sold in China and nearly 30 provinces, cities and autonomous regions, as well as exported to foreign countries such as Africa and Southeast Asia, and we are dedicated to win-win cooperation with domestic and foreign businesses. Warmly welcome friends from all walks of life to visit, guidance and business negotiations.
