TF-5080B Ophthalmic Equipment Adjustable Eye Test Lens Trial Frame for Sale
US$ 20 - 30
/ Piece
1 Piece(Min. Order)
- China
- T/T
You May Like
-
TF-5470A Ophthalmic Equipment Adjustable Eye Test Lens Trial Frame for Sale
-
High Quality Universal Optical Trial Frame Material Titanium TF-5080 for Sale
-
Optometry Equipment TF-C Optical Lens Frame Low Price
-
TF-P Optical Instrument Optometry Eye Training Optician Child Universal Trial Lens Frame Ophthalmic Test Tool 52-70mm Low Price
-
Optical Instrument Eye Vision Test Children Trial Frame for Sale RB-307
-
New 5pc TF-X Plastic Optical Trial Frame Set Ophthalmic Trial Lens Frame 52-70mm Optional PD Grey Color
Product Description
Features:
1. Range of PD adjustments:PD of both eyes:50~76mm;
Left or right PD:24~40mm,Minimum Calibration Value:1mm.
2. Axial calibration on each disc:
Left disc:120°~0°~135°,Right disc:45°~180°~60°,
Axial calibration increases counter clockwise along the lens frame axis, and the calibration distance is 5.
3. Inner diameter of lens frame:Φ38mm
4. The Number of lens which can be inserted into left or right lens frame simultaneously:4 pieces
5. Degree of lens rotating around optical axis in the lens frame:360°
6. Non-parallelism degree between lens' optical axis and lens frame's geometric axis:≤2.5°
7. Non-concentricity between lens' optical center and lens frame geometric center:≤0.5mm
8. Displacement of lens in relation to position of lens frame geometric center:≤0.3mm
9. Range of nose pad adjustment:Length:0~14mm,Angle:0°~30°
10. Range of left or right lens frame leg's length adjustment:98mm~135mm
11. Maximum interval between left and right lens frame legs:200mm
Left or right PD:24~40mm,Minimum Calibration Value:1mm.
2. Axial calibration on each disc:
Left disc:120°~0°~135°,Right disc:45°~180°~60°,
Axial calibration increases counter clockwise along the lens frame axis, and the calibration distance is 5.
3. Inner diameter of lens frame:Φ38mm
4. The Number of lens which can be inserted into left or right lens frame simultaneously:4 pieces
5. Degree of lens rotating around optical axis in the lens frame:360°
6. Non-parallelism degree between lens' optical axis and lens frame's geometric axis:≤2.5°
7. Non-concentricity between lens' optical center and lens frame geometric center:≤0.5mm
8. Displacement of lens in relation to position of lens frame geometric center:≤0.3mm
9. Range of nose pad adjustment:Length:0~14mm,Angle:0°~30°
10. Range of left or right lens frame leg's length adjustment:98mm~135mm
11. Maximum interval between left and right lens frame legs:200mm
