Pyrolysis Machine Recycle Tyre Rubber Powder To Fuel Oil Pyrolysis Plant Scrap Tire Pyrolysis Reactor

Name: Pyrolysis Machine Recycle Tyre Rubber Powder To Fuel Oil Pyrolysis Plant Scrap Tire Pyrolysis Reactor
Brand: DOING
Availability: InStock

FOB Price

US$ 58000 - 78000 / Set

1 Set(Min. Order)

Port qingdao
Payment TermsT/T L/C D/P D/A Other

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DOING	Place of Origin	China
Model Number	DY-C-20-50 TPD	After-sales Service Provided	Overseas service center available
Warranty	one-year service guarantee	Certification	SGS/ISO/CE
Condition	New

Product Description

DOING Pyrolysis Machine | Factory supply | Latest technology

Products Description

DOING COMPANY PYROLYSIS PLANT

The continuous type and batch type pyrolysis plants designed by Doing Company’s engineer team have been exported to the United States, the United Kingdom, France, Italy, Australia, Dubai, Brazil, Kazakhstan, Pakistan, India, Nigeria, Mexico, Egypt, Thailand and other 90+ countries and regions. Their outstanding economic and environmental benefits have led the development of the waste tire/plastic/oil sludge/rubber/aluminum plastic composite material pyrolysis industry.

Product Paramenters

Scheme 1: New design continuous type pyrolysis plant

Scheme 2: Cost-effective batch type pyrolysis plant

Scheme 3: Free installation small scale pyrolysis plant unit

Items	Waste Pyrolysis Plant
Equipment type	DY-100-6	DY-1-10-12	DY-1-15-50
Raw material	Waste plastics, tyres	Waste plastics, tyres	Waste plastics, tyres
Structural form	Horizontal rotation	Horizontal rotation	Horizontal rotation
24-hour Capacity	100kg-6 ton	10-12 ton	15-50ton
Oil yield	0.45-3.3ton	4.5 -7.2ton	6.7-30ton
Operating pressure	Normal	Normal	Normal
Material of pyrolysis Reactor	Q245R	Q245R	Q245R
Thickness of pyrolysis Reactor	16mm	16mm	16mm
Rotate speed of pyrolysis Reactor	0.4turn/minute	0.4turn/minute	0.4turn/minute
Total power	15KW	15KW	65KW
Mode of cooling	Water cooling	Water cooling	Water cooling
Cooling area of condenser	100sqm	100sqm	100sqm
Kind of transmission	Internal gear drive	Internal gear drive	Internal gear drive
Noise dB(A)	≤85	≤85	≤85
Size of Reactor(D×L)	2200×6000	2600×6600	2800×6600
Working form	Intermittent operation	Intermittent operation	Intermittent operation
Delivery time	20days	20days	20days
Weight	Depends on the Scales	32T	35T

Recommend Products

Project Case

Customer Feedback

Our services

Company Profile

00:00

00:45

DOING HOLDINGS CO., Ltd

Henan Doing Environmental Protection Technology Co., Ltd, the subsidiary company of Doing Holdings Co., LTD, is a comprehensive environmental equipment manufacturer integrating technological design, research and development, machine production, sales and after-sales service in one. Relying on excellent technical R&D strength and innovative spirit, our company has won up to 23 new utility patents and invention patents. And our company is honored as the National High Technology Enterprise awarded by the Municipal Science and Technology Commission.Our main business: solid waste and hazardous waste treatment equipment, waste rubber tire /plastic/oil sludge/coal tar/aluminum plastic pyrolysis plant, pyrolysis oil/waste/crude oil to diesel distillation plant, other tire recycling machines, and related environmental protection devices. Now, our products sell well in 100+ countries and regions around the world.

FAQ

Q: How much a waste pyrolysis plant?A: Different capacity of tyre pyrolysis plants have different cost. And also different desgins of tyre pyrolysis plants have different cost. But if you want to save some cost, our engineer also can design the most efficient machine solutions for you. To caculate detailed cost for your referrence , please contact us directly.Q: How can I sell the tyre pyrolysis oil and plastic oil?A: The good sales, because oil is an energy, hotels, restaurants, bath center, diesel stoves, boilers, mostly using this oil as fuel, other power plants, ceramic plants and many other enterprises to use more of this fuel. In addition, this oil through the oil processing and reconciling national standard can be directly used as fuel engine. Buy our equipment, users share a large network, this network has sold buy.
Q: How many countries your machine have been exported and installed?A: Our machinery have been sold to 90+ countries and regions around the world, winning great praise and trust of our customers all over the world! For example, Italy, Romania, Macedonia, Albania, Estonia, Rusian, Egypt, Ethopia, Nigeria, Congo, Lebanon, Jordan, Pakistan, Kazakhstan, India, Tailand, Malaysia, Mexico, Panama, Guatemala, Aruba, Jamaica, Ecuador, Haiti, etc.Q: Can we visit your factory of pyrolysis plant ? And where is your factory?A: Our office is in Zhengzhou City, Henan Province, China. From Zhengzhou International Airport to our office is just need 30min. We are responsible to pick customer up. We have sample machine in our factory for your visiting. Welcome at any time!
