2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer

2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer photo-1
2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer photo-2
2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer photo-3
2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer photo-4
2D Movement Coffee Cocoa Matcha Salt Powder Mixer Two Dimensional Tumbler Rotating Drum Mixer photo-5
US$ 2000 - 3000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Packaging Production Line
Application:
Drinks, Dairy Products, Cleaning, Detergent, Cosmetics, Skin Care Products, Oil, Tea, Vegetable, Fruit, Fish, Meat, Snack, Rice, Flour, Seasoning, Hair Care Products
Driven Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
shantou
Delivery Detail:
14 days
Type Packaging Production Line
Application Drinks, Dairy Products, Cleaning, Detergent, Cosmetics, Skin Care Products, Oil, Tea, Vegetable, Fruit, Fish, Meat, Snack, Rice, Flour, Seasoning, Hair Care Products
Driven Type Electric
Website https://todaymachine.com/
Manufacturer Today Machine Co., Ltd
Email sales@TodayMachine.com
Origin CHINA

2D Motion Blender

The blender known as the Two-Dimensional Motion Mixer can move in two directions: by rotating its drum and by oscillating it with the frame. Because the materials spin, invert, and blend inside the drum, as well as experience side-to-side mixing from the oscillation of the drum, this dual movement guarantees complete mixing of the ingredients in a brief amount of time.

The oscillating frame, the stand, and the revolving drum make up its three primary components. The drum revolves on the oscillating frame, which is axially positioned by two stop wheels and supported by four rollers, two of which are powered by a power system. A crank-rocker mechanism on the stand powers the oscillating frame, which enables the drum to revolve and oscillate at the same time, guaranteeing complete material mixing inside.



Two-Dimensional Motion: To ensure complete mixing of all ingredients, the 2D Mixer uses a special two-dimensional motion that combines oscillation and rotation.

Adjustable Time and Speed: You can change the mixing time and speed to fit your particular application and material needs.

Sturdy Construction: The 2D Mixer is made with premium components and sophisticated engineering to endure regular use and deliver enduring performance.



TECHNICAL SPECIFICATION

Model

Volume

Max capacity

Voltage

Power

Dimension(mm)

Weight(kg)

EYH-250

225L

60kg

220V

2.2kw

1200*800*1120

260

EYH-500

485L

100kg

220V

3kw

1600*900*1200

850

EYH-800

835L

200kg

380V

3.3kw

2100*1050*1250

1300

EYH-1000

1085L

300kg

380V

4kw

2300*1200*1800

1500
