Home > Products > graphite crucible > High Purity Graphite Crucibles for Matal Casting
High Purity Graphite Crucibles for Matal Casting
Negotiable
/ Piece
1 Piece(Min. Order)
- qingdao
- T/T
- 30 days
You May Like
-
High Purity Graphite Crucibles for Matal Casting
-
Customized High Strength Graphite Rod High Pure Graphite Electrode Rods
-
High Purity Graphite Ingot Mold Graphite Customize Mold Casting for Industries
-
Customized High Purity Graphite Crucibles for Matal Casting
-
Factory Supply High Purity Graphite Crucible for Gold Smelting
-
Wholesale Price High Purity Graphite Crucibles for Gold Silver Smelting
Product Details
| Brand Name | Yiguan | Type | Isostatic | |
| Application | for matal casting | Height | customize | |
| Composition | High Pure | Bottom Diameter | customize | |
| Top Diameter | customize |
Product Description
| Technical Parameters | YG-4 | YG-5 | YG-6 | YG-7 | YG-8 |
| Density (g/cm³) | 1.8 | 1.85 | 1.9 | 1.82 | 1.9 |
| Electrical Resistivity (μΩ.m) | 8~11 | 8~10 | 8~9 | 11~13 | 11~13 |
| Thermal conductivity 100℃ (W/m.k) | 121.1 | 139.2 | 140 | 85~110 | 85~110 |
| Coefficient of Thermal Expansion (indoor temperature-600℃) 10-6℃ | 5.46 | 4.8 | 4.5 | 5.7 | 5.85 |
| Shore hardness (HSD) | 42 | 48 | 53 | 65 | 70 |
| Flexural Strength (Mpa) | 38 | 48 | 55 | 51 | 60 |
| COMPRESSION STRENGTH (Mpa) | 65 | 85 | 95 | 115 | 135 |
| Elasticity modulus (Gpa) | 9 | 11.8 | 12 | 11 | 12 |
| Porosity % | 17 | 13 | 11 | 12 | 11 |
| Ash Content (PPM) | 500 | 500 | 500 | 500 | 500 |
| Granularity (μm) | 13~15 | 13~15 | 8~10 | 8~10 | 8~10 |
| Usage | common use | common use | Continuous casting, Sintering, High temperature metallurgy | EDM, Photovoltaic | EDM, Photovoltaic, Glass |
