POWDER Coated round hole Perforated Metal Mesh,Stainless steel perforated and Hot zin perforated plate

Pallets and wooden box.

Perforated metal mesh usually used galvanized steel, stainless steel, copper steel, aluminum steel, nickel steel and alloy steel as material. We have advanced CNC equipment, our products made by model. Our products have the advantage of high precision, small error and good quality. The punch diameter from 0.3mm to 100mm, and made thickness equal diameter, namely the thickness 0.5mm can punch diameter 0.5mm.


Feature of perforated metal:

• Easily process. There are a variety selection of plate thickness, pore size and arrangement.

• Beautiful appearance, our products through painting or polishing have the advantage of abrasion resistance and long service life.

• Uniform mesh and smooth surface.

• Low cost, easy to install.

Material:
 The raw material usually is stainless steel carbon plate, galvanized plate and cold rolled coil, etc.

The classificationGalvanized perforated metal

Galvanized Perforated Metal is made of high quality low carbon Galvanized steel sheet after being perforated on the digital control perforated machines. Galvanized Perforated Metal has the features of good strength-to-weight ratio, wide range of open area percentages, accurate hole size, available in corrosion resistant materials, available in lightweight material and suitable for decorative applications.

Specification:

• The thickness of coil from 0.2mm to 1mm, the length from 1m to 20m, the diameter from 0.8mm to 10mm.

• The thickness of plate from 0.3mm to 10mm, size 1.53m, the diameter from 0.8mm to 100mm. Specific style according to customer requirements.

Process of Perforated Metal:

• Hot-dipped galvanized perforated metal. Immersed thin steel plate into the zinc bath, adhesion to the surface layer of zinc. Currently the main use is production of continuous galvanizing process, that is a continuous roll of steel immersed in melted zinc plating bath is made with galvanized steel.

• Electro galvanized perforated metal. This kind of perforated metal have a good ability of processed. However, thinner coatings, corrosion resistance than hot-dip galvanized perforated metal sheet.

Stainless steel perforated metal

Stainless Steel Perforated Metal is made of high quality Stainless Steel sheet/coil after being perforated on the digital control machines. Stainless Steel Perforated Metal is used in a variety of corrosive atmospheres; its long life pays back its seemingly high cost.

Specification: The thickness of coil from 0.2mm to 0.7mm, the length from 1m to 20m, the diameter from 2mm to 20mm. The thickness of plate from 0.3mm to 3mm, the minimum aperture is 0.6mm.

Aluminum perforated metal

Aluminum Perforated Metal is made of high quality aluminum sheet/coil after being perforated on the digital control perforated machines. Aluminum perforated metal has the features of good strength-to-weight ratio, wide range of open area percentages, accurate hole size, available in corrosion resistant materials, available in lightweight material and suitable for decorative applications.

Hole shape: Round hole, square hole, long round hole, triangle hole, scale hole, diamond hole, oval hole, hexagonal hole, slot hole, and so on.

The application of perforated metal:

• Used for environmental noise control barriers, such as, highway, railway, subway, etc.

• As sound-absorbing material of the building ceiling and wall.

• Used for building stairs, balconies, beautifully decorated plate of green furniture.

• Protective cover for the machinery and equipment, ornate speaker enclosures.

• Used as kitchenware, such as, stainless steel fruit basket, food cover, fruit tray, etc.

• Shopping network with shelves, decorative exhibition units.

• Grain storage within the ventilation network, soccer turf seepage water treatment network, and so on.

Plate  material	Thickness of metal (mm)	Hole Dia. (mm)	Pitch (mm)	Sheet Width(m)	Porosity (%)	Weight (kg/m2)
Rolling plate	0.2	6	2	1	44	0.88
	0.35	5	4	1	24	2
	0.45	6	3	1	35	2.5
	0.8	3	3	1	19.6	3
Flat  plate	0.5	1	1	1	19.6	3.14
	0.55	1.1	2.2	1	22.67	3.411
	0.55	1.5	2.8	1	26.03	3.268
	0.8	1.5	1.5	1	19.6	5
	0.8	2	3.4	1	30.78	4.465
	1.5	2	2	1	19.6	9.4
	1.5	5	8.0	1	35.39	7.843
	3	5	16	1	19.6	18.8
Stainless  steel  plate	0.5	1	1	1	19.6	3.14
	0.8	1.5	1.5	1	19.6	5
	1	2	2	1	19.6	6.28
	2	5	16	1	19.6	6.28
Aluminum plate	0.5	1	1	1	19.6	1.08
	0.8	3	3	1	19.6	1.72
	1.6	2	2	1	19.6	3.24
	3	4	16	1	19.6	4.23

Company Profile

BOLI Wire Mesh Co.,Ltd is an exporter and manufacturer of iron fence, wire mesh fence, chain link fence, crowd control barrier, temporary fence, etc. Our products are strictly manufactured according to ISO9001 quality standard.

Our company is located in Anping County, Hebei, China, which is the native land of wire mesh.After years of development, our company has grown into an all-round enterprise, integrating scientific research, production and management together. The total fixed assets of our company have come to 20 million USD. We regard customers as God and quality as the most important.

Our products are mainly used in the garden building, factory security, highway, construction site, and mine, and sell well to more than 30 countries and regions such as Europe countries, America, Canada, Australia, New Zealand, Singapore, Malaysia, Aferica countries and etc. Yingkang is an old company of Anhua Group. We specialized in fence and wire mesh field since 1996. We can supply the most suitable and best solutions. Qualified products and professional service is our main purpose.

Our Advantages

1> Free Sample can be offered;
2> Free Drawings can be offered;
3> OEM and ODM order are accepted;
4> Good Quality + Factory Price + Quick Response + Reliable Service;
5> Provide visualization services to view production progress anytime and anywhere;
6> Rich exporting market experience offered to enlarge your market;
7> Warranty: Best quality products to be manufactured. if the quality is not meet your demand, we are sure to give you full compensation in any way, money back or free reorder.

FAQ

1. Who are we?
BOLI WIRE MESH CO based in Hebei, China, start from 2008, selling to Southeast Asia(15.00%),Oceania(15.00%),South America(12.00%),Eastern Europe(10.00%),Domestic Market(10.00%),Mid East(8.00%),Africa(6.00%),Western Europe(6.00%),North America(5.00%),Eastern Asia(3.00%),Central America(3.00%),Northern Europe(3.00%),Southern Europe(2.00%),South Asia(2.00%).

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
All kinds of wire mesh and related products, such as wire mesh fence, barbed wire, razor wire, gabion box, chain link fence, steel grating, temporary fence, expanded metal sheet, stainless steel wire mesh, window screen and so on.

4. Why should you buy from us not from other suppliers?
We are specialized in fence and wire mesh field since 2008. We can supply the most suitable and best solutions. Qualified products and professional service is our main purpose.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Credit Card, Western Union, Cash, Escrow;
Language Spoken: English, Chinese, Japanese, Korean, France
