12W 12VDC 1000mA IP20 Lead-acid Battery Charger 12V Kids Electric Car Charger for Kids Electric Motorcycle Charger

12W 12VDC 1000mA IP20 Lead-acid Battery Charger 12V Kids Electric Car Charger for Kids Electric Motorcycle Charger photo-1
12W 12VDC 1000mA IP20 Lead-acid Battery Charger 12V Kids Electric Car Charger for Kids Electric Motorcycle Charger photo-2
12W 12VDC 1000mA IP20 Lead-acid Battery Charger 12V Kids Electric Car Charger for Kids Electric Motorcycle Charger photo-3
12W 12VDC 1000mA IP20 Lead-acid Battery Charger 12V Kids Electric Car Charger for Kids Electric Motorcycle Charger photo-4
US$ 1.5 - 3 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
Anenerge
Place of Origin:
China
Model Number:
RKP-EU1201000DP-2-#5633
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
3 days
Brand Name Anenerge
Place of Origin China
Model Number RKP-EU1201000DP-2-#5633
Connection Plug In
Output Type DC

12W 12VDC 1000mA IP20 lead-acid battery charger 12V kids electric car charger for kids electric motorcycle charger


Model Number RKP-EU1201000DP-2-#5633
Brand Name Anenerge
origin China
Small Orders Accepted

Key Specifications/Special Features:

LED Power Supply/LED Driver/AC DC Adapter
Model No.: RKP-EU1201000DP-2

Key Specifications:
  • Input voltage: 100-240VAC

  • Input frequency range: 50/60Hz

  • Input current: 0.3A

  • Output voltage: 12VDC

  • Output current: 1000mA

  • Output power: 12W

  • Output with min 18AWG while the output current>2A and Min21AWG while the output voltage

  • No load power consumptions: less than 0.1W

  • With 2-4 hours full load burn-in test and 100% hi-pot test

  • Temperature ambient: 40℃

  • Surface temperature of body: 75℃

  • Humidity range: 35 to 80% RH

  • Constant voltage precision: ±5%

  • MTBF: ≥ 60000 hours at 25℃

  • Dimansions: 74x29x81mm

  • Weights: 0.07kg

  • Type: direct plug-in


Special Features:
  • Universal AC input/full range

  • Certificates: TUV/GS CE

  • Efficiency standard: DOE VI, NRCan, ERP, CEC, COC V5 Tier2

  • Safety compliance: UL1310+UL8750

  • Protections: SCP, OVP, OCP and OTP

  • High reliability and light weight

  • Low working temperatures

  • Low noise, energy saving and environment friendly

  • Fire-proof plastic case and cooling by free air convection

  • Compact size and low cost

  • Low ripple design

  • 24 months warranty


Custom:
  • OEM/ODM orders are accepted


Applications:
  • LED lights

  • Medical equipment

  • Home appliance and more

12W 12VDC 1000mA IP20 direct put-in LED drivers supplier

Input voltage: 100-240VAC

Input frequency range: 50/60Hz

Input current: 0.3A

Output voltage: 12VDC

Output current: 1000mA

Output power: 12W

Output with min 18AWG while the output current>2A and Min21AWG while the output voltage

Dimansions: 74x29x81mm

Weights: 0.07kg

Type: direct plug-in


Product Certifications
Certificate Standard UL
Certificate Image
UL
Click on the picture to see a larger one
Certificate Number E467791-20160815
Validity From 2016/08/17 To 2025/08/16
Issued By UL LLC
Certificate Standard GS
Certificate Image
GS
Click on the picture to see a larger one
Certificate Number Z1A 090755 0016 Rev.00
Validity From 2019/01/10 To 2024/12/24
Issued By TUV SUD Products Service GmbH
Certificate Standard SAA
Certificate Image
SAA
Click on the picture to see a larger one
Certificate Number SAA-192783-EA
Validity From 2019/10/10 To 2024/10/10
Issued By SAA Approvals Pty Ltd
Certificate Standard UKCA
Certificate Image
UKCA
Click on the picture to see a larger one
Certificate Number UKCA GZES2106021725LM
Validity From 2021/09/10 To 2025/09/10
Issued By SGS-CSTC
Note: Not all certifying agents offer online lookup, and some have a lag time for posting new certificates. If you are unable to find a certificate online, contact the certification agency or supplier for further verification.
Shipping Information

FOB Port Shenzhen
Weight per Unit 0.082 Kilograms
HTS Code 8504.40.99 99
Export Carton Dimensions L/W/H 47.5 x 28.0 x 36.0 Centimeters
Lead Time 15–18 days
Dimensions per Unit 7.4 x 2.9 x 6.3 Centimeters
Units per Export Carton 165.0
Export Carton Weight 16.8 Kilograms
