Help CenterGlass Lined Reactor 50L-80000L
Related Products
Glass lined reactor, jacketed, 50L-80000L capacity, two pieces type (i.e. FK, open type) and one piece type ( i.e. FF, closed type), with good anti-corrosion performance widely to be used in the reaction, neutralization, and polymerization etc process:
1. The detailed assembling of our Glass lined reactor:
(1) Electric Motor: Explosion-proof, Ordinary type;
(2) Reducer(i.e.gear box): Cycloidal-pin wheel type, Spiral bevel gear type, Helical gear type;
(3) Seal type: Packing seal, Mechanical Seal (single type, double type);
(4) Agitator: Frame type, Anchor type, Impeller type, Paddle type, combination type;
(5) Thermometer Pocket: A type (Straight); B type (Slant), C type ( Slant with Wing);
(6) Bottom discharge Valve: Upper extension type,
2. The technical performance of our Glass lined reactor:
(1)The working pressure: Inside the vessel: less than or equal to 1.0Mpa (for Packing seal: less than or equal to 0.2Mpa; for Single mechanical seal: less than or equal to 0.4Mpa, for Double mechanical seal: less than or equal to1.0Mpa); Inside the jacket: less than or equal to 0.6Mpa;
(2) The working temperature: from -20 degree centigrade to 200 Celsius degree, the cooling shock: 110 Celsius degree, the thermal shock: 120 Celsius degree;
(3) The Glass-lining thickness: 0.8-2.0mm;
(4) The high Voltage-test to the Glass-lining: 20KV.
(5) Nonstick: the smooth and clean glass-lining surface is nonstick to the materials.
(6) Anti-corrosion performance: suitable for all kinds of organic or inorganic acids, organic solvents and weak alkaline etc.
Besides Glass lined reactor, we also make Glass lined storage tank 200L-50000L, distiller 300L-6000L, condenser and dryer etc, certified by ISO900 and as one world class manufacturer & supplier of Glass lined equipments in china, we promise our products in high quality with favorable price and excellent service, select us, select trust, please contact us for more details, thanks.
