Home > Products > Mechanical Seal > Double Sealing Mechanical Seal 224UU-35-50-65 304SS 316L Silicon Carbide or Hard Alloy or Graphite Seals
Double Sealing Mechanical Seal 224UU-35-50-65 304SS 316L Silicon Carbide or Hard Alloy or Graphite Seals
- Shanghai Seaport
- T/T L/C Cash
- 25 days
You May Like
-
H74D-35 U22U22V22VGG Double Hard Alloy Sealing Surface Mechanical Seal Used for Chemical Pump ZCPZA005-0200
-
ZIPO ZYX Vertical Immersion/submerged Slurry Pump or ZYJ Stirring Type Submerged Slurry Pump
-
ZIPO ZISW or ZISWH or ZISWR Horizontal Pipeline Centrifugal Pump
-
ZIPO ZND or ZNG Type High Lift Wear Resistant Alloy Steel Mud Slurry Pumpp
-
ZIPO Industrial Pump 3ZPNL Vertical Mud Slurry Pump
-
3ZPN Horizontal Single Stage Single Suction Mud Pump
Product Details
| Brand Name | ZP | Place of Origin | China | |
| Model Number | 224UU-35-50-65 304SS 316L | Material | Metal | |
| Style | Mechanical Seal | Standard or Nonstandard | Nonstandard |
Product Description
cartridge mechanical seal
Double sealing mechanical seal 224UU-35-50-65 304SS 316L silicon carbide or hard alloy or graphite seals
Online service: WEIXIN: 180 (8165) 9672 or Zipo2019; Q: 219(141)7589
Machine seal code: 224UU-35 Q2Q2VGG
Material: Rotating Ring Silicon Carbide (SiC)
Fixed Ring Silicon Carbide (SiC)
Spring seat: 316L Spring: 316L
O-ring: Fluororubber
Applicable pump type: ZCPZX25-200
Machine seal code: 224UU-35 U22B3V2GG
Rotating ring: Hard alloy
Fixed ring: Graphite
Spring seat: 316L Spring: 316L
O-ring: Fluororubber
Applicable pump type: ZCPZX32-200
Machine seal code: 224UU-35 U22B3V2GG
Rotating ring: Hard alloy
Fixed ring: Graphite
Spring seat: 316L Spring: 316L
O-ring: Fluororubber
Applicable pump type: ZCPZX40-125
Machine seal code: 224UU-50 U22B3V2FF
Rotating ring: Hard alloy
Fixed ring: Graphite
Spring seat: 321SS or 304SS
Spring: 321SS or 304SS
O-ring: Fluororubber
Applicable pump type: ZCPLF25-15-200
Machine seal code: 224UU-65 Q2Q2VGG
Rotating ring: Silicon carbide SIC
Fixed ring: Silicon carbide SIC
Spring seat: 316L
Spring: 316L
O-ring: Fluororubber
Applicable pump type ZCPZX100-400
Manufacturer: ZIPO VALVE & PUMP CO., LTD
