10L Flexible FPC Second Stage

Product field: Automotive battery products

Layer number: 10L flexible FPC second order

Plate thickness: 0.350mm

Size: 142 * 106.0mm/1 * 1pcs

Process structure: PI, copper thickness 1OZ, covering film

The minimum mechanical hole is 0.35mm,

Laser hole 0.076mm

Minimum line width and spacing 5/5ml

Surface treatment: Sinking gold 1u"
