Industrial Terminal Blocks Distributor
US$ 15 - 20
/ Piece
1 Piece(Min. Order)
- Shanghai
- T/T L/C D/P D/A Credit Card Other
- 7 days
You May Like
Product Details
| Brand Name | Sell-Best | Place of Origin | China | |
| Type | PCB | Conductor Size | 1- 5 AWG | |
| Number of Contacts | 1 - 10 |
Product Description
PCB terminal block; Push-in CAGE CLAMP with operating lever; AWG 24 – 12; Pin spacing 5 mm; 6-pole; top entry; gray.
Feature of Industrial terminal blocks
PCB terminal blocks with Push-in CAGE CLAMP® connection and levers
Push-in termination of solid and ferruled conductors
Intuitive and tool-free operation
Several clamping units can be held open simultaneously, simplifying the connection of multi-core cables
Testing can be performed both parallel and perpendicular to conductor entry
| Connection points | 6 |
| Total number of potentials | 6 |
| Number of connection types | 1 |
| Number of levels | 1 |
| Connection technology | Push-in CAGE CLAMP® |
| Actuation type | Lever |
| Solid conductor | 0.2 … 4 mm² / 24 … 12 AWG |
| Fine-stranded conductor | 0.2 … 4 mm² / 24 … 12 AWG |
| Fine-stranded conductor; with insulated ferrule | 0.25 … 2.5 mm² |
| Fine-stranded conductor; with uninsulated ferrule | 0.25 … 2.5 mm² |
| Fine-stranded conductor; with twin ferrule | 0.25 … 1.5 mm² |
| Strip length | 9 … 11 mm / 0.35 … 0.43 inches |
| Conductor connection direction to PCB | 90° |
| Number of poles | 6 |
| Pin spacing | 5 mm / 0.197 inches |
| Width | 32.4 mm / 1.276 inches |
| Height | 25.3 mm / 0.996 inches |
| Height | 21.3 mm / 0.839 inches |
| Depth | 16.7 mm / 0.657 inches |
| Length | 4mm |
| Length | 0.8 x 1 mm |
| Length | 1.3 (+0.1) mm |
